Extron electronics SW RGBHV Series User Manual page 11

Introduction, cont'd
Autoswitching mode — When autoswitching is enabled, the switcher continuously
Operational flexibility — The operator can select the input and set the audio gain
Rack mount — Rack mountable in any conventional 19" wide rack with the
Power supply — Includes an internal 100 VAC to 240 VAC, 50/60 Hz, 20 watts,
1-4 SW RGBHV Series Switchers • Introduction
monitors all inputs and automatically switches to the highest-numbered
input with video sync pulses present. If video is absent from all inputs, no
input is selected.
and attenuation for each input using the front panel buttons or via the
switcher's Remote port RS-232 link. The RS-232 link allows remote control
via a PC or control system. You can select inputs via the switcher's contact
closure link on the Remote port. You can also remotely control the switchers
using a contact closure keypad connected to the Remote port or an Extron IR
102 Remote Control Kit (part #70-224-01) connected to the Remote port.
supplied rack ears. The two SW2 models require an optional RSU 129 or
RSB 129 1U Universal Rack Mount Kit (part #60-190-01 or 60-604-02) for rack
mounting.
auto-switchable power supply, which provides worldwide power
compatibility.
