Table of Contents

Chapter One • Introduction
About this Manual
IPL T S Series Products
IPL T S1 ................................................................................... 1-3
IPL T S2 ................................................................................... 1-3
IPL T S4 ................................................................................... 1-3
IPL T S6 ................................................................................... 1-3
Global Configurator
System requirements ............................................................. 1-5
Installing Global Configurator .............................................. 1-5
Chapter Two • Hardware Setup
Front Panel
Rear Panel
Power Connection
Local Area Network (LAN) Connection
Serial Device Connection
9-pin D connector ................................................................... 2-6
Captive screw connector ....................................................... 2-6
Chapter Three • Software Setup
Creating a Global Configurator Project File
Step one: download device drivers ...................................... 3-2
Step two: create a new project ............................................. 3-4
Step three: add a device ........................................................ 3-6
Step four: define the location of the new device ............... 3-8
Step five: save the new Global Configurator file ................ 3-9
Configuring a New Device
Step six: configure contacts ................................................ 3-10
Step seven: configure e-mail ............................................... 3-11
Step eight: assign device drivers ........................................ 3-12
Step nine: set scheduled actions and e-mail deliveries ..... 3-13
Step ten: set monitored conditions .................................... 3-17
Building and Uploading a GC File
Step eleven: build the Global Configurator file ................ 3-19
Step twelve: upload the Global Configurator file ............. 3-20
Step thirteen: change device settings (if desired) ............. 3-21
.................................................................... 1-2
.............................................................. 1-2
.................................................................. 1-4
................................................................................... 2-2
.................................................................................... 2-3
..................................................................... 2-4
IPL T S Series Interfaces • Table of Contents
................................................... 1-1
............................................ 2-1
............................... 2-4
........................................................ 2-5
......................................... 3-1
.................................................... 3-10
...................................... 3-19
...................... 3-2
i
