  • Page 1 Setup Guide IP Link ® IPL T Series IP Link Ethernet Control Interfaces (IPL T S Series, IPL T SFI244, IPL T CR48) 68-1377-01 Rev. E 09 10...
  • Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source indicated This symbol is intended to alert the user of important on the product. This equipment is intended to be used with a main power system with a operating and maintenance (servicing) instructions in grounded (neutral) conductor.
  • Page 3 A caution warns of things that might damage the equipment. NOTE: A note draws attention to important information. Copyright © 2010 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners.
  • Page 5: Table Of Contents

    Contents Introduction ........1 About this Guide ........1 IPL T Series Products ......1 IPL T S Series ........1 IPL T SFI244 ........4 IPL T CR48 ........4 Global Configurator ......5 System Requirements ....7 Installing Global Configurator ..7 Setup ............9 Front Panel Features ......9 IPL T S Series ........9 IPL T SFI244 ........10 IPL T CR48 ........11...
  • Page 6 IPL T Series • Contents...
  • Page 7: Introduction

    IPL T CR48 User Guide for more detailed information. IPL T Series Products The IPL T Series includes the IPL T S Series (IPL T S1, S2, S4, S6), the IPL T SFI244, and IPL T CR48 Ethernet Control Interfaces. These controllers can be installed as nodes on an Ethernet-based network.
  • Page 8 IPL T S2 Features of the IPL T S2 include: 12 VDC, 1 A desktop power supply RJ-45 Ethernet receptacle Two (2) 9-pin D RS-232, RS-422, or RS-485 serial ports - or - Two (2) 3.5 millimeter captive screw RS-232 serial ports (common to the two 9-pin D serial ports) Six (6) Ethernet control ports IPL T S4...
  • Page 9 Lighting Control Extron IPL T S4 Ethernet Control Interface with GlobalViewer software U ID RS-232 p to .5 A D IS TCP/IP M IN Network t r o RS-232 Extron Ethernet MLC 206 MediaLink Controller Remote User Control & Administrator Monitoring Projector Laptop...
  • Page 10: Ipl T Sfi244

    IPL T SFI244 Features of the IPL T SFI244 include: 12 VDC, 1 A desktop power supply RJ-45 Ethernet receptacle Two (2) RS-232 serial ports Four (4) flex I/O ports Four (4) I/R ports Six (6) Ethernet control ports Motion Projector Detector RS-232...
  • Page 11: Global Configurator

    Screen Control Projector Blinds Lift Control Projector Extron IPL T CR48 0 .5 Ethernet Control TCP/IP Interface Network Lighting System GlobalViewer ® A/V Resource Management and Remote Control Application Figure 3. Typical IPL T CR48 Controller Application Global Configurator Global Configurator (GC) is a software application that gives you the ability to create a single configuration file of all the controlled devices on their audio/video (A/V) network.
  • Page 12 Figure 4. Global Configurator Application Screen Using GC you can configure a single room controller or create a Web-based remote monitoring system for hundreds of A/V devices in multiple locations. You can configure an IPL T controller using GC without having the device physically connected to the A/V network.
  • Page 13: System Requirements

    System Requirements The miminum system requirements for the PC on which you install Global Configurator include: Intel Pentium III, 1 GHz processor ® ® Microsoft Windows XP SP2, Windows Vista , or Windows 7 ® ® ® Microsoft Internet Explorer 6.0 with ActiveX enabled ®...
  • Page 14 To install Global Configurator from an Extron Software Products Disk if Autorun is not enabled on your PC: Insert the Extron Software Products Disk into the disk drive of your PC. From the Windows desktop, open My Computer and select the appropriate disk drive.
  • Page 15: Setup

    Configuring the IPL T Series with Global Configurator Front Panel Features IPL T S Series Power LED — A green LED lights to indicate that the unit is receiving power. IPL T S1 Reset button — Recessed multiple function Reset button. See Resetting the Controller for more information.
  • Page 16: Ipl T Sfi244

    LINK LED — A green LED lights to indicate that the IPL T S6 unit is connected to an active network. LINK ACT LED — A yellow LED lights to indicate that data is being sent or received. IPL T SFI244 IPL T SFI244 LINK Power LED —...
  • Page 17: Ipl T Cr48

    LINK LED — A green LED lights to indicate that the unit is connected to an active network. ACT LED — A yellow LED lights to indicate that data is being sent or received. Rear Panel Features IPL T S1 MAC: 00-05-A6-XX-XX-XX S/N: IPL T S Series 0.5A MAX COM1 Power connection —...
  • Page 18: Ipl T Sfi244

    COM4 — 9-pin D connector for IPL T S6 serial port 4 COM1 MAC: 00-05-A6-XX-XX-XX S/N: MAC address — The unique POWER COM2 hardware ID number (MAC COM3 COM4 COM5 COM6 .5A MAX address) of the unit (for TX RX TX RX TX RX TX RX...
  • Page 19: Resetting The Controller

    Resetting the Controller There are five reset modes (numbered 1, 2, 3, 4, 5 for the sake of comparison with other Extron IPL products) available by using the Reset button ( ) on the front panel. The Reset button is recessed, so use of a pointed stylus, ballpoint pen, or Extron Tweeker is suggested.
  • Page 20: Connections And Wiring

    Connections and Wiring Power Connection To connect the power supply: Insert the 2-pole captive screw connector into the power supply receptacle on the rear panel of the controller. Ridges Smooth SECTION A–A 3/16” (5 mm) Max. Power Supply Output Cord MAC: 00-05-A6-XX-XX-XX S/N: FLEX I/O...
  • Page 21: Serial Device Connection

    Clear to Send/Receive Data + Figure 8. 9-pin D Connector Pinouts NOTE: IPL T S1 supports RS-232 only. With RS-485, Data + can connect to pin 7 or 8. Data - can connect to pin 2 or 3. IPL T Series • Setup...
  • Page 22: Relay Ports

    Captive screw connector The IPL T S2, IPL T S6, and IPL T SFI244 have COM ports with captive screw connectors. The two COM ports with captive screw connectors on the IPL T S2 are common to the two 9-pin D connectors. Only one connector can be used for each COM port.
  • Page 23: Ir Ports

    IR Ports The IPL T SFI244 has four IR ports for infrared device connection. You can connect IR emitters or a wired IR control port of another device to send IR signals (with or without carrier frequencies) to display or source devices.
  • Page 24: Flex I/O Ports

    Flex I/O Ports The IPL T SFI244 has four Flex I/O ports that can be configured as digital inputs, digital outputs, or analog inputs. When configured as digital inputs, the Flex I/O ports can connect to switches and sensors. When configured as digital outputs, the Flex I/O ports can drive devices that accept a TTL input signal.
  • Page 25 Then, you must change the default settings of the controller (IP address, subnet mask, and [optional] administrator name and password) in order to use the controller on an intranet (LAN) or on the Internet. After you have set up the IPL T controller for network communication, you can reset the PC to its original network configuration.
  • Page 26: Configuring The Ipl T Series With Global Configurator

    Execute a ping command by typing ping followed by a space and the new IP address at the command prompt. For example: ping 10.13.170.15 After issuing this command, the controller changes to the new address and starts responding to the ping requests, as described. You must ping the IPL T controller in order for the IP address change to take place.
  • Page 27 IPL T Series • Setup...
  • Page 28 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
  • Page 29 +971.4.2991880 FAX Inside Asia Only Inside China Only Inside USA/Canada Inside USA/Canada Inside Europe Only Only Only +65.6383.4400 +86.21.3760.1568 +31.33.453.4040 +65.6383.4664 FAX +86.21.3760.1566 FAX +1.714.491.1500 +1.919.863.1794 +31.33.453.4050 FAX +1.714.491.1517 FAX +1.919.863.1797 FAX www.extron.com © 2010 Extron Electronics All rights reserved.
