GAS CONNECTIONS

MAKING THE CONNECTIONS

10
3"
15"
Install a manual shut-off valve in the gas
A
supply line in an easily accessible location.
Know how and where to shut off the gas
B
supply to the range.
C Shut off gas supply before removing an
old range. Leave it off until hookup of
new range is finished.
D Because solid pipe restricts moving the
range, we recommend use of a C.S.A.
certified flexible metal appliance
connector.
WARNING:
flexible connectors. The use of old flexible
connectors can cause gas leaks and personal
injury. Always use new flexible connectors
when installing a gas appliance.
Installation Instructions
7"
"
3 1 ⁄
2
12"
Never reuse old
Gas supply to
top burner
Pressure
regulator as
seen from
front of range
NOTE: When
screwing on the flare
union adaptor, hold
the gas inlet firmly
with a wrench.
MAKING THE CONNECTIONS
10
(cont.)
Install 1/2" flare union adaptor to the 1/2"
E
NPT elbow on pressure regulator.
F Connect flexible appliance connector to
flare union.
Move range into approximate position
G
and connect flexible connector to gas
supply line with proper flare union
adaptor.
Shut-off valve
7" Max.
90° street
Gas
elbow
supply
line
To prevent gas leaks, put a pipe joint
H
sealant or Teflon
threads. NOTE: Make sure sealant or tape
is compatible with Natural and LP gases.
When you are finished making
I
connections, be sure that all range knobs
are turned to OFF before you open the
main gas supply valve.
WARNING:
to check for gas leaks. Use liquid leak detector
at all joints and connections to check for leaks
in the system.
7
Flexible gas line
Pressure
regulator
tape on all male
®
Do not use a flame
