• Enter the values shown on
the page.
Channel 1
Control
Wait set point
Max speed
: 0.00 °C
Set point
: 0.00 °C/min
Grad.
: 1,00 °C
Near set
Temperature 30°C
At maximum speed
: 30.00 °C
Set point
: 0.00 °C/min
Grad.
: 1,00 °C
Near set
Channel 2
Control
Wait set point
Max speed
Channel 2
Control
Wait set point
Max speed
Set point : 0.00 RH %
Grad. : 0.00 RH %/min
Near set : 3,00 RH %
60% humidity
At maximum speed
Set point : 60.00 RH %
Grad. : 0.00 RH %/min
Near set : 3,00 RH %
21
B8
: ON
Turn all the values to ON as shown
: ON
: ON
B9
B10
Leave the gradient at 0 = max speed
Default value (tollerance within which
the segment is considered to have been
reached)
B11
Channel 2: to set the humidity
: OFF
: OFF
: OFF
B12
: ON
Turn all the values to ON as shown
: ON
: ON
B13
Default value
B14
Leave the gradient at 0 = max speed
Default value
(tollerance within which the segment is
considered to have been reached)
