Install Plastic Cover; Configuring Bendix; Wingman Acb; Following Distance Alerts - BENDIX Wingman ACB Service Data

FIGURE 21 - ACOM ® SOFTWARE – CONFIGURATION
NUMBER
Con-
fi guration Option
No.
City
1
(Bendix
Highway
Default)
(>37 mph)
City
2
Highway
(>37 mph)
City
3
Highway
(>37 mph)
City
4
Highway
(>37 mph)
City
5
Highway
(>37 mph)
City
6
Highway
(>37 mph)
TABLE 8 - CONFIGURING FOLLOWING DISTANCE ALERTS (FDA) FOLLOWING DISTANCE
Following Distance Alert (sec)
Slow Medium
— —
1.5 1.0
— —
1.5 1.0
— 1.5
2.0 1.5
— 1.5
2.0 1.5
— 1.5
3.0 2.0
3.0 1.5
3.0 2.0

INSTALL PLASTIC COVER

With a slight force, push the cover onto the bracket so that
the plastic fasteners line up with the slots on the plastic
cover. Ensure the cover is secure over the ACB sensor
assembly before driving the vehicle.

CONFIGURING BENDIX

FOLLOWING DISTANCE ALERTS

Multiple alert and distance setting strategies, known as
Following Distance Alert (FDA) confi gurations, can be
chosen using the Bendix
(version 6.3 or higher) the service technician will fi nd a
selection box called "Confi guration Number" which gives
the service technician the choices shown in Figure 21 and
in Table 8.
Changing confi guration allows the fl eet user to adjust both
the following distance alerts and the following distance
behind a forward target vehicle, while in distance control
mode. See Figure 21.
ACB
Following
Fast
Distance
0.5
2.8
0.5
0.5
3.5
0.5
1.0
2.8
1.0
1.0
3.5
1.0
1.0
3.5
1.0
1.0
3.5
1.0
®
WINGMAN
® ACom ® tool. In ACom
Following Distance
Example (Feet @ 60mph)
246'
308'
246'
308'
308'
308'
®
ACB
® software
25
