BENDIX Wingman ACB Service Data page 12

Questions To Ask The
Driver
Has the sensor been changed
recently?
Does the mounting bracket look
damaged or tampered with?
Did the ACB sensor currently on the
vehicle come from another vehicle?
With cruise control "set", does the
system consistently bring on the
foundation brakes when a forward
vehicle slows?
Does a trouble code seem to occur
when driving through the desert
or in barren areas (no road signs,
trees or vehicles)?
Does the system seem to disengage
after an automatic braking event?
Does cruise control disengage
sometimes when the brakes come
on and not at other times?
Does the connector or wiring
appear damaged?
Does the system generate a trouble
code going down a grade, but the
code goes away later?
Does the sensor have noticeable
d a m a g e b e y o n d n o r m a l
discoloration or surface scratches?
12
If so, the new sensor may be incompatible with the vehicle. Follow the SENSOR INTERCHANGEABILITY procedure
and check system trouble codes with Bendix
Read BENDIX WINGMAN ACB DIAGNOSTIC TROUBLE CODES VIA BENDIX
® ®
Other than expected surface scratches or some discoloration over time, there should be no visible damage to the
sensor bracket assembly. If so, realign the sensor vertically and laterally. If sensor alignment cannot be held in
place, the bracket assembly must be replaced. Verify the bumper is not damaged.
• Check the vertical alignment and adjust if needed.
• Check the lateral alignment and adjust if needed.
• Wingman ACB Mounting - The ACB Wingman sensor needs a solid mounting surface in order to hold alignment.
®
If the bumper or mounting cross member is damaged, replace it fi rst, then align the sensor.
The sensor may be incompatible with the new vehicle. Follow the SENSOR INTERCHANGEABILITY procedure
and check system trouble codes with Bendix
Read BENDIX ® WINGMAN ® ACB DIAGNOSTIC TROUBLE CODES VIA BENDIX
This is normal operation. Continue asking the driver questions to diagnose the problem. The sensor may be
blocked or misaligned. The service technician will need to check trouble codes as well.
• Check the vertical alignment and adjust if needed.
• Check the lateral alignment and adjust if needed.
Check ACB MOUNTING - This system needs a solid mounting surface in order to hold the alignment. If the bumper
or mounting cross member is damaged, replace it fi rst, then align the sensor.
Read BENDIX WINGMAN ACB DIAGNOSTIC TROUBLE CODES VIA BENDIX
® ®
In normal operation the Wingman
pre-determined period. This is rare, but most likely to occur when driving in deserts or barren areas. If the sensor
does "go dormant," Wingman
®
cruise mode, providing a sensory warning to the driver as well.
The driver must actively re-engage the vehicle's cruise control. Once the desired cruise speed is set, Wingman
ACB will resume operation. When metallic objects are again "seen" by the Wingman
previously recorded in the Wingman
This is normal operation. The driver must "set" or "resume" the cruise control once again to regain the following
distance management function provided by Bendix
This is normal operation. When traveling with lightly loaded trailers or bobtail, Wingman
function even after an automatic brake application. No driver input is needed.
Wires can become corroded if the sensor is not plugged in properly. Clean the connectors on the wire harness
as well as the sensor and reattach. If wires are chaffed, replace the wire harness. Also, check for trouble codes.
Read BENDIX WINGMAN ACB DIAGNOSTIC TROUBLE CODES VIA BENDIX
® ®
See the TROUBLESHOOT WIRING HARNESS INSTALLATION section.
This is normal operation. Bendix
this, it will generate a trouble code. Verify there are no trouble codes. Proper down-grade driving techniques
should be used.
Read BENDIX WINGMAN ACB DIAGNOSTIC TROUBLE CODES VIA BENDIX
® ®
The radar sensor and bracket are very durable. However, if the sensor housing or lens is cracked or broken,
immediately look for trouble codes via Bendix
Read BENDIX WINGMAN ACB DIAGNOSTIC TROUBLE CODES VIA BENDIX
® ®
See the ACB MOUNTING section.
TABLE 5 - UNDERSTANDING THE DRIVER'S COMPLAINTS (CONTINUED)
Next Steps
ACom software.
® ®
ACom software.
® ®
ACB radar sensor may "go dormant" if it hasn't "seen" a metallic object after a
®
ACB provides a visible warning to the driver and the vehicle also will drop out of
system will clear automatically.
®
Wingman
®
Wingman ACB is not intended to be used on steep grades. If the system detects
® ®
ACom software and replace the damaged sensor.
® ®
ACOM SOFTWARE.
® ®
® ACOM ® SOFTWARE.
ACOM SOFTWARE.
® ®
sensor, the trouble code
®
ACB.
®
ACB may continue to
®
ACOM SOFTWARE section.
® ®
ACOM SOFTWARE.
® ®
ACOM SOFTWARE.
® ®
®
