Bosch Solution 6+6 Quick Reference Manual page 3

Quick Reference Guide
Solution 6+6
Introduction
Thank you for choosing the
this system extremely flexible, reliable and easy to use.
Before using the system for the first time, we suggest that you read the section in this Quick Reference Guide
called "Programming Using The Remote Codepad" to familiarise yourself with the basic programming
methodology.
The Quick Reference Guide is supplied with the
information to wire, configure and operate the system. Due to the systems many programmable features and
options we suggest that you obtain the complete Installation Manual which provides detailed information on all
system options and functions as well as detailed information on the numerous programming methods.
Programming
The programming options of this system are stored in a non-volatile EPROM. This memory will hold all the
relevant configuration and user specific data even during a total power loss.
The data retention time is as long as ten years without power, therefore no reprogramming will be required after
powering the system down.
The data can be altered as many times as required without the need for any additional specialised equipment.
This memory is laid out in numerous locations, each of which holds the data for a specific function. In general,
the entire programming sequence will consist of nominating the location then entering or altering the required
data. You will repeat this procedure until all the data has been altered to suit your requirements. The factory
default settings have been selected for Contact ID format.
Note: '15' is the maximum value that can be programmed into any location.
There are two programming modes. The Installer's Programming Mode and the Operators Programming Mode.
Both modes have individual access codes and these two codes must always be programmed differently. The
Master Code, as well as being able to arm and disarm the system gives access to the Operators Programming
Mode. The Installer's Code only gives access to the Installer's Programming Mode and does NOT arm and
disarm the system.
Programming of the
Solution 6+6
Note: For further information on the different programming options available for the Solution 6+6,
refer to the Installation Manual (MA600I).
control panel for your installation. We are sure that you will find
Solution 6+6
Solution
control panel can be carried out via any of the following four methods.
System Codepad
Hand Held Programmer (CC814)
Programming Key (CC810)
Alarm Link (Upload/Download) Software (CC816)
Bosch Security Systems Pty Limited
to provide users with enough basic
6+6
SOL 6+6 QUICK REF GUIDE.DOC
Page 3
