Bosch Solution 6+6 Quick Reference Manual page 11

Quick Reference Guide
Solution 6+6
Location 000 - 015
Primary Telephone Number
Location 016 - 031
Secondary Telephone Number
Location 032 - 047
Callback Telephone Number
Location 048
Dialling Format
Location 049
Handshake Tone
Location 050
Transmission Format
Location 051
Transmission Speed
Location 052 - 055
Subscriber ID Number
Location 056 - 059
Installer Code
Location 060
Ring Count
Location 061 - 100
User Codes
Location 71 - 75
User Code 3
15 15 15 15
Location 86 - 90
User Code 6
15 15 15 15
Location 101
Day Alarm Mask
Location 102
Code Retries
Location 103
EOL Resistor Value
1 = Australian DTMF
2 = Australian Decadic
3 = Alternate DTMF & Decadic (AUST)
1 = HI-LO Handshake (Contact ID)
2 = 1400 Hz (Ademco TX @ 1900 Hz)
3 = 2300 Hz (Sescoa TX @ 1800 Hz)
1 = Contact ID
2 = 4 + 2 Expressed
3 = 4 + 2 Pulsed
4 = 4 + 2 Pulsed + Checksum
5 = 4 + 1 Pulsed + Universal
1 = 1 Pulse / Second
2 = 10 Pulses / Second
3 = 15 Pulses / Second
15 = Answering Machine Bypass 1
14 = Answering Machine Bypass 2 (New - Software Version 1.27 Onwards)
User Code 1
2 5 8 0
User Code 4
0 15 15 15 15
User Code 7
0 15 15 15 15
1 = Zone 1
2 = Zone 2
4 = Zone 3
8 = Zone 4
1 = 1K 5 = 3K9
2 = 1K5 6 = 4K7
3 = 2K2 7 = 5K6
4 = 3K3 8 = 6K8
Bosch Security Systems Pty Limited
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
4 = International DTMF
5 = Reversed Decadic
6 = Alternate DTMF & Reversed Decadic
4 = No Handshake Required
5 = Pager
6 = 4 + 1 Pulsed Expanded
7 = 3 + 1 Pulsed Universal
8 = 3 + 1 Pulsed Expanded
9 = Reserved
10 = Reserved
4 = 20 Pulses / Second
5 = 20 Pulses / Second FDL
6 = 40 Pulses / Second
Location 61 - 65
User Code 2
8
Location 76 - 80
User Code 5
0
Location 91 - 95
User Code 8
0
9 = 10K 13 = Reserved
10 = 12K 14 = Reserved
11 = 22K 15 = Split EOL (3K3/6K8) For
12 = Reserved
SOL 6+6 QUICK REF GUIDE.DOC
Page 11
11 = Domestic
12 = Basic Pager
13 = Reserved
14 = Reserved
15 = Reserved
0 0 0 0
1 2 3 4
Location 66 - 70
15 15 15 15 0
Location 81 - 85
15 15 15 15 0
Location 96 - 100
0 15 15 15 1
6 Zones + 6 Tamper Zones
1
1
1
2
8
1
6
4
