Digimerge DCB13TL Quick Start Manual

Camera Specifications Camera Specifications
Image Sensor 1/4" Echelon Series Sensor
Video Format / Pixels NTSC: 656(H) x 492 (V)
Horizontal Resolution 480 TVL
Internal; 2:1 Interlace
Sync. & Scan. Systems
S/N Ratio > 48dB
Iris & Shutter Speed AES; 1/60 ~ 1/50,000 sec.
Minimum Illumination 0.6 LUX @ F1.2 (IR Off)
0 LUX (IR LEDs ON)
Video Output Comp. 1.0 Vpp @ 75ohm
Lens / Lens Mount 5.08 mm F2.8/ Fixed
FOV (diagonal) 50 Degrees
Termination Video: BNC Female
Power: Barrel Female
30 IR LEDs/850nm/75'(23m)
IR / Night Vision Range
Power Requirement 12V DC ±10%
Power Consumption 200mA max
Operating Temp. -4°F ~ 122°F
(-20°C ~ 50°C)
Weight (with stand) 10.4 oz / 294.8 g
Dimensions 3.9" x 2.7" x 3.2"
LxWxH 100mm x 68mm x 80mm
(with stand & sunshade)
IT'S ALL ON THE WEB!
Product Information
User Manuals
Quick Start Guides
VISIT
www.digimerge.com
Digimerge Technologies Inc.
Copyright © 2010 Digimerge Technologies Inc.
As our products are subject to continuous improvement,
Digimerge reserves the right to modify product design,
specifications and prices, without notice and without
incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
Copyright
HIGH RESOLUTION
COLOR IR BULLET CAMERA
MODEL:
QUICK START GUIDE
English Version 1.0
www.digimerge.com
©
2010 Digimerge Technology Inc.
DCB13TL
