Summary of Contents for Hunter Hydrawise HC
-
Page 2: Table Of Contents
Table of Contents Table of Contents HPC Hydrawise - Quick Start Guide HPC - Mounting the Controller HPC - Installing Station Modules HPC - Connecting Station Wires HPC - Connecting AC Power Copyright 2020 Hunter Industries. All Rights Reserved. -
Page 3: Hpc Hydrawise - Quick Start Guide
Note: Install screw anchors if attaching to drywall or masonry wall. 2. Align controller with the screw and slide the keyhole on top of the controller over the screw. 3. Secure controller in place by installing screws in the holes. Copyright 2020 Hunter Industries. All Rights Reserved. -
Page 4: Hpc - Installing Station Modules
Improper installation could result in shock or fire hazard. This device is not intended for use by young children. Never let children play with this device. HPC - Installing Station Modules Copyright 2020 Hunter Industries. All Rights Reserved. -
Page 5: Hpc - Connecting Station Wires
1. Route valve wires between control valve location and controller. 2. At valves, attach a common wire to either solenoid wire of all valves. This is most commonly a white colored wire. Attach a separate control wire to the remaining wire of Copyright 2020 Hunter Industries. All Rights Reserved. -
Page 6: Hpc - Connecting Ac Power
The battery allows the user to program the controller without AC power. Watering will not occur without AC power. Since this controller has non-volatile memory, the program clock and calendar will be retained Copyright 2020 Hunter Industries. All Rights Reserved. - Page 7 NOTE: To be performed by a licensed electrician only. Always use UL listed ½" (13 mm) conduit with male adapter when installing AC wiring. HPC controllers are intended to be supplied AC power with a 15A rated overcurrent protected device. Copyright 2020 Hunter Industries. All Rights Reserved.
