PRO-HC - Connecting AC Power

Indoor Cabinet:

1. Route transformer cable through the hole on the bottom left side of the controller

2. Connect one Yellow Wire to each of the screws marked 24AC and the Green Wire to

GND.

STEPS 1-4

Note: The indoor Pro-HC is not water or weather resistant and must be installed indoors or

in a protected area. This device is not intended for use by young children. Never let

children play with this device.

Page 1 Note: The indoor Pro-HC is not water or weather resistant and must be installed indoors or in a protected area. This device is not intended for use by young children. Never let children play with this device. Copyright 2020 Hunter Industries. All Rights Reserved.
Page 2 AC wiring. Pro-HC controllers are intended to be supplied AC power with an over-current protected device. Improper installation could result in shock or fire hazard. This device is not intended for use by young children. Never let Copyright 2020 Hunter Industries. All Rights Reserved.
