Remote Address
Control
Button Name
RIGHT 1785
TOP 1785
ZONE 1 1785
ZONE 2 1785
ZONE 3 1785
ZONE 4 1785
PIP MODE 1785
PIP SWAP 1785
HDMI 1 1785
HDMI 2 1785
HDMI 3 1785
HDMI 4 1785
DP 1785
DVI 1785
VGA 1785
OPS 1785

14. Locking the Keypad and IR Remote

The keypad and IR remote functionality can be locked on the display. To lock the keypad,
go to Main Menu > Advanced Settings > System Settings and select Keypad Lock.
To lock the IR remote, go to Main Menu > Advanced Settings > System Settings and
select IR Remote Lock.

15. Unlocking the Keypad and IR Remote

To unlock the keypad, press the following keys on the keypad in the order listed: UP, UP,
RIGHT, LEFT, DOWN. If the IR remote is unlocked, the keypad can also be unlocked by
using the IR remote to go to Main Menu > Advanced Settings > System Settings and
unchecking Keypad Lock.
To unlock the IR remote, press the following keys on the IR remote in the order listed: UP,
UP, RIGHT, LEFT, DOWN. If the keypad is unlocked, the IR remote can also be unlocked
Planar LookThru Transparent OLED Display User Manual
020-1380-00D
Data NEC Data From
Remote (Hex Code)
24 0x06F918E7
30 0x06F91EE1
35 0x06F923DC
36 0x06F924DB
38 0x06F926D9
39 0x06F927D8
37 0x06F925DA
40 0x06F928D7
41 0x06F929D6
42 0x06F92AD5
43 0x06F92BD4
44 0x06F92CD3
45 0x06F92DD2
46 0x06F92ED1
47 0x06F92FD0
48 0x06F930CF
IR Command Protocol
Description
Navigate down
Selects the top line in the current
menu
Selects the input for Zone 1
Selects the input for Zone 2
Selects the input for Zone 3
Selects the input for Zone 4
Selects the Multi-Source View
setting
Swaps the main and PIP windows
Selects HDMI 1 for the current
zone
Selects HDMI 2 for the current
zone
Selects HDMI 3 for the current
zone
Selects HDMI 4 for the current
zone
Selects DP for the current zone
Not used
Not used
Not used
