Model No. WESY81081
Serial No.
The serial number is found in the
location shown below. Write the
serial number in the space above.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
¨
USERÕS
MANUAL
PATENT PENDING
Advertisement
Table of Contents
Related Manuals for Weider WESY81081
Summary of Contents for Weider WESY81081
- Page 1 Model No. WESY81081 Serial No. The serial number is found in the location shown below. Write the serial number in the space above. Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you...
-
Page 2: Table Of Contents
This warranty gives you specific legal rights. You may also have other rights which vary from state to state. ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813 WEIDER is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
Important Precautions WARNING: To reduce the risk of serious injury, read the following important precautions before using the training system. 1. It is the responsibility of the owner to ensure that all users of the training system are ade- quately informed of all precautions. 2. -
Page 4: Before You Begin
Time (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is WESY81081. The serial number can be found on a decal attached to the WEIDER (see the front cover of this manual). -
Page 5: Assembly
Assembly Note: This introduction will save you more time than it takes to read it! Making Things Easier for Yourself Everything in this manual is designed to ensure that the assembly of our products can be complet- ed successfully by anyone. However, it is impor- tant to recognize that your new equipment is a sophisticated product with many small parts. -
Page 6: Frame Assembly
Frame Assembly 1. Before beginning assembly, make sure you have read and understood the information on page 5. Locate and open the parts bag labeled ÒFRAME ASSEMBLY.Ó Press a 2Ó Square Outer Cap (51) onto each end of the Stabilizer (5). Insert two 5/16Ó... - Page 7 4. Set four Weight Bumpers (19) onto the Base (8) and align them with the indicated holes. Insert both Weight Guides (23) through the Weight Bumpers (19) and the holes in the Base (8). Slide eight Weights (26) onto the Weight Guides (23). Make sure all of the Weights are turned so the pin grooves are on the same side and are oriented as shown on the drawing.
-
Page 8: Arm Assembly
7. Slide two 5/16Ó Flat Washers (56) onto two 5/16Ó x 1 3/4Ó Bolts (58). Align the holes in the bracket on the Top Frame (1) with the holes in the Rear Upright (18). Insert the 5/16Ó x 1 3/4Ó Bolts (58) and hand tighten two 5/16Ó Nylon Locknuts (53) onto them. - Page 9 11. Press a 2Ó Square Inner Cap (21) into the top end of each Press Arm (46). Press a 1Ó Round Inner Cap (49) into the indicated hole on each Press Arm (46). Attach each Press Arm (46) to the Press Frame (12) with two 5/16Ó...
-
Page 10: Cable Assembly
13. Press a 1 1/2Ó Square Inner Cap (33) into the Leg Lever (29). Lubricate a 5/16Ó x 2 1/2Ó Bolt (22). Attach the Leg Lever (29) to the Seat Frame (36) with the Bolt and a 5/16Ó Nylon Jamnut (80). Do not overtighten the Nylon Jamnut. - Page 11 16. Wrap the Short Cable (9) around a 3 1/2Ó Pulley (35) in the direction shown. Attach the 3 1/2Ó Pulley (35) and a Cable Trap (66) to the Left Butterfly Arm (47) with a 3/8Ó x 2Ó Bolt (62) and a 3/8Ó...
- Page 12 20. Wrap the Short Cable (9) around a 3 1/2Ó Pulley (35) in the direction shown. Attach the 3 1/2Ó Pulley (35) to the front bracket (M) underneath the Top Frame (1) with a 3/8Ó x 2Ó Bolt (62) and a 3/8Ó Nylon Locknut (63).
- Page 13 24. Move to the other side of the unit. Wrap the Long Cable (2) around a 3 1/2Ó Pulley (35) in the direction shown. Attach the Pulley to the Front Upright (42) with a 3/8Ó x 3 1/2Ó Bolt (54), a Cable Trap (66), a 3/8Ó Flat Washer (55) and a 3/8Ó...
-
Page 14: Seat Assembly
28. Wrap the Long Cable (2) around a 3 1/2Ó Pulley (35) in the direction shown. Attach the Pulley to the Front Upright (42) with a 3/8Ó x 3 1/2Ó Bolt (54), a Cable Trap (66), a 3/8Ó Flat Washer (55) and a 3/8Ó Nylon Jamnut (57). - Page 15 31. Press two 3/4Ó Round Inner Caps (34) into each Pad Tube (28). Insert one Pad Tube into the Seat Frame (36). Slide a Foam Pad (30) onto each end of the Pad Tube. Insert the other Pad Tube into the Leg Lever (29). Slide a Foam Pad (30) onto each end of the Pad Tube.
-
Page 16: Cable Diagram
Cable Diagram The Cable Diagram below shows the proper routing of the Short Cable (9) and the Long Cable (2). The numbers show the correct route for each Cable. Make sure the Cables are routed correctly, that the Pulleys move smoothly and that the Cable Traps do not touch or bind the Cables. -
Page 17: Adjustment
Adjustment The instructions below describe how each part of the home gym system can be adjusted. Refer to the exercise poster accompanying this manual to see how the home gym system should be set up for each exercise. IMPORTANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the cor- rect starting position for the exercise to be performed. -
Page 18: Weight Resistance Chart
Weight Resistance Chart This chart shows the approximate weight resistance at each station. ÒTopÓ refers to the 6 lbs. top weight. The other numbers refer to the 12.5 lbs. weight plates. Note: The actual resistance at each weight station may vary due to differences in individual weight plates, as well as friction between the cables, pulleys, and weight guides. -
Page 19: Trouble-Shooting And Maintenance
Trouble-shooting and Maintenance Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. Tightening the Cables Woven cable, the type of cable used on the home gym system, can stretch slightly when it is first used. - Page 21 Part ListÑModel No. WESY81081 Key No. Qty. Description Top Frame Long Cable 1Ó Round Cover Cap 1Ó Retainer Stabilizer ÒVÓ-Pulley #8 x 1/2Ó Tap Screw Base Short Cable Curl Post 1Ó x 2Ó Inner Cap Press Frame Seat 5/16Ó x 2 3/4Ó Carriage Bolt...
- Page 22 1/4" Flat Washer (81) 1/4" Nylon Locknut (82) 1" Retainer (4) 1/4" x 1/2" Screw (17) 3/8" x 1 1/2" Bolt (60) 3/8" x 2" Bolt (62) Cable Clip (73) 3/8" x 2 1/4" Bolt 65) #8 x 1/2" Tap Screw (7) 3/8"...
- Page 23 Part Identification ChartÑWESY81081 5/16" Nylon Locknut (53) 5/16" Plain Nut (32) 3/8" Nylon Jam Nut (57) 3/8" Nylon Locknut (63) 1/2" Nylon Locknut (68) 5/16" Flat Washer (56) 3/8" Flat Washer (55) 1/4" x 2" Carriage Bolt (38) 1/4" x 2" Bolt (71) 1/4"...
- Page 24 1" Round Inner Cap (49) 1" Round Cover Cap (3) 3/4" Round Inner Cap (34) 5/16" x 2" Eyebolt (44) 1 1/2" Square Inner Cap (33) 2" Square Outer Cap (51) 1" x 2Ó Inner Cap (11) 2" Square Inner Cap (21)
-
Page 25: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: 1. The MODEL NUMBER of the product (WESY81081). 2. The NAME of the product (WEIDER ¨...
