INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20
Installation Manual
Installation and Appliance Setup
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
Pour demander un exemplaire en français de ce Manuel du
propriétaire, visitez www.heatnglo.com/translations.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo SL-3X-IFT

  • Page 1 Pour demander un exemplaire en français de ce Manuel du See Table of Contents for location of additional Commonwealth of Massachusetts requirements. propriétaire, visitez www.heatnglo.com/translations. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 2: Table Of Contents

    D. Non-Combustible Material ......41  = Contains updated information. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 3: Installation Standard Work Checklist

    Comments Communicated to party responsible ____________________ by ______________________on ___________ (Builder / Gen. Contractor/) (Installer) (Date)  = Contains updated information. 2472-982 Rev. C 4/18 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 4: Product Specific And Important Safety Information

    State of California to cause cancer and SL-9X-IFT reproductive harm. For more information go to: www. 31,000 16,500 (0-2000 FT) (Propane) P65Warnings.ca.gov. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 5: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 6: Getting Started

    1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300 ºF minimum continuous exposure rating) One 1/4 in. female connection (for optional fan). Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 7: Inspect Appliance And Components

    Call a qualified service technician to inspect the appliance and to replace any part of the control system and/or gas control which has been under water. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 8: Framing And Clearances

    18-7/8 15-7/8 15-7/8 15-7/8 15-7/8 6-5/8 6-5/8 6-5/8 6-5/8 2-1/8 2-1/8 2-1/8 2-1/8 30-1/16 33-9/16 35-9/16 9-1/8 9-1/8 9-1/8 9-1/8 Figure 3.1 Appliance Dimensions Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 9 3-1/2 4-9/16 SL-7X-IFT CF-36 38-1/2 24-1/16 42-3/4 28-11/16 30-13/16 3-1/2 4-9/16 SL-9X-IFT CF-42 1086 Figure 3.2 Decorative Front Dimensions - Firescreen and Clean Face Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 10 SL-7X-IFT HAL-36 39-7/16 23-1/8 44-3/16 1-1/8 6-1/4 34-3/4 44-3/8 36-3/8 SL-9X-IFT HAL-42 1002 1122 1127 Figure 3.3 Decorative Front Dimensions - Chateau and Halston Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 11 ARC-36 39-7/16 22-7/16 44-3/16 1-1/4 7-7/16 34-3/4 44-3/8 36-3/8 SL-9X-IFT ARC-42 1002 1122 1127 Figure 3.4 Decorative Front Dimensions - Chateau Forge and Arcadia Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 12 34-3/8 SL-7X-IFT FSI-36 34-3/8 25-3/16 44-3/16 1-1/4 6-3/4 34-13/16 36-1/16 44-3/8 36-3/8 SL-9X-IFT FSI-42 1122 1127 Figure 3.5 Decorative Front Dimensions - Iron Age Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 13: Clearances To Combustibles

    1635 1232 1746 50-1/2 71-1/2 50-1/2 71-1/2 16-1/4 50-1/2 71-1/2 19-1/2 9-1/4 SL-9X-IFT 1283 1245 1816 1283 1816 1283 1816 Figure 3.5 Appliance Locations Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 14 * Adjust framing dimensions for interior sheathing (such as sheetrock) C** Add 12 inches when rear venting with one 90º elbow. Figure 3.6 Clearances to Combustibles Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 15: Constructing The Appliance Chase

    • Failure to maintain airspace may cause overheating and a fire. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 16: Termination Location And Vent Information

    Refer to local codes. H=Measure Horizontal Distances from H V=Measure Vertical Distances from V Figure 4.1 Minimum Height From Roof to Lowest Discharge Opening Figure 4.3 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 17: Vent Terminal Clearances

    12 in. (305 mm)* two sides beneath the floor.) vinyl or composite overhang 42 in. (1067 mm) 42 in. (1067 mm) Figure 4.4 Minimum Clearances for Termination Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 18: Approved Pipe

    WARNING! Risk of Fire or Asphyxiation. This appli- ance requires a separate vent. DO NOT vent to a pipe serving a separate solid fuel burning appliance. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 19: Use Of Elbows

    DVP36 25-1/2 DVP48 1219 DVP6A 3 to 6 76 to 152 2-1/8-4-1/4 54-108 DVP12A 3 to 12 76 to 305 2-1/8-8-1/2 54-216 Figure 4.5 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 20: Measuring Standards

    Figure 4.7 Measure to Outside Mounting Surface Figure 4.9 Flex Vent Pipe - Generic Fireplace Shown Figure 4.8 Measure to Top of Last Section of Pipe Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 21: Vent Diagrams

    See Figure 4.10. 1/4 in. max. (6 mm) Figure 4.10 Vent Cap - Generic Fireplace Shown Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 22 • When using SLP-HRC-SS termination cap on top vented fireplaces, a one foot minimum vertical vent section is required before installing first elbow. Figure 4.11 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 23 • When using SLP-HRC-SS termination cap on top vented fireplaces, a one foot minimum vertical vent section is required before installing first elbow. INSTALLED HORIZONTALLY Figure 4.12 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 24 • When using SLP-HRC-SS termination cap on top vented fireplaces, a one foot minimum vertical vent section is required before installing first elbow. Figure 4.13 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 25 TOP VENT APPLICATION EXHAUST RESTRICTOR REAR VENT APPLICATION EXHAUST RESTRICTOR Figure 4.14 Figure 4.15 Exhaust Restrictor Installation (Top Refractory Panel Removed to Aid in Visual Clarity) Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 26 Note: There MUST be a 25% reduction in total H when using flex vent except when using the simple up and out installation. See Figure 4.9. Figure 4.16 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 27 Maximum = 14 ft. (4.3 m) *No specific restrictions on this value EXCEPT V CANNOT exceed 40 ft. (12.2 m). INSTALLED HORIZONTALLY Figure 4.17 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 28 4 ft. 1.2 m 3-1/2 ft. 1.0 m installation. See Figure 4.9. Maximum= 40 ft. (12.2 m) Note: Use SLP Series components only. Figure 4.18 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 29 90º elbows in a corner installation will affect space re- components only. quirements. See Section 3.B. Use of 45º elbow not allowed. 90-DEGREE ELBOWS Figure 4.20 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 30 2.1 m 14 ft. 4.3 m Maximum = 7-1/2 ft. (2.3 m) Maximum = 14 ft. (4.3 m) = 40 ft. (12.2 m) Figure 4.21 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 31 13-1/2 ft. 4.1 m Maximum = 7-1/2 ft. (2.3 m) Maximum =13-1/2 ft. (4.1 m) = 40 ft. (12.2 m) INSTALLED HORIZONTALLY Figure 4.22 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 32 6-1/2 ft. 2.0 m 3 ft. 914 mm H Maximum = 6-1/2 ft. (2 m) Maximum = 40 ft. (12.2 m) INSTALLED HORIZONTALLY Figure 4.24 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 33 914 mm 7 ft. 2.1 m 14-1/2 ft. 4.4 m Maximum = 7-1/2 ft. (2.3 m) Maximum = 40 ft. (12.2 m) Figure 4.25 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 34 • Ensure all joints are properly engaged and the chimney pilot malfunction, or overheating. is properly secured. Table 2 CLEARANCE TO COMBUSTIBLES REQUIREMENTS DV-46DVA-GCL 3 IN. Exhaust Vent Pipe 5 IN. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 35 0 ft. 0 mm Minimum 10 ft. 3.05 m Maximum 40 ft. 12.2 m 2 ft. 610 mm Maximum 40 ft. 12.2 m Figure 4.28 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 36: Vent Clearances And Framing

    Top: 2-1/2 in. (64 mm) Bottom: 1/2 in. (13 mm) Sides: 1 in. (25 mm) Figure 5.1 Horizontal Venting Clearances To Combustible Materials - Generic Fireplace Shown Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 37: Wall Penetration Framing/Firestops

    Whenever a non-combustible wall is penetrated, the wall shield firestop is only required on one side and no heat Figure 5.2 Wall Penetration shield is necessary. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 38: Ceiling Firestop/Floor Penetration Framing

    INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 5.4 Installing the Attic Shield Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 39: Appliance Preparation

    The heat shield must remain in the vertical position. 2 SCREWS Figure 6.6 Remove the insulation from the outer vent pipe. Figure 6.3 Replace the two screws as shown. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 40 Use two self-tapping screws to secure Figure 6.9 (Generic Fireplace Shown) Cut the metal gasket to outer wrap. retaining band and fold the sides out. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 41: Installing Optional Heat Management Systems

    • Bend out nailing tabs on each side. • Place the appliance into position. Figure 6.15 Facing Materials Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 42: Venting And Chimneys

    Use screws no longer than 1/2 INCORRECT in. (13 mm). If predrilling screw holes, DO NOT penetrate Figure 7.4 Seams inner pipe. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 43: Assemble Slip Sections

    • All unit collar, pipe, slip section, elbow and cap outer Figure 7.5 Adding Venting Components flues shall be sealed. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 44: Secure The Vent Sections

    120º Figure 7.11 Align and Disassemble Vent Sections Figure 7.8 Securing Vertical Pipe Sections 120º Figure 7.9 Securing Horizontal Pipe Sections Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 45: Vertical Termination Requirements

    • Caulk the perimeter of the flashing where it contacts the roof surface. See Figure 7.13. • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 46: Horizontal Termination Requirements

    Figure 7.15 Figure 7.15 Important Notice: Heat shields may not be field constructed. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 47 DVP-TRAP2 can adjust 4 in. (5-3/8 to 9-3/8) DVP-HPC1 can adjust 2-1/8 in. (4-1/4 to 6-3/8) DVP-HPC2 can adjust 4-1/8 in. (6-3/8 to 10-1/2) Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 48: Electrical Information

    Wiring for optional Hearth & Home Technologies approved accessories should be done now to avoid reconstruction. Follow instructions that come with those accessories. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 49 LED CONTROLLER PLACEMENT TABS IFT-ECM REAR PLACEMENT TAB GUIDE GREEN/WHITE/BLACK WIRES GUIDES IFT-ECM FRONT PLACEMENT TAB Figure 8.2. Electrical Component Tray Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 50: Wiring Requirements

    NOT USED FOR SL-3X-IFT, SL-5X-IFT, SL-5XLP-IFT, EMBER LIGHTING SL-7X-IFT, SL-7XLP-IFT, SL-9X-IFT MODELS BLK (GROUND) APPLIANCE 6V DC MODELS. ON/OFF BATTERY PACK CONTROL (OPTIONAL) Figure 8.2 IntelliFire Touch Wiring Diagram Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 51: Gas Information

    4500 feet (1370 m). • If substituting for these components, please consult local codes for compliance. Check with your local gas utility to determine proper orifice size. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 52: Air Shutter Setting

    If flames are dark orange with dark, smoky tips, provide more primary air to the burner by opening the air shutter accordingly. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 53: Burner Identification/Verification

    Notch patterns are located on bottom side of burner. DETAIL A NG /LP SL-3X-IFT SL-5X-IFT SL-7X-IFT SL-9X-IFT Figure 9.2 Burner Identification Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 54: Finishing

    1 IN. 1 IN. 0 IN. 0 IN. HIGH TEMPERATURE (300º F / 149º C MIN.) TOP & SIDE SEAL JOINT Figure 10.1 Facing Materials Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 55: Mantel And Wall Projections

    Figure 10.3 Minimum Vertical and Maximum Horizontal Figure 10.6 Non-Combustible Mantel Legs or Wall Projections Dimensions of Non-Combustibles (Acceptable on both sides of opening) Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 56 3-1/2 IN. MIN. 12 IN. MIN. Figure 10.7 Rear Vent Non-Combustible Zone Above Appliance Figure 10.8 Top Vent Non-Combustible Zone Above Appliance Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 57: Decorative Front Finishing

    Finishing material between 1 and 6 inches thick. Refer to Section 3 for X and Y dimensions. Figure 10.10 Overlap Fit Decorative Front (ARC, CHA, CHAF, HAL, FSI) Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 58: Appliance Setup

    “legs.” See Figure 11.3. Clean/vacuum any sawdust that may have accumulated inside the firebox or underneath in the control cavity. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 59 It is acceptable to remove excess flashing on the left and right hearth components to best align grout lines. Figure 11.7 Right Refractory Panel Installed Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 60 Allow the paint to dry/cure a minimum of 15 minutes. • DO NOT allow paint or paint overspray on the pilot. Figure 11.8 Paint Teco-Sil Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 61 TOP RIGHT LOG TOP RIGHT LOG SL-7X EMBERS BURNER LOG BURNER LOG Figure 3. Log Set Components SL-9X Figure 1. Log Pin and Glowing Ember Locations Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 62 Failure to follow this procedure will likely cause tween the right end of the log and the right refractory lighting and sooting problems. panel See Figure 5. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 63 INDENTATION-LEFT LOG INDENTATION-LEFT LOG Figure 9. Top Right Log Installed - Log Set Complete 2372-935F Figure 7. Location of Left Log indentation Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 64: Intellifire Touch ® Control System Setup

    For more information refer to the instructions supplied with your decorative door or front. Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 65: Reference Materials

    (152 mm) 14 IN. (356 MM) 12 IN. (305 MM) DVP-WS (Wall Shield Firestop) DVP-RDS ROOF DECK INSULATION SHIELD Figure 12.1 DVP Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 66 DVP-TRAP 5-3/8 in. 9-3/8 in. Horizontal Termination Cap Trap2 137 mm 238 mm DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 DVP-HPC1 DVP-HPC2 Figure 12.2 DVP Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 67 (352 mm) (241 mm) 26 in. 660 mm 14 in. (356 mm) DVP-HSM-B DRC-RADIUS Extended Heat Shield Cap Shield Figure 12.3 DVP Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 68 146 to 213 mm 3° 87° 15 in. (381 mm) 10-1/2 in. 267 mm 10-7/8 in. 276 mm DVP-HRC-SS DVP-HRC-ZC-SS Figure 12.4 DVP Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 69 424 mm (424 mm) 12-1/2 IN. SLP-LPC (318 mm) SLP Low Profile Cap (Approved for use with PVI-SLP-B only) Figure 12.5 PVI-SLP-B Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 70 PVI-WH60 80 FT PV Wire Harness PVI-WH80 100 FT PV Wire Harness PVI-WH100 PVLP-HS PVLP-BEK Heat Shield Brick Kit Figure 12.6 PVLP-SLP Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 71 12 in. 5-1/2 in. 220 mm 38 mm 305 mm 146 mm SLP-WS SLP-FS Wall Shield Firestop Ceiling Firestop Figure 12.7 SLP Series Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 72 10-5/8 IN. 59 mm 367 mm (321 mm) (270 mm) SLP-RDS SLP-WT-BK ROOF DECK INSULATION SHIELD Wall Thimble-Black Figure 12.8 SLP Series Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 73 13-1/2 in. 4-3/4 in. 343 mm 121 mm DVP-FBHT Horizontal SLK-SNKD Termination Cap Snorkel (SL-2DVP Adapter Required) Termination Cap Figure 12.9 SLP Series Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 74 Figure 12.10 SLP series Vent Components LINK-DV30B 768-380A DV-46DVA-GCL Flex Liner Kit Stainless Steel Flex Pipe Coaxial/Colinear Appliance Connector DVP-2SL Adapter Figure 12.11 Coaxial to Colinear Vent Components Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
  • Page 75: Accessories

    Please contact your Heat & Glo dealer with any questions or concerns. For the location of your nearest Heat & Glo dealer, please visit www.heatnglo.com. Printed in U.S.A. - Copyright 2020 Heat & Glo • SL-3X-IFT, SL-5X-IFT, SL-7X-IFT, SL-9X-IFT Installation Manual • 2472-980 Rev. Q • 3/20...
