Provisioning
P
ROVISIONING
There are two methods for provisioning:
•
Use the MODE and SEL pushbuttons on the front panel of the H4TU-C to:
—
Set system options
—
Reset the H4TU-C to its factory default settings for system options
—
Display system option settings (scroll mode)
—
Select system loopbacks
•
Use a maintenance terminal (ASCII terminal or a PC running terminal emulation software) connected to the
H4TU-C craft port (or to an HMU craft port) to access the maintenance screens
gives you full access to all H4TU-C status, history, inventory, and provisioning screens.
The MNGD message displays if the H4TU-C-319 is under HMU management. When this occurs,
the front-panel pushbuttons and craft port are disabled.
No dip switches or jumpers are required to provision the H4TU-C-319 as it contains a
non-volatile RAM (NVRAM) which stores the system option settings. System option settings are
retained if shelf power is lost or the H4TU-C-319 is unplugged.
U
MODE
SING THE
Setting Options through MODE and SEL
To provision the H4TU-C-319 through the MODE and SEL pushbuttons on the front panel:
1
Press the MODE pushbutton for 1 second and then release it. The front-panel display alternately shows the
first system parameter and its current setting.
2
Press the SEL pushbutton to step through all possible settings of the selected parameter. (See
page 19
and
Table 6 on page
3
After the desired setting has been selected, press the MODE pushbutton. This updates the current displayed
parameter to the selected setting, then advances to the next configurable parameter. After the last parameter
has been selected, a CONF NO message appears on the front-panel display.
4
Do one of the following:
•
To cancel the session without saving the requested parameter changes, press the MODE pushbutton or
do nothing. (After 30 seconds, the display returns to its normal mode without saving the new changes.)
•
To accept the requested parameter changes, press the SEL pushbutton. (A CONF YES message appears,
and the display returns to its normal mode after saving the new changes.)
10
SEL P
AND
USHBUTTONS
20.)
September 12, 2003
LTPH-UM-1031-03, Issue 3
(Figure 3 on page
13). This
Table 5 on
H4TU-C-319 List 1
