LTPH-TP-1005-02, Issue 2
P
ROVISIONING
There are two provisioning methods:
• Setting the DIP switch located on the H2TU-C-202 circuit card
• Using a maintenance terminal (ASCII terminal or a PC running terminal emulation software) connected to
the H2TU-C craft port (or to an HMU craft port) to access the HiGain maintenance screens
page 10). Using a maintenance terminal allows you full access to all H2TU-C status, history, inventory, and
provisioning screens.
The options set with DIP switch S1
"On-board DIP Switch S1" on page
U M
SING A AINTENANCE

Connecting to a Maintenance Terminal

The craft port on the front panel allows you to connect the H2TU-C-202 to a maintenance terminal (ASCII
terminal or PC running a terminal emulation program). Once connected to a maintenance terminal, you can access
the maintenance, provisioning, and performance screens.
To connect to a maintenance terminal:
1 Connect a standard 9-pin terminal cable to the RS-232 craft port
front panel.
2 Connect the other end of the cable to the serial port on the maintenance terminal.
3 Start a terminal emulation program such as ProComm (emulating a VT100 terminal).
4 Configure the maintenance terminal to the following communication settings:
• 9600 baud
• No parity
• 8 data bits
•
1 stop bit
•
Hardware flow control to OFF
5 If necessary, press

Logon Screen

The HiGain HDSL2 maintenance terminal screens allow you to monitor, provision, and troubleshoot an
H2TU-C-202 system.
To select a menu from the HiGain HDSL2 logon screen
• Type the underlined letter of the menu.
← →
• Use the arrow keys to select a menu, then press
H2TU-C-202 List 3E
(Figure
6.
T
ERMINAL
CTRL + R to refresh the HiGain HDSL2 logon screen.
February 28, 2001
3) cannot be set from a maintenance terminal. See
(Figure 2 on page
(Figure 5 on page 10), do one of the following:
ENTER .

Provisioning

(Figure 5 on
4) on the H2TU-C-202
9
