RC Hinge Cover Trim
W10648975—36" BM
(Right)
W10564251—36" FDBM
(Right)
W10606804—42" FDBM
(Right)
Panel Templates
W10222281—SxS
W10488115—36" BM
W10704869—36" FDBM
W10488118—42" FDBM
W10489178—Grille
Installation Block
W10234156

LOCATION REQUIREMENTS

WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
FC Hinge Cover Trim
W10611107—36" BM (Left)
W10582015—36" FDBM
(Left)
W10606808—42" FDBM
(Left)
Handle Side Door Trim
W10611106—BM (Left)
W10648977—BM (Right
W10606802—FDBM (Right
W10606806—FDBM (Left)
Grille—Bottom / Skirt—
Grille
W10189198 / W10188549—
42" BM
W10189196 / W10188547—
36" BM
IMPORTANT: This refrigerator is designed for indoor,
household use only.
This appliance is intended to be used in household and
similar applications such as:
Staff kitchen areas in shops, offices and other working
environments.
Farm houses and by clients in hotels, motels and
other residential type environments.
Bed and breakfast type environments.
Catering and similar non-retail applications.
NOTE: The refrigerator is intended for use in a location
where the temperature ranges from a minimum of 55°F
(13°C) to a maximum of 110°F (43°C). The preferred room
temperature range for optimum performance, which
reduces electricity usage and provides superior cooling, is
between 60°F (15°C) and 90°F (32°C). It is recommended
that you do not install the refrigerator near a heat source,
such as an oven or radiator.
IMPORTANT:
Observe all governing codes and ordinances.
Floor must support the refrigerator weight, more
than 600 lbs (272 kg), door panels and contents of
the refrigerator. Flooring under refrigerator must be
at same level as the room. Face of cabinetry must be
plumb.
Location should permit door to open fully. See "Door
Swing Dimensions."
Location must permit top grille removal. See
"Opening Dimensions."
OPENING DIMENSIONS
IMPORTANT:
The width of the opening (Width A), from side to side,
must be as specified for your model, for at least
2" (5.08 cm) back from the face of the cabinet.
NOTE: If your opening does not meet this
requirement, you will need to make modifications.
A solid soffit or wall cabinet must be installed 84"
(213.4 cm) above the floor. If the solid soffit is higher
than 84" (213.4 cm) or one is not available, then the
refrigerator must be braced.
If anti-tip boards are needed, they must be attached to
the rear wall studs so that there is 84" (213.4 cm) from the
bottom of the anti-tip board to the floor. See "Install Anti-
Tip Boards" for more information.
NOTES:
A clearance of 1/2" (1.3 cm) must be maintained above
the top grille so that the top grille can be removed.
Do not remove the foam gasket from the top of the
compressor cover unless removal is necessary to fit
the unit under a soffit. Removal of the gasket will
cause loss in cooling efficiency.
7
