EDID and Mute Settings Page

The EDID and Mute Settings
rate for each input and to mute and unmute all or individual outputs. Access the
Mute Settings
the Set and View Ties
Set and View Ties
Refresh
Global Presets
Figure 56.
NOTES:
Select the resolution and refresh rate for an output by using the drop-down box for that
input.
Save the output resolution of the monitor connected to output 1 to one of the User
Assigned locations by clicking the desired User button.
Toggle mute on and off for an output by clicking the
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
page provides a way to set the EDID resolution and refresh
page (see figure 56) by clicking the
page.
EDID and Mute Settings Page
EDID communicates video display information, including native resolution
•
and vertical interval refresh rate requirements, to the input. The input device
then outputs the optimal video format for the output (such as a display)
based on the provided EDID data, ensuring proper video image quality. This
communication takes place over the Display Data Channel (DDC).
On the EDID and Mute Settings page, the EDID data can come from either an
•
active output or be set to a specified value.
EDID and Mute Settings
Mute button for that output.
DMS 1600 and DMS 3600 • HTML Operation
EDID and
link on
99
