EDID Minder
The HDMI and RGBHV input groups feature EDID Minder, which ensures that each input
source reads the EDID of the output display even when the input is not selected. The result
is the video source powers up properly and reliably outputs content when selected.
Depending on the EDID mode selected, the EDID of the connected display is stored in
slot 65 (see
from the internal list or read the display EDID and store it one of four user slots. Whether
stored automatically or manually, the EDID file is written to internal memory for each input.
Automatic Mode
If an output display has never been connected, a default EDID file is placed on the RGB and
HDMI inputs according to the following table:
Input Group
RGBHV
HDMI
When a display is connected to the output, the EDID of the display is read and replaces the
default EDID on each input. The EDID remains even if the display is removed. If a different
display is connected or a user assigned EDID is selected, the previous EDID is overwritten.
User Assigned EDID Mode
Default EDID
1920x1080 @ 60 Hz
1080p @ 60 Hz,
2-Ch PCM audio
on page 16). The user can select an EDID file
MPS 601 • Operation
15
