- Page 1 TECHNICAL MANUAL Ciao Series Entrance panel Art. CA2100P-CA2200P Passion.Technology. Design.
-
Page 2: Table Of Contents
Warning Intended use This Comelit product was designed for use in the creation of audio and video communication systems in residential, commercial or industrial settings and in public buildings or buildings used by the public. Installation All activities connected to the installation of Comelit products must be carried out by qualified technical personnel, with careful observation of the indications provided in the Manuals / Instruction sheets supplied with those products. -
Page 3: Description
Description Ciao Series modular entrance panel with die-cast aluminium front cover and nameplates with white LED backlighting. To be finished with 1/2/4/8 call buttons, available to purchase separately. Featuring a Smart button programming mode. Supplied with a surface-mount installation support. -
Page 4: Art. Ca2200P
Art. CA2200P art. CA9213 art. CA9210 art. CA9211 art. CA9212 1. Call buttons 1 / 2 / 4 / 8 users (available to purchase separately) 2. TM1 button brightness control/switch off trimmer 3. S1 dip switch for button type configuration (1 / 2 / 4 / 8 users) and button module addressing 4. -
Page 5: Technical Features
Technical features Art. CA2100P MAIN FEATURES Type of power supply Power supply voltage 27÷34 Vdc (BUS) Min. absorption (W) 1.7W Max. absorption (W) 7.6W Terminals L L COM DO RTE C NO NC SE+ SE- Removable terminals Microphone electret Loudspeaker 8ohm 0.2W Loudspeaker volume control Brightness control... -
Page 6: Installing Entrance Panel Art. Ca2100P
Installing entrance panel Art. CA2100P 100 mm 28 mm art. CA9213 art. CA9210 art. CA9211 art. CA9212 Changing nameplates... -
Page 7: Installing Entrance Panel Art. Ca2100P With Button Module Art
Installing entrance panel Art. CA2100P with button module Art. CA2200P 100 mm 28 mm art. CA9213 art. CA9210 art. CA9211 art. CA9212... -
Page 8: Ca2200P
The addressing of button modules allows, if a module Art. CA2200P is replaced, just the address of the replaced module Art. CA2200P to be programmed, without having to reprogram all the buttons. 1 2 3 4 1 2 3 4 1 2 3 1 2 3 1 2 3 4... -
Page 9: Connections
Connections 1210/1209 NO C MAX. 4 modules (72 users) with 1210 CA2100P CA2200P +CA921x +CA921x 20 m Max. Local lock-release button. 20 m Max. Active input closed for DOOR OPEN signal Variants Variant for using the external unit relay 230 V NO C CA2100P 12V/24V... -
Page 10: Call Button Addressing
Call button addressing Set the address of the apartment you want to call using the dip switches (see Addressing table). Example: code 1 CA2200P Press the button you want to associate with the call Dip switch Code address set using the dip switches Press the following buttons to assign incremental addresses... - Page 11 If you need to set a NON-progressive address, set the code using the dip switches and press the button you want to associate with the address. Example: code 25...
-
Page 12: Special Programmes
Special programmes example code 208 Set the dip switches for the function you wish to program, see the table. Repeat steps 3 and 4 to program other special functions CODE DIP SWITCHES ON FUNCTIONS Audio messages 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8... -
Page 13: Operating Notes
1,3,6,7,8 C.NC.NO relay activation on actuator command: 2 sec 2,3,6,7,8 C.NC.NO relay activation on actuator command: 4 sec 1,2,3,6,7,8 C.NC.NO relay activation on actuator command: 8 sec Door lock 1,3,5,6,7,8 Door lock time: 2 sec + disabling tone (default) 2,3,5,6,7,8 Door lock time: 4 sec 1,2,3,5,6,7,8 Door lock time: 8 sec... -
Page 14: Addressing Table
Addressing table Dip switch Code 1,2,3,4,5 1,3,4,5,6 1,2,4,5,7 1,4,5,6,7 1,2,3,5,8 1,3,5,6,8 1,2,5,7,8 2,3,4,5,6 3,4,5,7 2,4,5,6,7 4,5,8 2,3,5,6,8 3,5,7,8 1,2,3,4,5,6 1,3,4,5,7 1,2,4,5,6,7 1,4,5,8 1,2,3,5,6,8 1,3,5,7,8 2,3,4,5,7 3,4,5,6,7 2,4,5,8 4,5,6,8 2,3,5,7,8 1,2,6 1,2,3,4,5,7 1,3,4,5,6,7 1,2,4,5,8 1,4,5,6,8 1,2,3,5,7,8 2,3,4,5,6,7 3,4,5,8 2,4,5,6,8 4,5,7,8 1,2,3 1,3,6 1,2,7 1,6,7... - Page 15 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
