Performance Data

8.2 Configurations

8.2 Configurations
Quantity structure in a multi-user system
The performance of the WinCC system depends on the employed hardware and the volume
of process data.
The following configurations were tested as typical scenarios:
Server or redundant server pairs
WinCC clients without their own project 32 clients
WinCC clients with their own project
Configuration example 1
Configuration example 2
1) When the server is also used as an operator station, the number of clients for this server is
reduced to four.
You can find additional information in the WinCC Information System under:
● "Configurations > Multi-User Systems > Typical Configurations"
● "Configurations > Multi-User Systems > Quantity Structures and Performance"
210
Quantity Comment
18 servers WinCC client with its own project:
Access to a maximum of 18 WinCC serv‐
ers or redundant server pairs
The mixed configuration of WinCC serv‐
ers which access other WinCC servers
as clients has not been approved.
Maximum of 64 WinCC clients without
1)
their own project in the WinCC system
32 clients Maximum of 50 WinCC clients without
1)
their own project in the WinCC system
32 clients WinCC clients with their own project
+ 3 Web clients
1 client WinCC client with its own project
+ 150 Web clients
