- Page 1 The power behind competitiveness Delta InfraSuite EMS Environmental Management System EnviroStation User Manual www.deltapowersolutions.com...
- Page 2 Failure to heed these instructions and warnings will void the warranty. Copyright © 2013 by Delta Electronics Inc. All Rights Reserved. All rights of this User Manual (“Manual”), including but not limited to the contents, information, and figures are solely owned and reserved by Delta Electronics Inc.
-
Page 3: Table Of Contents
Table of Contents Table of Contents CHAPTER 1 : IMPORTANT SAFETY INSTRUCTIONS ..........1 1.1..................1 AFETY ARNINGS 1.2..................1 SAGE ARNINGS 1.3................2 TANDARD OMPLIANCE CHAPTER 2 : INTRODUCTION................3 2.1................. 3 RODUCT ESCRIPTION 2.2....................3 EATURES 2.3..................5 ACKAGE ONTENTS 2.4. - Page 4 ....................34 ONITOR 5.1.1. Information ..................34 Status ......................34 Delta Bus .......................35 RS485 ......................35 PDU .......................36 IPMI.......................36 5.1.2. History....................37 Event Log.......................37 Energy Log.....................38 Energy Compare....................39 Data Log ......................39 Configuration ....................40 5.1.3. About ....................41 Information ....................41 ......................42...
- Page 5 Table of Contents ....................... 55 YSTEM 5.3.1. Administration................... 55 User Manager ....................55 TCP/ IP ......................56 Web.......................57 Console ......................59 FTP ........................60 Time Server....................60 Syslog ......................61 Batch Configuration ..................62 Upgrade......................63 5.3.2. Notification ..................64 SNMP Access ....................64 SNMPv3 USM ....................65 ...
-
Page 6: Chapter 1 : Important Safety Instructions
Do not attempt to fix/ replace internal components. When repair is needed, refer all servicing to the nearest Delta service center or authorized distributor. Do not allow any objects or liquids of any kind to penetrate the unit. -
Page 7: Standard Compliance
Chapter 1 : Important Safety Instructions 1.3. Standard Compliance Network IPv6 Phase-2 Application ID: TW-2-C-20100323-000158 CE EN55022 (CISPR 22) Class A EN55024 IEC 61000-4-2 (ESD Test) Level 3 @ Air 8 KV/ Contact 4 KV IEC 61000-4-3 (RS Test) Level 2 @ 3 V/m ... -
Page 8: Chapter 2 : Introduction
Chapter 2 : Introduction 2.1. Product Description The EnviroStation monitors and controls environmental conditions through peripheral devices to ensure that your equipment is protected from critical conditions such as high temperature, humidity or water leakage. This rack-mountable product works seamlessly with temperature and humidity sensor EnviroProbes (optional) and other environment monitoring devices. - Page 9 Chapter 2 : Introduction Network connection through RJ45 connector Direct network connection through an RJ45 cable offers immediate configuration via your local network environment with comprehensive management capabilities networking security. Compatibility with SNMP (Simple Network Management Protocol), HTTP and HTTPS Works with universal protocols including SNMP, HTTP and HTTPS.
-
Page 10: Package Contents
Signal Flow The following figure explains how EnviroStation monitors and processes signals. 2.3. Package Contents Please carefully verify EnviroStation and the included accessories. Contact your dealer if any item is missing or damaged. Should you return the items for any reason, ensure that they are carefully repacked using the original packing materials that came with the unit. - Page 11 Chapter 2 : Introduction Item Quantity ❶ EnviroStation 1 PC ❷ Manual and software CD 1 PC Sensor HUB adapter 8 PCS ❸ Terminal block (for Sensor HUB adapter) 8 PCS ❹ Alarm Beacon 1 PC ❺ Bracket ear (including cage nuts and screws) 1 SET ❻...
-
Page 12: Interface
2.4. Interface The LED indicators and connectors on the front and rear panel are shown as follows. For their functions and indications, please refer to the table below. Front panel: Rear panel: No. Item Description ❶ Power Indicates whether the unit is connected to a power source. ... - Page 13 Chapter 2 : Introduction No. Item Description Off: The Digital Input is defined as ‘None’ or ‘Information’. ❻ Sensor On (yellow): The Sensor HUB is activated and defined as ‘Warning’ or ‘Alarm’. LEDs Off: The Sensor HUB is defined as ‘None’ or ‘Information’. ❼...
- Page 14 No. Item Description Delta- Provides power (12Vdc) and connects to EnviroProbe(s) using a standard CAT5 cable with straight-through wiring. Sensor Connects and provides power (12/ 24Vdc) to general sensor devices using standard CAT5 cables with straight-through wiring. Digital Input Four input contact devices can be connected to EnviroStation.
-
Page 15: Chapter 3 : Installation
Chapter 3 : Installation Chapter 3 : Installation In this chapter, you will learn the installation procedures for the EnviroStation, EnviroProbes, Alarm Beacon, and devices connecting via RS485, Sensor HUB, Digital Inputs, Analog Inputs and Relay Outputs. 3.1. Rack-mount Installation Step 1 Choose a location in the rack. -
Page 16: Rs485
Step 4 Connect the AC power cable from the rear panel to an unoccupied power outlet. This will automatically power up the EnviroStation. WARNING: Before connecting the EnviroStation to a power source, make sure that the power source is rated between 100-240V and is well grounded. 3.2. -
Page 17: Enviroprobe
Attach the EnviroProbe(s) to rack cabinet doors or metal plates. Step 5 Use a standard CAT5 cable to connect the first (nearest) EnviroProbe’s Input to the Delta-BUS port on the rear panel. Step 6 Cascade other EnviroProbes using standard CAT5 cables. Connect the Output port to the next EnviroProbe’s Input port. -
Page 18: Digital Input
WARNING: Under no circumstance should you connect the EnviroProbe’s Input port to another one’s Input port. This may cause unrecoverable malfunction to your EnviroProbes. Please be careful and always make sure that you are connecting the correct ports before you plug in. 3.4. -
Page 19: Sensor Hub
Chapter 3 : Installation Dry Contact : Normal Open [NO] or Normal Close [NC]. Wet Contact: Active rating 5~24Vdc, 1~9mA. 3.5. Sensor HUB In the accessory box you can find eight provided Sensor HUB adapters (RJ45 to 6-pin terminal connector) which are used to connect peripheral devices for purposes such as smoke, fire and door contact detection. - Page 20 Connect a Sensor HUB adapter to a Sensor HUB port on the rear panel with a standard CAT5 cable. On the other side of the adapter, plug a 6-pin terminal block (provided with the package) into the green terminal connector so wires from peripheral devices can be tightened and fixed with the screws.
-
Page 21: Analog Input
Chapter 3 : Installation 3.6. Analog Input The EnviroStation provides four Analog Inputs, which are generally used to connect sensor devices that monitor the environment by observing voltage or current fluctuations. The Analog Input 1 and 2 can be connected to a voltage (0~10Vdc) or current (0~20mA) source. -
Page 22: Relay Output
3.7. Relay Output EnviroStation provides two Relay Outputs which can be used in cooperation with Digital/ Analog Input devices to take appropriate actions when events are reported. The power rating is 26Vdc, 0.8A. Please see the following illustrations for the terminal configurations: 3.8. -
Page 23: Pdu Installation
Chapter 3 : Installation Step 4 Place the Alarm Beacon in a visible location. 3.9. PDU Installation Step 1 The EnviroStation can connect with up to 16 PDU devices (different models are allowed). If you wish to cascade PDU devices, please set a unique ID No. - Page 24 Step 2 Use the provided RJ45-DB9 cable to connect the EnviroStation and your PDU. Connect the RJ45 to the EnviroStation’s console port and connect the DB9 to the PDU’s RS232-2 port. If you need to cascade several PDU devices, please use the RS232 cables provided in your PDU devices. Please refer to the figure below.
-
Page 25: Chapter 4 : System Configurations
Chapter 4 : System Configurations Chapter 4 : System Configurations There are different ways you can configure your EnviroStation. If a network conne- ction is available at your location, the following methods can be used: Web-based interface: The InsightPower SNMP IPv6 for EnviroStation Web offers comprehensive system management and monitoring. - Page 26 NOTE: If you have previously changed the EnviroStation’s Host Name or IP address, connect with the new settings. Step 2 Log in as Administrator (default account/ password: admin/ password, case sensitive). Step 3 Specify your preferred display language (default: English) from the dropdown menu on the top right of the page.
-
Page 27: Configuring With Ezsetting
Chapter 4 : System Configurations 4.2. Configuring with EzSetting Included in the provided CD, the EzSetting (compatible with Windows 2000/ 2003/ 2008/ XP/ Vista/ 7) allows you to easily configure your EnviroStation and upgrade firmware on your SNMP devices. Follow the instructions below: Step 1 Use the provided standard CAT5 cable to connect the 10/ 100 Base-T network port from EnviroStation's rear panel to the network. - Page 28 Step 5 Select the SNMP device that you want to modify from the Device List. Click Modify and enter account and password (default: admin/ password, case sensitive). Step 6 Click Configuration to configure network settings. NOTE: Refer to Chapter 5: InsightPower SNMP IPv6 for EnviroStation Web for complete configurations.
-
Page 29: Configuring Via Telnet
Chapter 4 : System Configurations 4.3. Configuring via Telnet Step 1 Use the provided standard CAT5 cable to connect the 10/ 100 Base-T network port from the rear panel to the network. Step 2 Connect the workstation (Windows or Linux) to the LAN that the EnviroStation is connected to. - Page 30 NOTE: Microsoft has removed HyperTerminal from Windows Vista and later versions. If your operation system does not include the program, a free alternative Telnet/ SSH client PuTTy can be downloaded from http://www.putty.org. Step 3 Enter a name, choose an icon for the connection and click OK. From the dropdown menu connect using, select the COM port that is connected to the EnviroStation.
-
Page 31: Configuring Via Text Mode
Chapter 4 : System Configurations Step 5 Click OK to continue. HyperTerminal will automatically connect to the EnviroStation. If it does not connect, click the telephone icon from the tool bar. When connection is established, log in with account/ password. (Default: admin/ password, case sensitive). - Page 32 User Manager No Item Description Default RADIUS Auth Specify whether RADIUS login is Disable allowed. Server The RADIUS server name. Secret The RADIUS secret. Port The RADIUS port number. 1812 Administrator Account The default account/ password admin for the Administrator (case Administrator password sensitive).
- Page 33 Chapter 4 : System Configurations No Item Description Default Device Manager The default account/ password device Account (case sensitive) for the Device Manager who is only permitted to Device Manager password change device-related settings. Password Device Limitation Restrict login area of the Device Only in This Manager.
- Page 34 No. Item Description Default IPv4 Address The IPv4 address. 192.168.001.100 IPv4 Subnet The IPv4 subnet mask setting. 255.255.255.000 Mask IPv4 Gateway IP The IPv4 network gateway. 192.168.001.254 IPv4 DNS or IPv4 Domain Name Server or 192.168.001.001 WINS IP WINS IP. DHCPv4 Client Enable/ disable DHCPv4 Enable...
- Page 35 Chapter 4 : System Configurations Network Parameter No. Item Description Default HTTP Server Enable/ disable HTTP protocol. Enable HTTPS Server Enable/ disable HTTPS protocol. Enable Telnet Server Enable/ disable Telnet protocol. Enable SSH/ SFTP Enable/ disable SSH/ SFTP protocol. Enable Server FTP Server...
- Page 36 No. Item Description Default Telnet Server Port Telnet networking port. SSH Server Port SSH networking port. FTP Server Port FTP networking port. Syslog Server 1 The remote syslog Host Name. Syslog Server 2 The remote syslog Host Name. Syslog Server 3 The remote syslog Host Name.
- Page 37 Chapter 4 : System Configurations No. Item Description Default Time Selection SNTP or manual. SNTP Time Zone Select the time zone. +0 hr 1st Time Server The first time server for SNTP. POOL.NTP.ORG 2nd Time Server The second time server for SNTP.
-
Page 38: Chapter 5 : Insightpower Snmp Ipv6 For Envirostation Web
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web To configure EnviroStation via the InsightPower SNMP IPv6 for EnviroStation Web, please follow the steps below: Step 1 Make sure that your EnviroStation is connected to the LAN. Use a standard CAT5 cable to connect the EnviroStation’s 10/ 100 Base-T Network Port on the rear panel to your network. -
Page 39: Monitor
5.1 Monitor 5.1.1. Information This includes the information of System Status, Sensor HUB, Digital Input, Analog Input, Relay Output, Delta Bus, RS485, PDU and IPMI status. Status This page presents a status overview of connected devices. The values will be updated automatically. -
Page 40: Delta Bus
Delta Bus Go to Device → Information → Delta Bus to view the status of cascaded EnviroProbes. To add or remove Delta Bus devices, click Configuration on the bottom right corner, or go to Management → Delta Bus. RS485 To check RS485 device parameters, go to Information →... -
Page 41: Pdu
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web PDU Go to Information → PDU to look up a specific PDU’s ID No., model No., serial No., hardware version, firmware version, and relevant readings, such as load, frequency, watt & kWh, etc. You can also click the Data Log and Energy Log buttons (if your web page shows the two buttons) to view more relevant readings. -
Page 42: History
5.1.2. History Event Log This table lists all occurred event. The existing ones are overwritten when the maximum number of entries (1,000) is reached. You can also download the entire event log archive (event_log.xls) recorded during an assigned period of time on your computer. -
Page 43: Energy Log
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web Energy Log Go to Monitor → History → Energy Log to look up selected PDUs’ energy logs. You can set up a specific time, click the Display Detail Data button to view detailed records and click the Download button to download the energy logs. -
Page 44: Energy Compare
Energy Compare Go to Monitor → History → Energy Compare to see any selected two PDUs’ energy compare table. Choose any two PDUs’ ID No., select a specific time, click the Apply button, and an energy compare table appears. You can click the Display Detail Data button to view detailed comparison records and click the Download button to download comparison logs. -
Page 45: Configuration
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web Configuration Go to Monitor → History → Configuration to clear the event log, energy log, energy compare log, and data log. You can also assign Save Data Interval and Save Energy Interval. ... -
Page 46: About
5.1.3. About Information Go to Monitor → About → Information to see the version of your InsightPower SNMP IPv6 for EnviroStation and other information about OpenSSL toolkit and license. InfraSuite EnviroStation... -
Page 47: Device
5.2 Device 5.2.1. Management The InsightPower SNMP IPv6 for EnviroStation Web allows detailed configurations for Sensor HUB, Digital Input, Analog Input, Relay Output, Delta Bus, RS485, Protocol, PDU, IPMI Device, IPMI Template and Reaction. Sensor HUB NO/ NC: Stands for Normal Open and Normal Close. If Normal Open is selected, an event is triggered when 1. -
Page 48: Digital Input
Event Type: Allows you to individually determine sensor alarm levels. Reactions will only be triggered when Warning or Alarm is selected. Title: You can entitle devices for identification. Power Configuration: If Normal Open is selected, the EnviroStation supplies 12Vdc or 24Vdc power to Sensor HUB. -
Page 49: Analog Input
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web Analog Input Formula: AI (Analog Input) 1 and AI2 are designed for general Analog In-puts, each can be connected to a voltage (0~10Vdc) or current (0~20mA) source. EnviroStation translates the ADC (Analog-to-digital converter) values according to the following formula: (ADC-a)*b/c-d. -
Page 50: Relay Output
The EnviroStation communicates with EnviroProbes through the Delta Bus. There are three types of EnviroProbes, (1) EnviroProbe (EMS1000), (2) EnviroProbe 1100 (EMS1100) and (3) EnviroProbe 1200 (EMS1200). The Delta Bus page varies according to different types of EnviroProbes. Please see below: ... - Page 51 Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web For EnviroProbe 1100 (EMS1100) The EnviroProbe 1100 (EMS1100) provides four digital outputs. In this page, select an ID first and then set up Title and Type. Click Enable if you wish to enable the device.
- Page 52 For EnviroProbe 1200 (EMS1200) The EnviroProbe 1200 (EMS1200) provides two analog inputs, one analog output and one water-leakage detection. In this page, select an ID first and then set up Title and Type. Click Enable if you wish to enable the device. Please note that the ID means the ID No.
-
Page 53: Rs485
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web RS485 There are two RS485 ports on the rear panel, each port can be configured with a different baud rate, data bits, parity and stop bit. EnviroStation communicates with up to 16 Modbus devices in an RS485 port. You can individually select protocol for each Modbus device from the dropdown menu. -
Page 54: Protocol
Protocol In this page, you can add, modify or delete protocols. You can also export or import protocols from files for backup purposes. Each protocol contains 32 values and 32 statuses. InfraSuite EnviroStation... -
Page 55: Pdu
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web PDU After you check the PDU Enable box to enable monitoring PDU feature, please use the provided RJ45-DB9 cable to connect the EnviroStation and your PDU. Connect the RJ45 to the EnviroStation’s console port and connect the DB9 to the PDU’s RS232-2 port. - Page 56 Device scan result will appear after the scan process is done. You can add a device that you would like to monitor if you check the Add box, give a device name, specify its template, and then click the Add button. InfraSuite EnviroStation...
-
Page 57: Ipmi Template
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web IPMI Template You can add and delete an IPMI template in this page. You can also modify the IPMI template to decide how many sensors that you want to monitor. ... - Page 58 Template A new template will be shown on the template list after you click the New button. All sensors belonged to the new template are disabled (default). You can enable a specific sensor by checking its Enable box. You can also enable several sensors that you like and group them into a new template by giving a new template name in the Template Name column.
-
Page 59: Reaction
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web Reaction User can add (click +), modify and delete (click -) reaction items in this page. Click Edit to setup Reaction Rule. EnviroStation supports up to 64 reaction items. Reaction Rule includes settings of Weekday, Time, Condition and Output. When each situation/ condition is met, corresponding outputs will be enabled. -
Page 60: System
5.3 System 5.3.1. Administration User Manager The EnviroStation supports RADIUS. Check the Use RADIUS box, key in required information including Server, Secret and Port (default: 1812) and click submit to enable RADIUS. You can define service types for Administrator, De-vice Manager and Read Only User. -
Page 61: Tcp/ Ip
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web TCP/ IP Set IPv4 and IPv6 addresses and fill in system information in this page. Please refer to the descriptions below. IPv4 (TCP/ IP Settings for IPv4) 1) DHCP Client: Enable/ disable DHCP. If enabled, DHCP server automatically assigns an IP address to the EnviroStation. -
Page 62: Web
IPv6 (TCP/ IP Settings for IPv6) DHCP Client: Enable/ disable DHCP. If enabled, DHCP server automatically assigns an IP address to the EnviroStation. 2) IP Address: The IPv6 address. 3) Prefix Length: The prefix length for the IPv6 address. 4) Gateway V6IP: The IP address for the IPv6 network gateway. - Page 63 Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web HTTP: Enable/ disable HTTP connection. HTTPS: Enable/ disable HTTPS connection. HTTP Port: Assign an HTTP port number (default: 80). HTTPS Port: Assign an HTTPS port number (default: 443). Web Refresh Period: Web refresh update interval. ...
-
Page 64: Console
Console This page allows you to enable or disable Telnet/ SSH communication protocols and replace DSA/ RSA keys. Telnet: Enable/ disable Telnet connection. SSH/ SFTP: Enable/ disable SSH/ SFTP connection. Telnet Port: Assign a Telnet port number (default: 23). ... -
Page 65: Ftp
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web FTP This allows you to enable/ disable FTP communication Protocol. FTP: Enable/ disable FTP connection. FTP Port: Assign an FTP port number (default: 21). Time Server You can manually set the time and date, or enable automatic time synchronization with SNTP servers. -
Page 66: Syslog
Simple Network Time Server 1) Time Zone: From the dropdown menu, select the time zone for the location where the EnviroStation is located. 2) Primary/ Secondary Time Server: Two time servers can be added. Every 60 minutes, the EnviroStation synchronizes with the first responding server. -
Page 67: Batch Configuration
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web Batch Configuration The EnviroStation provides batch configuration to allow quick and effortless setup on multiple EnviroStations and SNMP devices. You can duplicate settings by exporting configuration files from the devices that you have successfully configured, and import the configuration files on other devices. -
Page 68: Upgrade
SNMP Configuration The SNMP Configuration includes settings in the Notification tab. To download a configuration file, simply click Download. To upload a configuration file, click Choose File, select the file you wish to upload, and click Upload. NOTE: If you need to modify the command lines, please do not delete the unmodified ones. -
Page 69: Notification
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web 5.3.2. Notification SNMP Access The EnviroStation supports SNMP protocol and SNMP NMS (Network Management System), which are commonly used to monitor network devices for conditions that call for administrative attention. To prevent unauthorized access, you can specify the NMS IP addresses that are allowed to access with their respective Community Strings and access levels. -
Page 70: Snmpv3 Usm
SNMPv3 USM SNMPv3 offers features such as the encryption of packets and authentication to improve security. The SNMPv3 USM (User Session Management) allows you to assign eight User Names whose access is granted via SNMPv3 protocol. You can also define their respective Security Levels, Auth Passwords, Priv Passwords and Access Level. -
Page 71: Mail Server
Chapter 5 : InsightPower SNMP IPv6 for EnviroStation Web Information: All event notifications are sent to the target address. Warning: Both Warning and Alarm event notifications are sent to the target address. Alarm: Only Alarm event notifications are sent to the target address. ... - Page 72 SMTP Server Name or IP: If a Host Name is entered, a DNS IP should be added in TCP/ IP. Please see 5.3.1 Administration – TCP/ IP. Account: The mail server login account. Password: The mail server login password. ...
-
Page 73: Chapter 6 : Snmp Device Firmware Upgrade
Chapter 6 : SNMP Device Firmware Upgrade Chapter 6 : SNMP Device Firmware Upgrade With the provided program EzSetting, you can effortlessly perform a firmware upgrade for SNMP devices via LAN. Please refer to the following instructions. Step 1 The subnet mask allows you to refine the device discovery range in the specified subnets. - Page 74 Step 3 Select a device from the Device List, click Modify, and key in Administrator account and password. Step 4 Click Upgrade. The upgrade dialog box pops up. Click Browse to select a valid firmware binary file. Verify the firmware version listed under File Information, and then click Upgrade Now to continue.
- Page 75 Chapter 6 : SNMP Device Firmware Upgrade Step 5 The upgrade process should take about 20 seconds. Step 6 When the upgrade is completed, the following dialog box appears. It takes about 1 minute for the device to reboot.
-
Page 76: Chapter 7 : Troubleshooting
Chapter 7 : Troubleshooting Q1. How to set up an SNTP server on my workstation for EnviroStation to synchronize? To enable SNTP services in Windows XP, go to Start → Control Panel → Add/ Remove Programs → Add/ Remove Windows Components → Networking Services →... - Page 77 Chapter 7 : Troubleshooting Q4. Unable to connect the EnviroStation via its Host name? If you assign a new static IP address to the EnviroStation, you may need to re-fresh the NetBIOS table so that it corresponds with the new one. Although Windows updates its NetBIOS table periodically, you can still manually force it to refresh by entering the following command nbtstat –R in DOS prompt mode or shell.
- Page 78 Q6. Unable to ping the EnviroStation from my workstation? If the EnviroStation is non-responsive, check the following: 1) If the green LED indicator on the EnviroStation is OFF, check if the network cable is correctly connected from the EnviroStation to the router or hub.
- Page 79 Chapter 7 : Troubleshooting Q10. Forgot Administrator’s account and password? You can reset Administrator’s account and password via text mode. Refer to 4.4 Configuring through COM Port to establish a COM port connection with the EnviroStation. When the login information is prompted, key in rstadmin within 30 seconds and press enter.
- Page 80 2) Launch shell and enter the following command to create your own keys: Please ignore it when prompted to provide passphrase. DSA Key:ssh-keygen –t dsa RSA Key:ssh-keygen –t rsa 3) Upload DSA and RSA key files on the InsightPower SNMP IPv6 for EnviroStation Web.
- Page 81 Chapter 7 : Troubleshooting 5) Select SSH-2 DSA from the Parameters area and select Key → Generate key pair to generate a DSA key. 6) Select Export OpenSSH Key from Conversions and assign a file name to the DSA key. Please ignore it when prompted to provide key passphrase. 7) Copy the generated key from the text box, paste in a text editor and save as a text file.
- Page 82 snmpwalk -v 3 -u <user> -l authPriv -A <password> -X <pass-word> -n <context name> -t 3 <ip> 1.3.6.1.2.1.1.1.0 -v：1 for SNMPv1, 3 for SNMPv3. -l： Follow the security levels. They are: noAuthNoPriv, authNoPriv and authPriv. -u：The user name which is assigned from SNMPv3 USM table. -A：The Auth Password which is assigned from SNMPv3 USM table.
-
Page 83: Appendix A : Specifications
RJ45 jack connector Output + 12V, 0.8A (max) Sensor HUB + 24V, 1.0A (max) One port limit 0.6A Delta Bus + 12V, 0.8A (max) Relay Outputs 26 Vdc (max), 0.8A (max) Physical Size (W x D x H) 440 x 157 x 44 mm Weight 2.4 kg... -
Page 84: Appendix B : Warranty
Appendix B : Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship within the warranty period. If the product has any failure problem within the warranty period, Seller will repair or replace the product at its sole discretion according to the failure situation.
