Installation Preparation (Remote With Dongle); Connect The Dongle To The Control Head - Humminbird AS RC Operation Manual

I
NSTALLATION
Prior to installing the dongle on the boat, test the wireless remote and dongle to confirm connection
and operation. This section is applicable to all control heads without built-in Bluetooth technology.
Purchase Connection Accessories
Depending on your Humminbird control head model and network configuration, you may need to
purchase additional accessories and/or extension cables. See the table below for the required
cable(s) for your configuration.
NOTE: To purchase accessories or any additional equipment for your control head
configuration, visit our Web site at humminbird.com or contact Humminbird
Customer Service at 1-800-633-1468.
NOTE: Extension cables may affect performance.
Hardware
ONIX

1 | Connect the Dongle to the Control Head

Refer to your control head installation guide for more information about connecting cables.
NOTE: Confirm all control heads are powered off before proceeding with the
installation.
NOTE: The connectors are keyed to prevent incorrect installation, so be careful not
to force the connectors into the ports.
NOTE: Extension cables may affect performance.
ONIX
1. Connect the AS GPS NMEA cable connector to the cable connector on the dongle cable.
2. Connect the AS GPS NMEA cable connector to the NMEA 0183 (1-2) port on the back of the
control head.
3. Hand-tighten the screw nut to secure the connection.
P
REPARATION (R
Required Cables
(1) AS GPS NMEA
D
EMOTE WITH
8
)
ONGLE
Installation Preparation
