2 | Attach the Lanyard

Use the following instructions to attach the lanyard to the wireless remote.
1. Attach the Lanyard Connector to the Remote
1. Insert the loop on the lanyard connector through
the opening on the bottom of the remote.
2. Pull the lanyard connector through the loop to
secure the lanyard connector to the remote. See the
illustration Installing the Lanyard Connector on the
Remote.
2. Connect the Lanyard
1. Insert the clip on the lanyard into the lanyard
connector until you hear it click into place.
Disconnect the Lanyard
1. Pinch the sides of the lanyard clip, then gently pull
the lanyard clip out of the lanyard connector.
Wireless Remote Setup
Connector on the Remote
connector
Disconnecting the Lanyard
7
Installing the Lanyard
lanyard
lanyard loop
Connecting the Lanyard
lanyard
lanyard clip
lanyard connector
pinch sides of lanyard
clip to release it from
the lanyard connector
