[F102] HDD start error
[F103] HDD transfer time-out
[F104] HDD data error
[F105] HDD other error
Classification
Other service call
Check item
HDD
Replacement part
HDD
SYS board
[F106_0] ADI-HDD error: Illegal disk replacement detected (ADI-HDD Exchange to SATA-HDD)
Classification
Other service call
Check item
Setting
© 2013-2016 TOSHIBA TEC CORPORATION All rights reserved
HDD start error: HDD cannot become "Ready" state.
HDD transfer time-out: Reading/writing cannot be performed in
the specified period of time.
HDD data error: Abnormality is detected in the data of HDD.

HDD other error

• Connector and harness check
• Check if the connector pins of the HDD are bent.
• Perform the bad sector check (08-9072). If the check
result is OK, recover the data in the HDD. If the check
result is failed, replace the HDD.
ADI-HDD error: The ADI-HDD has been replaced illegally to
SATA-HDD (normal type).
Check if the HDD has been replaced with a SATA-HDD
(normal type).
1. Start the equipment in the 4C mode: [4] + [C] +
[POWER]
2. Check the type of the HDD shown on the top left of the
control panel display "Current HDD type".
2a. In case of "SATA-HDD" (normal type), replace it with
the original ADI-HDD or a new ADI-HDD.
Notes:
To replace with the original ADI-HDD, start the
equipment in the normal mode and then reinstall
system software only if any abnormality occurs.
2b. In case of "ADI-HDD"
Check each item in the Measures field for the HDD
below.
If the error still occurs, reinstall the system software.
5 - 55
Contents
Measures
Measure
Error item
Measures
e-STUDIO477S/527S/477SL
ERROR CODE AND TROUBLESHOOTING
5
