DT4572 X-Band Down Converter
System Operation
3.3.7 U F
TILITY UNCTION
The local operator can input commands to the following Utility Functions which are
displayed on the LCD display:
TIME. Military time is used in hours, minutes and seconds.
DATE. The date is displayed in month, day and year.
Serial MODE (communications link).
EIA-485 or EIA-232C.
Physical Address. The default address starts from 001.
BAUD (Rate). The default baud rate is 9600.
PARITY. Even, Odd or None.
Display Controls.
DISPLAY CONTRAST. The default is 15, with values from 0 - 30.
DISPLAY BRIGHTNESS. The default is 15, with values from 0 - 30.
REF Adjust.
REFERENCE FREQUENCY ADJUSTMENT. The default tuning adjustment is 87, with
values from 0 – 255
M
ENU
29
Rev. 0
MM/DT4572.IOM
