Buzzer operation and distance to an obstacle
A beep sounds when the corner sensors and center sensors are
operating.
● The buzzer beeps faster as the vehicle approaches an obstacle.
When the vehicle comes within the following distance of the
obstacle, the buzzer sounds continuously.
• Front corner sensors: Approximately 35 cm (1.1 ft.)
• Front center sensors: Approximately 30 cm (1.0 ft.)
• Rear corner sensors: Approximately 25 cm (0.8 ft.)
• Rear center sensors: Approximately 40 cm (1.3 ft.)
● When 2 or more obstacles are detected simultaneously, the
buzzer system responds to the nearest obstacle.
■
Sensors that operate
4 sensor type
2-4. Using other driving systems
2
265
