AutoPilot Overview

You can start AutoPilot navigation based on the motor heading or the cursor position. Also, AutoPilot can be used with Cruise Control
and while recording an iTrack. If another mode of navigation that controls steering is enabled while AutoPilot is enabled, AutoPilot
will disable automatically.
WARNING! It is the operator's responsibility to make prudent decisions regarding personal safety and the operation of the vessel.
Do NOT leave the autopilot unattended while it is steering the vessel. Watch for obstacles and potential hazards at all times. Be
prepared to respond to changing conditions and take manual control of the vessel as required.
WARNING! Do NOT use the autopilot where there may be shallow water, obstacles, or when manual navigation is required,
especially in the following situations:
• while navigating or maneuvering in shallow waters or dangerous seabeds,
• while entering or exiting harbor, mooring, or setting sail,
• while traveling at high speed,
• in heavy traffic areas, near breakwaters, canals,
• or while encountering any potential obstacles.
WARNING! Watch for a turning propeller and be prepared for boat movement when working with AutoPilot. If Prop Auto On is
turned on, the propeller will automatically turn on when AutoPilot is engaged, even if the engagement is accidental. A turning
propeller can cause injury. If the boat does not move, confirm the prop is turned on in the menu system (see Propeller Controls).
WARNING! To cancel AutoPilot navigation, you must select Cancel Navigation and then turn the propeller off. The propeller does
not automatically turn off when navigation is canceled. See Cancel Navigation and Propeller Controls for more details.
CAUTION! The i-Pilot Link uses a magnetic compass to detect direction of travel. The compass can be adversely affected by
magnets or large, ferrous metal objects near (within 24" of) the trolling motor control head.
Obstructions on the propeller may cause excessive vibration of the motor head. This vibration can cause the compass to wander
and erratic steering to occur. Clear the obstruction to return the motor to normal operation. See the i-Pilot Link Owner's Manual
for details.
NOTE: When AutoPilot is on and the trolling motor is pulled out of the water to the stow position, the steering motor will continue
to run. Turn off AutoPilot to stop the motor. If AutoPilot is left on, the steering motor will shut off automatically after 8 seconds.
The motor should not be stored in this condition for long periods as power is still being applied to all electronics. Always turn
AutoPilot off and disconnect your motor from the battery when storing your motor. See the i-Pilot Link Owner's Manual for
details.

Start AutoPilot Navigation

You can start AutoPilot navigation based on the motor heading or the cursor position.
CAUTION! Be prepared for boat movement as the prop will automatically be enabled and the prop speed will automatically adjust
to move the boat to the waypoint position. If the boat does not move, confirm the prop is turned on in the menu system (see
Propeller Controls).

Select the AutoPilot Mode

1. Main Menu: Press the MENU key twice. Select the Accessories tab.
2. Select i-Pilot Settings. Press the RIGHT Cursor key.
3. Select AutoPilot Mode.
4. Select Legacy or Advanced.
