Chapter 24 Managing Network Security with ACLs
Beginning in privileged EXEC mode, follow these steps to restrict incoming and outgoing connections
between a virtual terminal line and the addresses in an ACL:
Command
Step 1 configure terminal
Step 2
line [console | vty] line-number
Step 3 access-class access-list-number
{in | out}
Step 4 end
Step 5 show running-config
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
To remove an ACL from a terminal line, use the no access-class access-list-number {in | out} line
configuration command.

Applying an IPv4 ACL to a Management VLAN

Note This section describes how to apply IPv4 ACLs to a management VLAN. By default, the router sends
Internet Control Message Protocol (ICMP) unreachable messages when a packet is denied by an access
group. These access-group denied packets are not dropped in hardware but are bridged to the switch CPU
so that it can generate the ICMP-unreachable message.
Beginning in privileged EXEC mode, follow these steps to control access to an interface:
Command
Step 1
configure terminal
Step 2 interface vlan 1
Step 3 ip access-group {access-list-number |
name} in
Step 4 end
Step 5
show running-config
Step 6
copy running-config startup-config
OL-19808-01
Purpose
Enter global configuration mode.
Identify a specific line to configure, and enter in-line configuration mode.
• console—Specify the console terminal line. The console port is DCE.
vty—Specify a virtual terminal for remote console access.
•
The line-number is the first line number in a contiguous group that you want
to configure when the line type is specified. The range is from 0 to 16.
Restrict incoming and outgoing connections between a particular virtual
terminal line (into a device) and the addresses in an access list.
Return to privileged EXEC mode.
Display the access list configuration.
Purpose
Enter global configuration mode.
Configure management VLAN.
Control access to the specified interface.
Return to privileged EXEC mode.
Display the access list configuration.
(Optional) Save your entries in the configuration file.
Catalyst 2360 Switch Software Configuration Guide
Configuring IPv4 ACLs
24-13
