D Antenna
Insert the supplied antenna into the
antenna connector and screw down
the antenna as shown at right.
CAUTION!
• NEVER carry the transceiver by
the antenna.
• DO NOT transmit without an
antenna. Otherwise the transceiv-
er may be damaged.

ACCESSORY ATTACHMENT

D Belt clip
Conveniently attaches to your belt.
Attach the belt clip as described below.
q Release the battery pack if it is attached.
w Slide the belt clip in the direction of the arrow until the belt
lide the belt clip in the direction of the arrow until the belt lide the belt clip in the direction of the arrow until the belt
clip is locked and makes a 'click' sound. clip is locked and makes a 'click' sound. clip is locked and makes a 'click' sound.
- When detaching the belt clip - When detaching the belt clip - When detaching the belt clip
q Release the battery pack if it is attached. q q
w Pinch the clip
of the arrow (w).
(q), and slide the belt clip in the direction ), and slide the belt clip in the direction
w
q
