Serial Interface Operation
CDM-760 Advanced High-Speed Trunking Modem
Controller-to-Target
Instruction Code and
Qualifier
Parameter Type
Command
Query
Global
Configuration
(cont.)
Arguments for
Description of Arguments
Command or
(Note that all arguments are ASCII numeric codes from 48 to 57)
Query
T=Unit Test Mode
eeeeeeeeeeeeeeeeeeeeeeeeeeeeeeeeeeee=Unit Alarm Mask
c=Power Control State
dddd=AUPC Target Es/No
eeeee=AUPC Nominal Power Value
uuu.uuu.uuu.uuu.uu=IP address
vvv.vvv.vvv.vvv=IP gateway address
G=Tx/Rx BERT State
H=Tx/Rx BERT Pattern
fffff=AUPC Power Range
11111111111111111111=PIIC Card 1 Configuration
22222222222222222222=PIIC Card 2 Configuration
END OF MGC COMMAND/QUERY STRING
NOTES:
1) There are several possible types of PIIC interfaces available. The first bit of each 20 bit field determines the PIIC interface
type. 0 means no interface detected, non zero means an interface type was detected.
2) If no interface is present, then the following bits will be returned: 0UUUUUUUUUUUUUUUUUUU
3) If an interface is detected but the interface type is set to NONE, then the following bits will be returned:
20xxxxxxxxxxxxxxxxxx, where:
2 means G.703 interface detected
0 means NONE selected so it is disabled.
Description Of PIIC Interface Types:
ABCDEFGHIJKLMNOPssss
A=type of interface detected
0=No interface detected
1=Reserved
2=G.703 interface detected
3=OC3 interface detected
4=ASI interface detected
B=PIIC Mode
C=Tx Intf Clock Source
D=Rx Intf Clock Source
E=Intf Reference Clock
FGHIJ=Rx Buffer Size
K=Tx ASI Mode
L=Tx ASI Framing
M=Tx ASI Restamping
N=Rx ASI Mode
O=Rx ASI Framing
P=Rx ASI Output Format
ssss=spares
same as TST
same as MSK
same as PCS
same as ATE
same as ANP
same as IPA
same as IPG
same as BTX
same as TBP
same as APR
Notes 1-3
Notes 1-3
same as ETS (G703 and OC3 only)
same as TCK (G703 and OC3 only
same as RCK (G703 and OC3 only)
same as EFI (G703 only)
same as RBS
same as PTM (ASI only)
same as PTF (ASI only)
same as PTR (ASI only)
same as PRM (ASI only)
same as PRF (ASI only)
same as PRO (ASI only)
8–34
Revision 3
MN-CDM760
Target-to-Controller
(see Description of Arguments)
Response to
Response to
Command
Query
