SINUMERIK
SINUMERIK 840D sl / 828D / 808D
SINUMERIK Integrate Access
MyMachine /P2P (PC)
Operating Manual
Valid for: AMM Software Version V4.7 SP1
CNC Software Version 4.7 SP4
11/2016
A5E39356962B AA
Preface
Introduction
Safety notes
Description
Connection to the control
Operator control (software)
Reference
Troubleshooting/FAQs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents
loading

Related Manuals for Siemens SINUMERIK 840D sl

Summary of Contents for Siemens SINUMERIK 840D sl

  • Page 1 Preface Introduction Safety notes SINUMERIK Description SINUMERIK 840D sl / 828D / 808D SINUMERIK Integrate Access Connection to the control MyMachine /P2P (PC) Operator control (software) Operating Manual Reference Troubleshooting/FAQs Valid for: AMM Software Version V4.7 SP1 CNC Software Version 4.7 SP4...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Preface.................................7 SINUMERIK documentation.....................7 Target group..........................9 Hotline and Internet address....................10 Introduction..............................11 Scope of functions and supported SINUMERIK control systems...........11 Safety notes..............................15 Fundamental safety instructions for the software documentation (for all product families)..15 3.1.1 Fundamental safety instructions....................15 3.1.1.1 General safety instructions.....................15 3.1.1.2 Industrial security........................16 Security information on the product..................17...
  • Page 4 Table of contents 5.5.3.5 Assigning parameters for the internal modem...............52 5.5.3.6 Testing the connection......................54 5.5.4 Parameterize the TeleService adapter IE without the "TeleService" software.......59 5.5.5 Establishing a connection/Cabling..................60 5.5.6 Create modem connection under Windows 7................62 5.5.7 Establish modem connection under Windows 7..............67 5.5.8 Create a modem connection under Windows 10..............69 5.5.9...
  • Page 5 Languages supported by SINUMERIK Operate..............151 Toolbar..........................152 View overview........................153 Data structure on the CompactFlash Card system..............155 7.5.1 Data structure on the CompactFlash card (SINUMERIK 840D sl / 828D)......155 7.5.2 Data structure on the system CompactFlash card (SINUMERIK 808D)......158 7.5.3 Editing a file externally......................159 Open source software / licenses..................161...
  • Page 6 Table of contents SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 7: Preface

    Please send an e-mail (mailto:docu.motioncontrol@siemens.com) if you have any questions about the technical documentation (e.g. suggestions for improvement, corrections) to: My Documentation Manager (MDM) Under the following link (http://www.siemens.com/mdm) you will find information to individually compile OEM-specific machine documentation based on the Siemens content: Training For information about the range of training courses, refer to: ●...
  • Page 8 Preface 1.1 SINUMERIK documentation SINUMERIK You can find information on SINUMERIK at the following link. (http://www.siemens.com/ sinumerik) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 9: Target Group

    Preface 1.2 Target group Target group Target group This documentation is intended for operators of the "SINUMERIK Integrate Access MyMachine /P2P (PC)" software and teaches them how to utilize all the software functions correctly and completely. Benefits The operating manual familiarizes the target group with the control elements and commands. Based on the manual, the target group is capable of responding to problems and to take corrective action.

  • Page 10: Hotline And Internet Address

    1.3 Hotline and Internet address Hotline and Internet address Technical Support You can find country-specific telephone numbers for technical support on the Internet at the following address: Product support (www.siemens.com/automation/service&support). SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 11: Introduction

    Introduction Scope of functions and supported SINUMERIK control systems The "SINUMERIK Integrate Access MyMachine /P2P (PC)" tool (previously "RCS Commander") supports the commissioning and maintenance of machines with SINUMERIK Operate as of software version 2.6 using a standard Windows PC. From here on, the following terms/abbreviations are used synonymously in this document: "Access MyMachine"...
  • Page 12 Using the CNC lock function, you can activate, extend or deactivate a date in the control as of which the NC Start is locked. Supported SINUMERIK controls The following SINUMERIK controls are supported: ● SINUMERIK 840D sl (NCUs) ● SINUMERIK 828D (PPUs) ● SINUMERIK 808D (as of AMM version 4.6, PPU141.2 and PPU161.2) Foreign languages ●...
  • Page 13 Introduction 2.1 Scope of functions and supported SINUMERIK control systems In Windows, activate the support for Asian languages at "Region and Language" so that Asian characters are displayed correctly. Connections The following connections to a SINUMERIK solution line control are available: ●...
  • Page 14 Introduction 2.1 Scope of functions and supported SINUMERIK control systems SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 15: Safety Notes

    Safety notes Fundamental safety instructions for the software documentation (for all product families) 3.1.1 Fundamental safety instructions 3.1.1.1 General safety instructions WARNING Danger to life if the safety instructions and residual risks are not observed If the safety instructions and residual risks in the associated hardware documentation are not observed, accidents involving severe injuries or death can occur.

  • Page 16: Industrial Security

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends to apply product updates as soon as available and to always use the latest product versions. Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to cyber threats.

  • Page 17: Security Information On The Product

    Safety notes 3.2 Security information on the product Security information on the product NOTICE No confidential data on the control and in the AMM project Confidential data must not be loaded to the control and not downloaded to the AMM project from there.
  • Page 18 Safety notes 3.2 Security information on the product See also Industrial Security Configuration Manual (https://support.industry.siemens.com/cs/us/en/view/ 108862708) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 19: Description

    Description Structure of the user interface AMM user interface The following shows an overview of the AMM user interface with the most important windows, status indicators and operator controls. ① Main menu ② View of the computer file system (local file system) ③...

  • Page 20: First Start

    Description 4.2 First start First start Operating sequence The following prompts appear when AMM is started for the first time: 1. Enter a password. AMM always requires a password when started for the first time. Figure 4-2 Enter password – With the password, the file with the connection data of AMM is encrypted. –...

  • Page 21: Connection To The Control

    Connection to the control Establishing a connection to the control system: An overview AMM offers two options for establishing a connection to a control system: 1. Direct connection (peer-to-peer Ethernet) Direct connection involves connecting the PG/PC to the control system's X127 interface directly.

  • Page 22: Assigning The Connection Parameters

    Connection to the control 5.2 Assigning the connection parameters Assigning the connection parameters 5.2.1 Enable control ports 5.2.1.1 Overview You must access port 22 to establish a connection from AMM to the control. You must access port 5900 to establish a connection from AMM via remote control. Three ways of enabling a port are described below for each port access required.
  • Page 23 Connection to the control 5.2 Assigning the connection parameters 5. Press the "Change" softkey. Figure 5-1 Settings of the 840 sl workplace network 6. Set a check mark in the "Firewall exceptions" area for the following options: – VNC access (TCP/5900) –...

  • Page 24: Otherwise: Enable Ports Via Basesys.ini

    Otherwise: Enable ports via basesys.ini Note The port enable procedure applies only to the following SINUMERIK control: ● SINUMERIK 840D sl Operating sequence 1. Open the "/user/system/etc/basesys.ini" file on your control. 2. Under the variable "FirewallOpenPorts" enter the port "TCP/22" or if needed the port "TCP/ 5900".

  • Page 25: Otherwise: Enabling Ports Via The Service Shell

    Otherwise: Enabling ports via the service shell Note The port enable procedure applies only to the following SINUMERIK control: ● SINUMERIK 840D sl Operating sequence 1. Open a service shell on the TCU. 2. Enter the command "sc openport tcp/22 <IP Address>".
  • Page 26 Connection to the control 5.2 Assigning the connection parameters Operating sequence 1. Press the "Connection" icon. - OR - Select "Connection" > "Connect..." in the main window menu. The following dialog appears: Figure 5-3 Settings for direct connection 2. Select a direct connection, and click the "Edit" button. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 27: Assigning Parameters For Network Connection

    Connection to the control 5.2 Assigning the connection parameters 3. A direct connection is always established through the IP address 192.168.215.1 or IP 169.254.11.22 and via port 22. Enter the following authentication data: – Select a user name and enter the appropriate password. –...
  • Page 28 Connection to the control 5.2 Assigning the connection parameters Operating sequence 1. Press the "Connection" icon. - OR - Select "Connection > Connect..." in the main window menu. The following dialog appears: Figure 5-4 Network connection 2. Press "New" to create a new connection. 3.

  • Page 29: Converting An Ssh Key File

    Connection to the control 5.2 Assigning the connection parameters 5. Enter the following authentication data: – Select a user name and enter the appropriate password. – Select a user name and an SSH key file (Page 29). NOTICE The SSH key file must be available in OpenSSH format and must also be password protected.
  • Page 30 Connection to the control 5.2 Assigning the connection parameters Requirement This description is applicable to the PuTTYgen version 0.64: Note Note the central security information in Section Auto-Hotspot. Operating sequence 1. Download the PuTTYgen program from the Internet (http://www.chiark.greenend.org.uk/ ~sgtatham/putty/download.html). 2.

  • Page 31: Establishing The Connection

    If not, a dialog for entering the authentication data opens. See also Establishing a connection to the control system: An overview (Page 21) Industrial Security Configuration Manual (https://support.industry.siemens.com/cs/us/en/view/ 108862708) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 32: Establishing A Network Connection

    Connection to the control 5.3 Establishing the connection 5.3.2 Establishing a network connection Requirement Note Note the central security information in Section Auto-Hotspot. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 33 Connection to the control 5.3 Establishing the connection Operating sequence 1. The following ways of establishing a "network connection" are available: – Select "Connection" in the main window menu. The last five network connections are offered for selection. Select one of the menu entries. The connection to the selected control is established.
  • Page 34 Connection to the control 5.3 Establishing the connection See also Establishing a connection to the control system: An overview (Page 21) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 35: Disconnect Connection

    Connection to the control 5.4 Disconnect connection Disconnect connection You can disconnect a current connection to the control. Note that disconnecting the connection to the control also ends the remote control of your control. Operating sequence 1. There are two ways of disconnecting an active connection: –...

  • Page 36: Establishing A Modem Connection

    Connection to the control 5.5 Establishing a modem connection Establishing a modem connection 5.5.1 General information There are various ways to set up a modem connection from the PC to the control. This brief guide describes a modem connection to the 840D sl control using the TeleService Adapter IE (TS Adapter).

  • Page 37: Setting Up The Pg/Pc Interface

    Connection to the control 5.5 Establishing a modem connection See also Setting up the PG/PC interface (Page 37) Establishing a connection/Cabling (Page 60) Parameterize the TeleService adapter IE with the "TeleService" software (Page 38) Parameterize the TeleService adapter IE without the "TeleService" software (Page 59) 5.5.2 Setting up the PG/PC interface Operating sequence...

  • Page 38: Parameterize The Teleservice Adapter Ie With The "Teleservice" Software

    Connection to the control 5.5 Establishing a modem connection 9. Under "Location > Name:" select the location of your PG/PC. Click "Edit" if needed to open up the "Phone and Modem Options" dialog box to set up a new location. For more information on the location, refer to the help function for the "Edit location"...

  • Page 39: Inserting The System

    TeleService Adapter. Note The software is usually installed at C:\Program Files\Siemens\TeleService The license is on the supplied USB flash drive. In the first step, insert the plant (e.g. "840D sl") into the "TeleService" software.
  • Page 40 Connection to the control 5.5 Establishing a modem connection 5. Call it "my control systems". Figure 5-8 TeleService SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 41 Connection to the control 5.5 Establishing a modem connection 6. Press <F4>. A new system is inserted. Figure 5-9 Inserting a new system SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 42 Connection to the control 5.5 Establishing a modem connection 7. Enter the data for the system (see figure for an example). – Enter "840D sl" as the name and select "TS Adapter IE" as the adapter type. – Enter the telephone number for contacting the TS Adapter as the number. –...

  • Page 43: Assigning Parameters For The Ts Adapter

    Connection to the control 5.5 Establishing a modem connection 5.5.3.3 Assigning parameters for the TS Adapter Operating sequence 1. In the PG/PC interface, set the access point you wish to use when connecting to the TS Adapter. In this instance, we are using a network connection to the PC via USB. 2.
  • Page 44 Connection to the control 5.5 Establishing a modem connection 4. Select "Options" > "Set TS Adapter IE IP Parameter...". Figure 5-12 Setting parameters 5. Compare the MAC address with the MAC address printed on the TS Adapter. Note If the MAC addresses are different, select "Options" > "Settings". Now select the appropriate TS Adapter in the "Settings"...

  • Page 45: Administrating The Ts Adapter

    Connection to the control 5.5 Establishing a modem connection 5.5.3.4 Administrating the TS Adapter Operating sequence 1. Select "Options" > "Administrate TS Adapter IE" in the "TeleService" software menu. The following window appears. Figure 5-13 Administrate TS Adapter IE 2. Log on by entering "Administrator" and "admin" in the top-left section of the window. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 46 3. Generate at least one additional user in the "Security" > "User administration" window (see figure below) and assign admin rights to this user. Example: "Siemens" + "siemens" This user will be required again later and used to establish the connection to the TS Adapter.
  • Page 47 Connection to the control 5.5 Establishing a modem connection 4. Activate the following (see figure below) for the TS Adapter on the "General" tab in the "Security" > "Incoming calls" window: – "Firewall" SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 48 Connection to the control 5.5 Establishing a modem connection – "Allow the following exceptions" "Expert mode" The "expert mode" function is used subsequently to enable the port for the VNC connection. Figure 5-15 "Security" > "Incoming calls" > "General" tab SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 49 Connection to the control 5.5 Establishing a modem connection Figure 5-16 "Security" > "Incoming calls" > "SIMATIC protocols" tab SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 50 Connection to the control 5.5 Establishing a modem connection 5. It is important that SSH is approved (see figure below). Figure 5-17 "Security" > "Incoming calls" > "Internet protocols" tab 6. As already mentioned, VNC still requires approval. This is done in expert mode. Port 5900 for VNC must be opened (see figure below).
  • Page 51 Connection to the control 5.5 Establishing a modem connection Figure 5-18 "Security" > "Incoming calls" > "Expert mode" tab Note Make the same settings for "outgoing calls". You will now assign parameters for the internal modem of the TS Adapter IE. See also Assigning parameters for the internal modem (Page 52) SINUMERIK Integrate Access MyMachine /P2P (PC)

  • Page 52: Assigning Parameters For The Internal Modem

    Connection to the control 5.5 Establishing a modem connection 5.5.3.5 Assigning parameters for the internal modem Operating sequence 1. Select "Options" > "Administrate TS Adapter IE" in the "TeleService" software menu. 2. Assign the parameters for the internal modem as shown. If you are using an external modem, you will have to make the appropriate settings there.
  • Page 53 Connection to the control 5.5 Establishing a modem connection 4. Check the IP parameters you set earlier with the TeleService software. Figure 5-20 "Parameters" > "IP parameters" SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 54: Testing The Connection

    Connection to the control 5.5 Establishing a modem connection 5. To finish, reenter the contact telephone number for your modem on the PC. Figure 5-21 "Parameters" > "Outgoing calls" 6. Close the window. You will now test the connection which has been set. See also Testing the connection (Page 54) 5.5.3.6...
  • Page 55 Connection to the control 5.5 Establishing a modem connection 3. Enter the data for the user you have just created as the log-on data (e.g. "Siemens" + "siemens"). Figure 5-22 "Insert new system" > "Log-on data" SINUMERIK Integrate Access MyMachine /P2P (PC)
  • Page 56 Connection to the control 5.5 Establishing a modem connection 4. You can now test the connection you have set. To do this, select the system and choose "Establish" in the "Connection" menu (<F7> button). Figure 5-23 "Establish connection" SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 57 Connection to the control 5.5 Establishing a modem connection 5. Choose the modem and location and click "Select". If connection is successful, the "ONLINE" field in the status bar will become green. Figure 5-24 "ONLINE" system connection SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 58 Connection to the control 5.5 Establishing a modem connection 6. Select "Connection" > "Current connection" to observe the status of the connection currently established (see figure). Figure 5-25 Current connection 7. Parameter assignment for your TS Adapter is now complete. Make the following changes to the cabling (Page 60).

  • Page 59: Parameterize The Teleservice Adapter Ie Without The "Teleservice" Software

    Connection to the control 5.5 Establishing a modem connection Figure 5-26 Modem connection from the PC to the control system via the network and the TeleService Adapter IE See also Establishing a connection/Cabling (Page 60) 5.5.4 Parameterize the TeleService adapter IE without the "TeleService" software Operating sequence 1.

  • Page 60: Establishing A Connection/Cabling

    Connection to the control 5.5 Establishing a modem connection 5. Enter IP parameter as described as from Assigning parameters for the TS Adapter (Page 43) Step 4. 6. Continue through the following steps: – see Administrating the TS Adapter (Page 45) –...
  • Page 61 Connection to the control 5.5 Establishing a modem connection Establishing a modem connection via the general telephone network Set up the network via the modem terminals as follows (please also refer to the figure below): 1. Connect the PC with the general telephone network via the modem terminal. 2.

  • Page 62: Create Modem Connection Under Windows 7

    Connection to the control 5.5 Establishing a modem connection 5.5.6 Create modem connection under Windows 7 Operating sequence 1. Select "Start > Control Panel > Network and Sharing Center > Set up a new connection or network". 2. Select the connection option "Connect to a workplace". Figure 5-28 Connect to a workplace 3.
  • Page 63 Connection to the control 5.5 Establishing a modem connection 4. Select "Dial directly". Figure 5-29 Dial directly 5. Press "Set up a connection anyway". Connect a modem later if no modem is connected. Figure 5-30 Set up a connection anyway SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 64 Connection to the control 5.5 Establishing a modem connection 6. Enter the telephone number for contacting your TS adapter and assign a name to the connection. Figure 5-31 Enter telephone number 7. Press "Next". SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 65 Connection to the control 5.5 Establishing a modem connection 8. Enter the user name and password of the TS adapter. Figure 5-32 Enter user name and password: 9. Press "Create". Figure 5-33 Establish connection SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 66 Connection to the control 5.5 Establishing a modem connection Connection successfully established You can close the dialog or establish a connection. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 67: Establish Modem Connection Under Windows 7

    Connection to the control 5.5 Establishing a modem connection 5.5.7 Establish modem connection under Windows 7 Operating sequence Establish a connection to your TS adapter as follows. 1. In Windows, select "Start > Control panel > Network and sharing center > Connect to a network".
  • Page 68 Connection to the control 5.5 Establishing a modem connection Figure 5-35 Connecting A connection is established to the TS adapter. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 69: Create A Modem Connection Under Windows 10

    Connection to the control 5.5 Establishing a modem connection 5.5.8 Create a modem connection under Windows 10 Operating sequence 1. Select Start > Settings > Network and Internet > Dial-up > Set up a new connection". 2. Select the connection option "Connect to a workplace". Figure 5-36 Connect to a workplace 3.
  • Page 70 Connection to the control 5.5 Establishing a modem connection 4. Select "Dial directly". Figure 5-37 Dial directly 5. Press "Set up a connection anyway". Connect a modem later if no modem is connected. Figure 5-38 Set up a connection anyway SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 71 Connection to the control 5.5 Establishing a modem connection 6. Enter the telephone number for contacting your TS adapter and assign a name to the connection. Figure 5-39 Enter telephone number 7. Press "Next". SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 72 Connection to the control 5.5 Establishing a modem connection 8. Enter the user name and password of the TS adapter. Figure 5-40 Enter user name and password: 9. Press "Create". Figure 5-41 Establish connection SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 73 Connection to the control 5.5 Establishing a modem connection Connection successfully established You can close the dialog or establish a connection. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 74: Establish A Modem Connection Under Windows 10

    Connection to the control 5.5 Establishing a modem connection 5.5.9 Establish a modem connection under Windows 10 Operating sequence Establish a connection to your TS adapter as follows. 1. In Windows, select "Start > Settings > Network and Internet > Dial-up". 2.

  • Page 75: Connecting Amm To The Control System Via The Modem Connection

    Connection to the control 5.5 Establishing a modem connection Figure 5-43 Dial up - establish connection A connection is established to the TS adapter. 5.5.10 Connecting AMM to the control system via the modem connection Operating sequence 1. Establish a modem connection (Page 67) to your TS adapter. 2.

  • Page 76: Further Information

    Further information For more detailed information on parameter assignment for the TS Adapter, please refer to the supplementary material provided ("TS Adapter IE – Handbuch.pdf") or the following online sources: Product Support (http://support.automation.siemens.com/WW/view/de/10805406/130000) TeleService Adapter Manual (http://support.automation.siemens.com/WW/view/de/ 24623021) SINUMERIK Integrate Access MyMachine /P2P (PC)

  • Page 77: Operator Control (Software)

    Operator control (software) Remote control of the control system 6.1.1 Overview of remote control With the "remote control" function you can: ● Monitor and operate the control from the PG/PC (remotely). ● Generate screenshots of the control's HMI, and save them to the PG/PC. This enables you to inform support personnel of errors in the control's HMI via screenshots.

  • Page 78: Approving Remote Control Of The Control System On The Hmi

    Operator control (software) 6.1 Remote control of the control system 6.1.2 Approving remote control of the control system on the HMI 6.1.2.1 Approving remote control on the HMI Operating sequence for 840D sl/828D controls 1. Press the "Remote diagnostics" softkey in the "Diagnosis" operating area. Figure 6-1 "Remote diagnostics"...
  • Page 79 Operator control (software) 6.1 Remote control of the control system – Procedure for confirming remote access Figure 6-2 Observing "remote diagnostics" on the HMI 3. Choose the appropriate remote access function in the selection box. Operating sequence for an 808D control 1.
  • Page 80 Operator control (software) 6.1 Remote control of the control system 3. Confirm the selected setting with the "Select" softkey to enable remote access. 4. Confirm the settings made with the "Activate" softkey. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 81: Approving Remote Control Via The Control System

    Operator control (software) 6.1 Remote control of the control system 6.1.2.2 Approving remote control via the control system Operating sequence 1. If remote control is used to connect a PC with the control, the following dialog opens on the HMI: Figure 6-4 Allowing remote control 2.

  • Page 82: Further Documentation

    The following SINUMERIK manuals contain further information: ● SINUMERIK Operate Commissioning Manual ● 808D Commissioning Manual ● Turning, milling, and grinding operating manuals SINUMERIK support documentation (http://support.automation.siemens.com/WW/view/de/ 10805517/130000) 6.1.3 Functional scope of the remote control NOTICE Insecure use of the function to transfer files The VNC protocol used for remote control provides an option as standard for the transfer of files.
  • Page 83 Operator control (software) 6.1 Remote control of the control system 3. Once remote control has been started, a new window opens showing the screen contents of the connected control. Figure 6-5 Remote control of the control 4. While the remote control function is open, you can continue operating AMM as usual. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 84 Operator control (software) 6.1 Remote control of the control system Figure 6-6 AMM and remote-controlled control on the PG/PC See also Establishing a connection to the control system: An overview (Page 21) Overview of remote control (Page 77) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 85: Operation

    ● You can click the softkeys to operate them. ● The symbol for the operating areas is displayed in the top-left corner of the user interface. ● With SINUMERIK 840D sl and 828D click the symbol to display the operating areas on the horizontal softkey bar.
  • Page 86 ● Press F1 to F8 on the keyboard to operate the horizontal softkeys. ● Press Shift+F1 to Shift+F8 on the keyboard to operate the vertical softkeys. ● With SINUMERIK 840D sl and 828D press F10 on the keyboard to display the operating areas on the horizontal softkey bar.

  • Page 87: Using Remote Control To Generate The Screen Of The Control System's Hmi User Interface

    Operator control (software) 6.1 Remote control of the control system 6.1.3.3 Using remote control to generate the screen of the control system's HMI user interface Operating sequence 1. Establish a connection to a SINUMERIK solution line control (see "Establishing a connection to the control"...
  • Page 88 Operator control (software) 6.1 Remote control of the control system See also Establishing a connection to the control system: An overview (Page 21) Overview of remote control (Page 77) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 89: Project

    Operator control (software) 6.2 Project Project 6.2.1 Project overview Functionality You can edit various user files of a control configuration offline with the aid of a project. In this way, you can bring together logically related files of a control (e.g. for machine-specific administration of the user data for commissioning on the manufacturer's premises).
  • Page 90 Operator control (software) 6.2 Project Structure of a project A project always basically consists of a *.rcsproj file and an associated directory structure. The associated directories and files stand under each other in a logical relation. A subset of the file system of the control is normally shown in the offline project.

  • Page 91: Creating A Project (Offline)

    Operator control (software) 6.2 Project Transferring individual files from the control to the project (Page 119) Deleting files on the control using the project dialog (Page 121) Recommended procedure when translating files (Page 124) Activating the alarm text files on the control using an HMI restart (Page 126) 6.2.2 Creating a project (OFFLINE) This function generates a new project on the PG/PC for a specific control type.

  • Page 92: Create A Project And Read The Files From The Control System (Online)

    Operator control (software) 6.2 Project 5. Select the storage location of the project on the PC. 6. The project is created and opened in the project dialog with "Save". If a project already exists, an error message appears. Figure 6-10 Project dialog (OFFLINE) 6.2.3 Create a project and read the files from the control system (ONLINE)
  • Page 93 Operator control (software) 6.2 Project 3. A dialog opens to create a new project. Figure 6-11 New project 4. The control type is automatically preselected and cannot be changed. 5. Select a target language in which the first user text files are to be created. (If available on the control system, they will be automatically overwritten in the project.) 6.
  • Page 94 Operator control (software) 6.2 Project 8. The project is created with "Save". 9. The control system is then automatically read-out and the files that are found are transferred into the project. Figure 6-12 Copy – Once the found files have been copied, then the new project is displayed in the project dialog.

  • Page 95: Opening An Existing Project

    Operator control (software) 6.2 Project Figure 6-13 Project dialog (ONLINE) 6.2.4 Opening an existing project Introduction The following two options are available to open an existing project: ● Using the menu ● With a double-click on the project file SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 96 Operator control (software) 6.2 Project Operating sequence "Using the menu" 1. Select "File > Open project" from the menu. 2. The following dialog appears. The projects that were last opened are displayed in this dialog and can be subsequently selected, whereby the last project that was opened is preselected. Figure 6-14 Open project 3.
  • Page 97 Operator control (software) 6.2 Project 4. After the desired project has been selected, it can be opened with "Open". 5. The opened project is then displayed in the project dialog. The name of the active, open project appears at the top, in the title bar of the program. Figure 6-15 Project dialog (OFFLINE) SINUMERIK Integrate Access MyMachine /P2P (PC)
  • Page 98 Operator control (software) 6.2 Project Operator action "With a double-click on the project file" 1. Navigate in the file display of AMM to the storage location of the project to be opened. Figure 6-16 AMM (OFFLINE and without project) 2. Open the project with Open from the shortcut menu or by double-clicking the *.rcsproj file. 3.

  • Page 99: Closing The Project

    Operator control (software) 6.2 Project Figure 6-17 AMM with project dialog (OFFLINE) 6.2.5 Closing the project Operating sequence 1. You can close the open project with "File > Close project" in the main window menu. 2. The project dialog disappears, and "No project active" is displayed in the title bar of AMM. As a consequence, a project is not automatically opened the next time AMM starts.

  • Page 100: Deleting A Project

    Operator control (software) 6.2 Project 6.2.6 Deleting a project Note Possible data loss Note that files which you have copied into the project directory yourself are also deleted by the delete process! Operating sequence 1. Navigate in the file display of AMM to the storage location of the project to be deleted. Figure 6-18 AMM (OFFLINE and without project) The project was created in a directory which has the same name as the project.

  • Page 101: Creating A New Language

    Operator control (software) 6.2 Project 6.2.7 Creating a new language This function enables a new (additional) language to be created in the project. New language- specific files are copied into the project. The data they contain is accepted, and can then be translated into the target language.
  • Page 102 Operator control (software) 6.2 Project Operating sequence 1. Open a project. Figure 6-19 AMM with project dialog (OFFLINE) 2. From the tree topology in the project dialog, select the file type (alarm texts, EasyScreen, etc.) that you want to create in a new language. 3.

  • Page 103: Adding A File

    Operator control (software) 6.2 Project 5. Here, select the target language in which the files are to be created. Only those languages are listed here, which are not yet included in the project. By default, initially only the standard languages are listed. Additional languages are listed for selection by setting the check mark for "All languages".
  • Page 104 Operator control (software) 6.2 Project Operating sequence 1. Open a project. Figure 6-22 AMM with project dialog (OFFLINE) 2. From the tabs in the project dialog, select the file type (alarm texts, EasyScreen, tool management texts or archives) to which you want to add a file. 3.

  • Page 105: Deleting A File

    Operator control (software) 6.2 Project 6. The selected files are then copied to the project. If a file already exists, a confirmation prompt is displayed. 7. The new files are then displayed in the project dialog. 6.2.9 Deleting a file You can delete the selected files from the project with this function.

  • Page 106: Exporting A File

    Operator control (software) 6.2 Project 3. Activate the checkbox for the files you want to delete. Note If you activate a checkbox for a language folder, the checkboxes for all underlying files are activated automatically. This allows a quick and simple deletion of a language. Note This function always acts on just one tab! Not on all.
  • Page 107 Operator control (software) 6.2 Project Operating sequence 1. Open a project. Figure 6-24 AMM with project dialog (OFFLINE) 2. From the tree topology in the project dialog, select the file type (alarm texts, EasyScreen, etc.) from which you want to export files. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 108 Operator control (software) 6.2 Project 3. Activate the checkbox for the files you want to export. Note If you activate a checkbox for a language folder, the checkboxes for all underlying files are activated automatically. This allows a quick and simple export of a language. Note This function always acts on just one tab! Not on all.

  • Page 109: Import File

    Operator control (software) 6.2 Project 5. Select a folder and click "OK". 6. The files are then converted into CSV format and placed in the selected folder. In this case, the *.csv extension is added to the file name. Note The generated name should not be changed with the exception of the language code, as otherwise the import no longer functions and errors can occur in the file structure.
  • Page 110 Operator control (software) 6.2 Project Operating sequence 1. Open a project. Figure 6-26 AMM with project dialog (OFFLINE) 2. Under the tree topology in the project dialog, select the file type (Alarm texts, EasyScreen, etc.) to which you want to import files. 3.

  • Page 111: Edit File

    Operator control (software) 6.2 Project See also Recommended procedure when translating files (Page 124) 6.2.12 Edit file Files contained in the project can be opened and edited with this function. Several files can be opened simultaneously. Operating sequence 1. Open a project. Figure 6-27 AMM with project dialog (OFFLINE) 2.
  • Page 112 Operator control (software) 6.2 Project 3. Open a language folder. Select the file you want to edit. Figure 6-28 Project dialog (OFFLINE) - languages with selected file SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 113: Compare Archives

    Operator control (software) 6.2 Project 4. Click "Edit" or double-click the file you want to edit. 5. The file is then opened in an editor and can now be edited. (For more information, see Section Auto-Hotspot) Figure 6-29 AMM editor The archives are opened and can be edited in the already installed "Create MyConfig - Diff"...
  • Page 114 Operator control (software) 6.2 Project Operating sequence 1. Open a project. Figure 6-30 AMM with project dialog (OFFLINE) 2. Select the "Archives" file type from the tab In the Project dialog. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 115: Transferring Individual Files From The Project To The Control System

    Operator control (software) 6.2 Project 3. Open an archive directory, and select at least two files you want to compare. Figure 6-31 Project dialog (OFFLINE) - selected archives 4. Now click "Compare". 5. The archives are then opened and can be compared in the already installed "Create MyConfig - Diff"...
  • Page 116 Operator control (software) 6.2 Project Note Note the central security information in Section Auto-Hotspot. Operating sequence 1. Connect yourself to a control. 2. Open a project. Figure 6-32 AMM with project dialog (ONLINE) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 117 Operator control (software) 6.2 Project 3. In the project dialog, in each substructure (Alarm texts, EasyScreen, etc.), activate the checkbox for the files that you want to copy to the control. Figure 6-33 Project dialog (ONLINE) 4. Then click the "Transfer to control" button. Note As it does not make sense to copy files to the control if the control type is different to that in the project, in such a case a corresponding error message is output.
  • Page 118 Operator control (software) 6.2 Project 6. If the file(s) is/are already on the control, then the "Prepare to copy" dialog opens. You are prompted as to whether you want to overwrite the file. If you select "Yes", the file is overwritten.

  • Page 119: Transferring Individual Files From The Control To The Project

    Operator control (software) 6.2 Project 6.2.15 Transferring individual files from the control to the project Single or multiple files in the connected control are transferred to the project with this function. Note All files with an activated checkbox are transferred to the project. Note Note the central security information in Section Auto-Hotspot.
  • Page 120 Operator control (software) 6.2 Project 4. For the files that you want to transfer to the project, activate the checkbox in the appropriate window. In contrast to the display in the upper area of the project dialog, the color and configuration files are also displayed.

  • Page 121: Deleting Files On The Control Using The Project Dialog

    Operator control (software) 6.2 Project 5. Then click the "Transfer to PC" button. Note As it does not make sense to copy files to the project if the control type between the control and project is different, then a corresponding error message is output. 6.
  • Page 122 Operator control (software) 6.2 Project Operating sequence 1. Connect to a control system. 2. Open a project. Figure 6-40 AMM with project dialog (ONLINE) 3. In the lower window of the project dialog, all files (Alarm texts, EasyScreen, etc.) are displayed that are in the control system.
  • Page 123 Operator control (software) 6.2 Project 4. Activate the checkboxes alongside the files in the window you want to delete. Figure 6-41 Project dialog (ONLINE) - with activated checkbox for the files Note If you activate the checkbox in one of the higher-level elements, the checkboxes for all underlying elements are also activated.

  • Page 124: Recommended Procedure When Translating Files

    Operator control (software) 6.2 Project 6.2.17 Recommended procedure when translating files The AMM project supports processes for translating the text files it contains into various languages. The AMM offers an export and import function into the standardized CSV format. This makes it possible to pass the exported languages to a translator, and import them back in after translation.
  • Page 125 Operator control (software) 6.2 Project 4. Activate the checkbox alongside the newly created (Chinese) files, and export (Page 106) the files. Figure 6-43 Project dialog (OFFLINE) - languages with check mark SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 126: Activating The Alarm Text Files On The Control Using An Hmi Restart

    Operator control (software) 6.2 Project 5. Give the generated CSV files to a translator - or translate the texts in the CSV files yourself. Figure 6-44 AMM - exported files 6. Import the translated files (Chinese) back into the project, thus overwriting the existing Chinese files.
  • Page 127 3. Copy (Page 115) the alarm text files from the project to the control. 4. After copying has been successfully completed, start the remote control. Figure 6-45 Remote control (e.g. SINUMERIK 840D sl / 828D) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 128 5. Click in the upper left-hand corner of the displayed HMI screen or press F10. The menu is now displayed. Figure 6-46 Remote control menu (e.g. SINUMERIK 840D sl / 828D) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 129 Operator control (software) 6.2 Project 6. Click the arrow pointing to the right. Figure 6-47 HMI restart (e.g. SINUMERIK 840D sl / 828D) 7. Click "HMI restart". 8. Wait until the HMI has rebooted. The new texts then become effective. See also...

  • Page 130: Access To Nc File System

    Operator control (software) 6.3 Access to NC file system Access to NC file system 6.3.1 NC file system of the 840D sl and 828D controls AMM can be used to access the NC file system of the 840D sl and 828D controls. You can copy, change, or delete part programs, workpiece programs, cycles, etc., in the control system's NC itself.

  • Page 131: Nc File System Of The 808D Control

    Operator control (software) 6.3 Access to NC file system Structure The "NC data" directory has the following structure: Table 6-1 "NC data" /CMA Manufacturer cycles Directory for manufacturer cycles /COM Comments Directory for comment files /CST Standard cycles Directory for standard cycles /CUS User cycles Directory for user cycles...
  • Page 132 Operator control (software) 6.3 Access to NC file system Operating sequence 1. Choose one of the two directories in the main window: – "Program" – "User cycles" Figure 6-49 NC file system 808D 2. Select the file you want to copy, change, or delete from one of the two directories. Structure The "Program"...

  • Page 133: Backing Up/Restoring A Compactflash Card

    Operator control (software) 6.4 Backing up/restoring a CompactFlash Card Backing up/restoring a CompactFlash Card 6.4.1 Overview of backing up/restoring a CompactFlash Card It is recommended that you create an image of your CompactFlash card so that your control settings can be restored, and to back up your data. You have the following options for control data: ●...
  • Page 134 Operator control (software) 6.4 Backing up/restoring a CompactFlash Card Operating sequence 1. To create a data storage medium image of the CompactFlash card / USB flash drive, click "Tools" > "Create CF card image" in the main window menu. Figure 6-50 Generate image 2.

  • Page 135: Writing An Image To The Compactflash Card/Usb-Flashdrive

    Operator control (software) 6.4 Backing up/restoring a CompactFlash Card See also Overview of backing up/restoring a CompactFlash Card (Page 133) 6.4.3 Writing an image to the CompactFlash Card/USB-FlashDrive Operating sequence 1. To write a CompactFlash card image to the CompactFlash card / USB flash drive, click "Tools"...

  • Page 136: Writing A Sinumerik 828D Boot System

    Operator control (software) 6.4 Backing up/restoring a CompactFlash Card 3. Select the CompactFlash card in the card reader for the PC or the USB flash drive to which the CompactFlash card image should be written. Figure 6-53 Select storage medium 4.
  • Page 137 Operator control (software) 6.4 Backing up/restoring a CompactFlash Card To restore a defective card or for writing a minimal SINUMERIK 828D system, proceed as follows: Operating sequence 1. Select "Tools" > "Write SINUMERIK 828D boot system" in the menu. (This menu item appears only if a SINUMERIK 828D toolbox has been installed on your PC.) 2.
  • Page 138 Operator control (software) 6.4 Backing up/restoring a CompactFlash Card 4. This dialog requires you to select the storage medium (CompactFlash card) to which the boot system image is to be written. Figure 6-56 Select a medium 5. Select "Write" to begin the writing process. Figure 6-57 Writing the SINUMERIK 828D boot system Note...

  • Page 139: Cnc Lock Function

    The machine manufacturer decides to sell a machine using the leasing business model with CNC lock function and licenses this function for the appropriate control from Siemens with the serial number of the CompactFlash card. This means that the machine manufacturer has the option, using the "SINUMERIK Integrate Access MyMachine/ P2P (PC)"...
  • Page 140 Operator control (software) 6.5 CNC Lock function Operating sequence 1. To activate the CNC lock function, click "Tools > CNC lock function" in the main window menu. Figure 6-58 CNC lock function The "CNC lock function" dialog opens. 2. Click the "Activate" button at "Select CNC lock function". The button is selected. 3.

  • Page 141: Extending The Cnc Lock Function

    109481523), Section "P4: PLC for SINUMERIK 828D > CNC lock function" ● "SINUMERIK 808D, SINUMERIK 808D ADVANCED Commissioning Manual (https:// support.industry.siemens.com/cs/de/de/view/109736343/en)", Section "Other frequently used functions", "CNC lock function". Managing data To manage the data, you can save the entered data in a dedicated file on the PC.
  • Page 142 Operator control (software) 6.5 CNC Lock function Requirement Software option You require the following option in order to use this function: "CNC lock function 6FC5800-0AP76-0YB0". Operating sequence 1. To extend the CNC lock function, click "Tools > CNC lock function" in the main window menu.
  • Page 143 109481523), Section "P4: PLC for SINUMERIK 828D > CNC lock function" ● "SINUMERIK 808D, SINUMERIK 808D ADVANCED Commissioning Manual (https:// support.industry.siemens.com/cs/de/de/view/109736343/en)", Section "Other frequently used functions", "CNC lock function". Managing data To manage the data, you can save the entered data in a dedicated file on the PC.

  • Page 144: Deactivating The Cnc Lock Function

    Operator control (software) 6.5 CNC Lock function Click the "Save data" button to save the entered data in a "user_lockset.ulcs" file on the PC. To retain clarity when a large number of files are involved, information such as which customer has installed which CompactFlash card in which machine can be entered in the comment field.
  • Page 145 Operator control (software) 6.5 CNC Lock function Operating sequence 1. To deactivate the CNC lock function, click "Tools > CNC lock function" in the main window menu. Figure 6-60 Deactivating the CNC lock function The "CNC lock function" dialog opens. 2.

  • Page 146: Reading In Lockset File

    109481523), Section "P4: PLC for SINUMERIK 828D > CNC lock function" ● "SINUMERIK 808D, SINUMERIK 808D ADVANCED Commissioning Manual (https:// support.industry.siemens.com/cs/de/de/view/109736343/en)", Section "Other frequently used functions", "CNC lock function". Managing data To manage the data, you can save the entered data in a dedicated file on the PC.

  • Page 147: Further Information

    5. Select the shortcut <ALT+N> at remote control. Press the arrow pointing to the right and select the "Version" softkey. Then select the "License key" softkey and select "Import file". See also Function Manual, Basic Functions (https://support.industry.siemens.com/cs/us/en/view/ 109481523) 6.5.6 Further information...
  • Page 148 Operator control (software) 6.5 CNC Lock function You can download the Function Manual "Basic Functions" in the Internet (https:// support.industry.siemens.com/cs/us/en/view/109481523). FAQs The Function Manual "Basic Functions" includes answers to important FAQs on the following subjects: ● What happens when defective control hardware (PPU) is replaced? ●...

  • Page 149: Reference

    Reference Supported files Supported files The following file types are supported in the AMM project: Files 840D sl 828D 808D Type Path Editable in Alarm texts oem_alarms_cycles_<lng>.ts oem_alarms_plc_<lng>.ts oem_partprogram_messages_<lng>.ts Color attribute files alarmtexteditor_db_oem_alarms_cycles.xml alarmtexteditor_db_oem_alarms_plc.xml alarmtexteditor_db_oem_partprogram_mes‐ sages.xml Configuration files slaesvcconf.xml slaesvcadapconf.xml Alarm texts alc_<lng>.txt alcu_<lng>.txt...
  • Page 150 Reference 7.1 Supported files Files 840D sl 828D 808D Type Path Editable in Maintenance planner svc_task_<lng>.txt Other almc_<lng>.txt md_descr_<lng>.txt rparam_name_<lng>.txt Archives Any names (*.arc and *.ard) Binary oem + user Direct editing of files is not supported. The files are automatically edited via the project when the alarm texts are edited. The color and popup information are saved in these files.

  • Page 151: Languages Supported By Sinumerik Operate

    Reference 7.2 Languages supported by SINUMERIK Operate Languages supported by SINUMERIK Operate Table 7-1 Supported languages Language Language code Standard languages Chinese (simplified) Chinese (traditional) Danish German English Finnish French Indonesian Italian Japanese Korean Malaysian Dutch Polish Portuguese Romanian Russian Swedish Slovenian Slovakian...

  • Page 152: Toolbar

    Reference 7.3 Toolbar Toolbar The table below describes the functions of the toolbar buttons. Symbol Function Connect Establish a connection to the control Disconnect Disconnect a connection established to the control Remote control Operate the control from the PC and display the HMI screens at the PC Show or hide the project window Showing or hiding of the "Project"...

  • Page 153: View Overview

    Reference 7.4 View overview View overview Using the "View" menu, you can show and hide windows and menus, and specify the directory view. The following submenus are available for this: ● Toolbar ● Status bar ● Project window ● Info window > Online status ●...
  • Page 154 Reference 7.4 View overview Menu Submenu Description Shortcut menu Large symbols Adaptation of the directory view The contents of the directory can be displayed as "Large sym‐ Small symbols bols", "Small symbols", or as a "List" or detailed view. The List function always relates to the window that is currently active.

  • Page 155: Data Structure On The Compactflash Card System

    To modify files, copy an original file from the "/Siemens/sinumerik/hmi/template" directory and paste it into the appropriate place in the "OEM" or "User" directory. There are also sample files in the "Siemens" directory that you can copy and use as user- specific files.
  • Page 156 Reference 7.5 Data structure on the CompactFlash Card system Path Meaning Texts of the applications in additional languages Online help of the applications for additional languages /osal/qt.cfs /osal/ace.cfs ACE/TAO /hlp Online help for runtime /deu Online help in German /hmi Directory for HMI online help in German /hmi.xml Directories for additional books...
  • Page 157 Reference 7.5 Data structure on the CompactFlash Card system Path Meaning /lng Language-dependent texts for runtime /hlp Online help for runtime (see above) Remarks: At runtime, the binaries from addon1.cfs, addon2.cfs are linked to /appl. At runtime, the config files are linked from addon1.cfs and addon2.cfs to /cfg. At runtime, the files are linked with the language-dependent texts to /lng.

  • Page 158: Data Structure On The System Compactflash Card (Sinumerik 808D)

    Reference 7.5 Data structure on the CompactFlash Card system The structure is the same as the "/OEM/sinumerik" structure. It begins, however, in the "/OEM_I/ sinumerik" path. Table 7-5 "/User/sinumerik" structure Path Meaning /User/sinumerik /hmi user User (everything except texts and online help) /ico/ico640 Icons in resolution 640 x 480 /ico/ico800...

  • Page 159: Editing A File Externally

    Reference 7.5 Data structure on the CompactFlash Card system Structure The following shows the structure of important directories: Table 7-6 "HMI root/siemens/sinumerik" structure Path Meaning /hmi /cfg All config files for runtime /hlp/[LANG] Online help for runtime in various languages...
  • Page 160 Reference 7.5 Data structure on the CompactFlash Card system Entering comments in an XML file If you are entering comments to explain a program, you must keep the following in mind: ● A comment always begins with the sequence: <!-- ●...

  • Page 161: Open Source Software / Licenses

    For further information, refer to the "License.txt" file in the Access MyMachine /P2P(PC) installation folder License conditions for the product This "SINUMERIK Integrate Access MyMachine /P2P (PC)" software is subject to the Siemens license conditions and third-party license conditions. For further information, refer to the "LiesMich_OSS.html" or the "ReadMe_OSS.html" file on the installation data storage medium.
  • Page 162 Reference 7.6 Open source software / licenses SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 163: Troubleshooting/Faqs

    Troubleshooting/FAQs Password forgotten If you have forgotten your password, you can reset your password with the "Reset password" function. This function is available in the "Enter password" dialog and in the "Change password" dialog. Operating sequence 1. Click the "Reset password" button. The "Assign password..."...

  • Page 164: Trace Files For Error Correction

    Troubleshooting/FAQs 8.2 Trace files for error correction Trace files for error correction For problems or errors in AMM, contact the Siemens Product support (www.siemens.com/ automation/service&support) at any time. The hotline will provide you with a trace file for the error correction in AMM. This is a comprehensive log for the error analysis. If required, you obtain more information on the precise functionality from the hotline.

  • Page 165: Problems Connecting To The Control

    You also need access to port 5900 to assign parameters to a connection from the AMM via remote control. As from specific software versions of the controls, these ports are disabled by default for security reasons. Control Software version SINUMERIK 840D sl V4.7 SP1 SINUMERIK 828D V4.7 SP1 SINUMERIK 808D V4.7 HF1 V4.6 SP2...

  • Page 166: Setting Up Series Machines

    Troubleshooting/FAQs 8.4 Setting up series machines Setting up series machines How can I set up series machines? This function is not supported. You need to use the SINUMERIK Integrate "Create MyConfig" tool instead. SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 167: Sl: Activate Remote Control For The Vnc Viewer

    Troubleshooting/FAQs 8.5 840D sl: Activate remote control for the VNC Viewer. 840D sl: Activate remote control for the VNC Viewer. You can use the VNC Viewer to connect yourself by remote control to 840D sl controls that have an active VNC server, e.g. PCU or NCU. The factory settings only enable you to monitor a system (e.g.
  • Page 168 Troubleshooting/FAQs 8.5 840D sl: Activate remote control for the VNC Viewer. Further information Operator Components and Networking Manual Options for the VNC Viewer Note Do not change the factory settings! To ensure that the VNC Viewer works properly, the following options must not be changed. After starting the VNC Viewer, the following dialog opens: Figure 8-1 VNC Viewer - Factory Settings...
  • Page 169 Troubleshooting/FAQs 8.5 840D sl: Activate remote control for the VNC Viewer. Figure 8-2 VNC Viewer > Options - Factory Settings SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 170: Cnc Lock Function

    ● Function Manual "Basic Functions", Chapter "P4: PLC for SINUMERIK 828D > CNC Lock function" You can download the Function Manual "Basic Functions" in the Internet (https:// support.industry.siemens.com/cs/us/en/view/109481523). FAQs The Function Manual "Basic Functions" includes answers to important FAQs on the following subjects: ●...

  • Page 171: Activating The Alarm Text Files On The Control Using An Hmi Restart

    3. Copy (Page 115) the alarm text files from the project to the control. 4. After copying has been successfully completed, start the remote control (Page 81). Figure 8-3 Remote control (e.g. SINUMERIK 840D sl / 828D) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 172 5. Click in the upper left-hand corner of the displayed HMI screen or press F10. The menu is now displayed. Figure 8-4 Remote control menu (e.g. SINUMERIK 840D sl / 828D) SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 173 8.7 Activating the alarm text files on the control using an HMI restart 6. Click the arrow pointing to the right. Figure 8-5 HMI restart (e.g. SINUMERIK 840D sl / 828D) 7. Click "HMI restart". 8. Wait until the HMI has rebooted. The new texts then become effective.

  • Page 174: Recommended Procedure When Translating Files

    Troubleshooting/FAQs 8.8 Recommended procedure when translating files Recommended procedure when translating files The AMM project supports processes for translating the text files it contains into various languages. The AMM offers an export and import function into the standardized CSV format. This makes it possible to pass the exported languages to a translator, and import them back in after translation.
  • Page 175 Troubleshooting/FAQs 8.8 Recommended procedure when translating files 4. Activate the checkbox alongside the newly created (Chinese) files, and export (Page 106) the files. Figure 8-7 Project dialog (OFFLINE) - languages with check mark SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
  • Page 176 Troubleshooting/FAQs 8.8 Recommended procedure when translating files 5. Give the generated CSV files to a translator - or translate the texts in the CSV files yourself. Figure 8-8 AMM - exported files 6. Import the translated files (Chinese) back into the project, thus overwriting the existing Chinese files.

  • Page 177: Backing Up Commissioning Data On The Control

    Troubleshooting/FAQs 8.9 Backing up commissioning data on the control Backing up commissioning data on the control Before restoring an image, back up the current commissioning data as follows: Backing up the commissioning data: 840D sl There are various ways of creating and reloading archives via the SINUMERIK Operate user interface.
  • Page 178 Troubleshooting/FAQs 8.9 Backing up commissioning data on the control SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...

  • Page 179: Index

    Index Deactivate, 145 Extend, 141 Comment input ini file, 160 *.arc, 150 XML file, 160 *.ard, 150 Commissioning support, 166 CompactFlash card Backing up, 133 Directory structure, 155 Restoring, 133 Alarm texts, 105 Compare Archives, 105 Archive, 115 EasyScreen, 105 Archives, 115 Tool management texts, 105 Configuration file...
  • Page 180 Index Error correction, 164 Error log, 164 oem_aggregate_<lng>.ts, 149 oem_alarms_cycles_<lng>.ts, 149 File, 104, 105, 107, 110, 111, 116, 119, 159 oem_alarms_plc_<lng>.ts, 149 Add, 104 oem_partprogram_messages_<lng>.ts, 149 Delete, 105 Online, 92 Edit, 111 Open source software, 161 Export, 107 External editing, 159 Import, 110 Transfer, 116, 119 Password, 20, 163...
  • Page 181 Index slstepforms_<lng>.ts, 149 sltmlistdialog_<lng>.ts, 149 SSH key file, 30 Adapt format, 30 Convert, 30 Status bar, 19 Status window, 19 svc_task_<lng>.txt, 150 Tool management texts, 105, 106, 113 Add, 105 Delete, 106 Edit, 113 Toolbar, 19 Trace, 164 Trace file, 164 User interface Overview, 19 User interface languages, 12...
  • Page 182 Index SINUMERIK Integrate Access MyMachine /P2P (PC) Operating Manual, 11/2016, A5E39356962B AA...
