• J-585 ™
• J-575 ™
J-500 ™ COLLECTION
OWNER'S MANUAL
2530-278D Rev A

Advertisement

Table of Contents
loading

Related Manuals for Jacuzzi J-585

Summary of Contents for Jacuzzi J-585

  • Page 1 • J-585 ™ • J-575 ™ J-500 ™ COLLECTION OWNER’S MANUAL 2530-278D Rev A...
  • Page 2 Attention New Spa Owner! Congratulations on the purchase of your new Jacuzzi® spa! The following is a list of automated functions performed by your spa. These functions are listed below in an attempt to suppress any operational concerns you may have during...

  • Page 3: Table Of Contents

    J-575 Spa Features ..............22 J-575 Massage/Waterfall Selector Diagram ........ 23 J-575 Air Controls Diagram............24 J-585 Spa Features ..............25 J-585 Massage/Waterfall Selector Diagram ........ 26 J-585 Air Controls Diagram............27 10.0 Registration and Start-up ............28 10.1 Start-up Sequence ............... 28 10.2...
  • Page 4 11.10 CLEARRAY on Demand .............. 38 11.11 Adjusting Jet Flow................ 38 11.12 Adjusting PowerPro™ MX2 Jets..........38 11.13 Adjusting RX Jets ................ 38 11.14 Waterfall Control ................38 11.15 Air Controls .................. 38 11.16 Selecting the Desired Massage Action ........39 11.17 Optional BLUEWAVE®...
  • Page 5 17.0 Typical Spa Wiring Diagrams ............ 70 17.1 Wiring diagram for North American 60 Hz Models Only ....70 18.0 Circuit Board Wiring Diagrams ..........71 18.1 Domestic 60Hz Wiring Diagram........... 71 18.2 Export 50Hz Wiring Diagram ............72 18.3 Dip Switch Settings ..............

  • Page 7: Important Spa Owner Information

    Jacuzzi insulating cover in place at all times when the spa is not in use. Read and carefully follow the requirements for your spa’s support base found in the Section 4.0 titled, “Choosing a Location”...

  • Page 8: Important Safety Instructions For All Spa Owners

    Important Safety Instructions for all Spa Owners READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY! This spa was manufactured to meet the standards and specifications outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safety Act). When installing and using this spa, basic safety precautions should always be followed, including: DANGER: RISK OF SEVERE INJURY OR DROWNING!
  • Page 9 • A grounding wire connector is provided on this unit to connect a minimum No. 8 AWG (8.4 mm²) solid copper conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit.
  • Page 10 WARNING: RISK OF SEVERE INJURY OR DEATH! • Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, if pregnant or possibly pregnant, consult your physician before using a spa. • Pregnant or possibly pregnant women should limit spa water temperatures to 100°F (38°C).
  • Page 11 WARNING: In addition to maintenance of filters and water chemistry, proper ventilation is recommended to reduce the risk of contracting a waterborne illness (e.g. an infection, bacteria or virus) and/or respiratory ailments that could be present in the air or water. Consult a licensed architect or building contractor to determine your specific needs if installing your hot tub indoors.

  • Page 12: Entrapment Risk

    Entrapment Risk The Consumer Products Safety Commission/USA has reported that users of pools and spas have become entrapped (stuck) to drain and/or suction fittings causing death, drowning, or serious injury (see diagram below). This spa was manufactured to meet the standards and specifica- tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”...

  • Page 13: Hyperthermia

    A Warning Sign is provided in your warranty packet. Please install at a location near your spa, where it is visible to users of the spa. For additional or replacement Warning Signs please contact your local Jacuzzi dealer and reference item number #6530-082. Page 7...

  • Page 14: Important Csa Safety Instructions (Canada Only)

    Important CSA safety instructions (Canada only) When using this electrical equipment, basic safety precautions should always be followed, including the following: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. A green colored terminal or a terminal marked G, Gr, Ground, Grounding or the symbol* is located inside the supply terminal box or compartment.

  • Page 15: Outdoor Location

    The spa must be installed in such a manner as to provide drainage away from it. Placing the spa in a depression without provisions for proper drainage could allow rain, overflow and other casual water to flood the equipment and create a wet condition in which it would sit in. For spas which will be recessed into a floor or deck, install so as to permit access to the equipment, either from above or below, for servicing.

  • Page 16: Indoor Location

    Indoor Location For indoor installations many factors need to be considered before installing a spa indoors. WARNING: In addition to maintenance of filters and water chemistry, proper ventilation is recommended to reduce the risk of contracting a waterborne illness (e.g. an infection, bac- teria or virus) and/or respiratory ailments that could be pres- ent in the air or water.

  • Page 17: Location For The Prolink™ Monitoring System

    Location for the ProLink™ Monitoring System IMPORTANT! Choose an installation site with the front control panel side pointing towards your home’s Wi-Fi router. CAUTION: You must make sure that the spa control panel side has a clear unobstructed line-of-site of the home Wi-Fi router. This action ensures maximum signal strength between the spa and your home’s Wi-Fi router.

  • Page 18: General Electrical Safety Instructions

    Nonetheless, this spa must be installed properly to ensure dependable usage. Please contact your local Jacuzzi dealer or local building department should you have any questions regarding your installation. Proper grounding is extremely important. Jacuzzi spas are equipped with a current collector system.
  • Page 19 4. The electrical supply for this product must include a suitably rated switch or circuit breaker to open all ungrounded supply conductors to comply with Section 422-20 of the National Electrical Code/USA, ANSI/NFPA 70. The disconnecting means must be readily accessible to the spa’s occupant but installed at least 5 feet (1.5m) from spa water.
  • Page 20 Power Supply Entrance(s) Heater 10. Spa Drain Valve CLEARRAY Water 11. Pump Drain Plugs(s) Purification System 12. BLUEWAVE 2.0 Wireless Stereo QuickDrain™ 13. Jacuzzi ProLink™ Module Jets Pump Figure 6.0d Terminal Block Connection Main Terminal Block Bonding Lug/Grounding Terminal Power wires Entrance...
  • Page 21 Figure 6.0e 1/4AT 250VAC Terminal Connections F7 30A (North American 60Hz 240 VAC Connection Shown) Red Black (Export 50Hz 230 VAC Connection Shown)* *Wire connections on circuit board must be changed, page 76. Single Service Blu Brn BREAKER TERMINAL (N1) (L1) SERVICE 1 CONNECTIONS...

  • Page 22: Power Requirements

    Power Requirements Jacuzzi ® spas are designed to provide optimum performance and flexibility of use when connected to their maximum electrical service. They are configured at the factory. The most common electrical connections are listed below. Reference page 73 for dip switch settings.

  • Page 23: Spa Fill Up Procedure

    Clear all debris from the spa. (Although the spa shell has been polished at the factory, you may want to treat it with a specially formulated spa cleaner.) Consult your authorized Jacuzzi dealer for additional information prior to filling spa.
  • Page 24 (see Section 11.2, page 32 to activate jets). 5. Add Start-Up Chemicals Add the spa water chemicals as recommended by your authorized Jacuzzi spa dealer. See Section titled “Water Quality Maintenance” (page 59) for general guidance. WARNING: RISK OF POISONING OR DEATH.
  • Page 25 7. Set Spa To Heat To warm spa water to a comfortable temperature, follow these steps: • The display on the control panel displays the actual temperature of the spa water. Tap to increase or decrease the water temperature in 1 degree increments. •...
  • Page 26 Fill Volume* Dichlor J-575........445 Gal (1,685 L) ........ 11.0 oz J-585........440 Gal (1,666 L) ........ 11.0 oz *Use average fill volume for chemical maintenance 2. Leave spa cover open during this step to allow excessive chemical vapors to exit spa, protecting pillows and plastic knobs from chemical attack.
  • Page 27 Water that is too soft can be corrosive to metal components. 5. Consult your authorized Jacuzzi dealer for chemical recommendations, then add chemicals to hot tub water to achieve a constant sanitizer reading within the levels recommended on the inside cover of this manual.

  • Page 28: Spa Features

    Spa Features J-575 Spa Features 1. Control Panel 13. RX Jets (6 ea.) 2. Air Control Valves (4 ea.) 14. FX Directional Jets (2 ea.) Introduce Air to Specified Jet 15. PX Jets (8 ea.) Groups 16. FX2-S Jets (6 ea.) 3.

  • Page 29: J-575 Massage/Waterfall Selector Diagram

    J-575 Massage/Waterfall Selector Diagram Massage Selectors (1-2) • Massage selector 1 diverts jets pump 1 output between jets groups 1a-1b. • Massage selector 2 diverts jets pump 2 output between jets groups 2a-2b. Waterfall Selectors (3-4) • Waterfall selector (3) controls circulation pump output to waterfall (3). •...

  • Page 30: J-575 Air Controls Diagram

    J-575 Air Controls Diagram Air Controls Operation • Toggle air controls 1-4 to add air to designated jet groups. Spa operation subject to change without notice Page 24...

  • Page 31: J-585 Spa Features

    J-585 Spa Features 1. Control Panel 15. PX Jets (2 ea.) 2. Air Control Valves (4 ea) 16. FX Small Jets (8 ea.) Introduce Air to Specified Jet 17. FX2S Jets (5 ea.) Groups 18. MX2 Jets (3 ea.) 3. Waterfall Control Valve 4.

  • Page 32: J-585 Massage/Waterfall Selector Diagram

    J-585 Massage/Waterfall Selector Diagram Massage Selectors (1-2) • Massage selector 1 diverts jets pump 1 output between jet groups 1a-1b. • Massage selector 2 diverts jets pump 2 output between jet groups 2a-2b. Waterfall Selectors (3-4) • Waterfall selector (3) controls circulation pump output to waterfall (3).

  • Page 33: J-585 Air Controls Diagram

    J-585 Air Controls Diagram Air Controls Operation • Toggle air controls 1-4 to add air to designated jet groups. Spa operation subject to change without notice Page 27...

  • Page 34: Registration And Start-Up

    North American models only. The passcode must be entered on the control panel in order to unlock the Registration Lockout screen, Figure 10.2c. Reminder Please register your spa at: www.jacuzzi.com Once registered, enter your spa serial # and registration passcode here: enter # later Figure 10.2a...
  • Page 35 Follow these steps to register your spa. Figure 10.2b 1. Using your home computer or other device, connect to the internet. 2. Go to www.Jacuzzi.com website to register your spa. 3. Click Outdoor Hot Tubs 4. Click For Owners 5. Click Warranty and Manuals 6.

  • Page 36: Protouch™ Glass Control Panel

    10.3 ProTouch™ Glass Control Panel Your Jacuzzi Spa is equipped with a state-of-the-art touch screen control panel. The control panel complements the contemporary and sleek design of your spa. Access to all menus can be achieved by using the touch screen. Programming features can be easily programmed with our user-friendly design.
  • Page 37 = Error Indicator Icon: Displays when there is error message that needs to be addressed. The icon will also appear under the Temperature reading as a reminder, page 65. = Invert Button: Tap to invert the display image. = Settings Button: Tap to access the programming and setting menus, page 40.

  • Page 38: Operating Instructions

    11.1 ProTouch™ Glass Control Panel Your Jacuzzi spa is equipped with a ProTouch Glass control panel; massage selectors, and air control knobs located on the top rim of the spa (pages 22-27). These controls let you operate many of the special functions of your Jacuzzi spa.

  • Page 39: Lights Menu

    11.3 Lights Menu From the Home Menu, (Figure 11.3a), tap to enter the Light submenus. The LCD screen will display the Light Submenu (Figure 11.3b). From this menu you can control the interior lighting, exterior lighting and experience effect. When you tap to enter the submenus, the lights will turn on, if not on already.

  • Page 40: Exterior Lights

    A. To control the intensity of the interior lights follow the steps below. 1. The “Bright” feature controls the intensity of the interior bright lights. Use to select your intensity level. The levels range from 5 to 0, as follows: 5 = 100%, Figure 11.4b 4 = 80%, 3 = 60%, 2 = 40%, 1 = 20% and 0 = 0%.

  • Page 41: Experience

    11.6 Experience LIGHTS The lighting experience can be user Experience enhanced by activating one of the settings quiet below. Just tap one of the words (Quiet, Fun, Glow or Joy) to start the experience, glow (Figure 11.6a). The default setting is “Glow.” 1.

  • Page 42: Bluetooth® Pairing Instructions

    = Auxiliary Settings: Tap to use your auxiliary device with the stereo. This is the default setting. = Audio Settings: Tap to access the audio submenu. = Forward: Tap to advance forward through tracks. = Rewind: Tap to move back through tracks. = Pause/Play: Tap to pause and play tracks.

  • Page 43: Audio Settings Menu

    11.9 Audio Settings Menu To enter the Audio Settings Menu, tap from the Music submenu, Figure 11.9a. The display will change to Figure 11.9b. The Audio Settings menu offers an enhanced audio experience by providing a custom or preset bass and treble settings. MUSIC Audio + Bass...

  • Page 44: Clearray On Demand

    Certain jet systems have their own air control. Each control introduces air into the water lines that supply that specific jet group (pages 22-27). Simply press any air control button, Jacuzzi logo side down, to open or press the opposite side to button to close. To minimize heat loss, all air controls should be closed when the spa is not in use.

  • Page 45: Selecting The Desired Massage Action

    11.16 Selecting the Desired Massage Action Your Jacuzzi spa is equipped to allow you to customize the massage action you desire. Each model incorporates a massage selector that allows you to customize the massage and performance by diverting water between various jet systems.

  • Page 46: Programming Instructions

    12.0 Programming Instructions Your Jacuzzi spa is equipped with setting menus that allow you to pro- gram and activate different components of the spa. With our ProTouch™ Glass control panel, programming your spa has never been easier. In the sections that follow, we will guide you through the process of program- ming the spa to fit your personal comfort.

  • Page 47: Programming The Heating Mode

    12.1 Programming the Heating Mode Your Jacuzzi spa is equipped with 3 modes of heating, Figure 12.1a. An automatic mode called “Auto,” where the spa’s temperature is maintained at all times. An energy saving heating cycle called “Econo.” A mode that will only activate the heater during the daytime called “Day”...
  • Page 48 During a primary filtration, the circulation pump, CLEARRAY and ozone unit (if applicable) are activated. The factory default cycle starts at 12:00 AM and last for 8 hours. If you elect to keep this setting, then you can skip this section. In extreme bitter cold weather we recommend you program the circulation pump to run 24 hours.

  • Page 49: Programming The Secondary Filter

    12.3 Programming the Secondary Filter To enter the Secondary Filter program, Secondary Filter > from the heat and filter menu, Figure Infrequent 12.2b. The display will change to Figure 12.3a. During a secondary filtration, the Jets Frequent Pump 1 is activated. There are 3 cycles you can select from, Figure 12.3a.

  • Page 50: Water Care Programming

    12.6 Water Care Programming Water care is crucial to maintaining a healthy and clean spa. The CLEARRAY water purification system leads the way by sanitizing the water using a UV light bulb. Your spa can be programmed to remind you when to check and replace certain components.
  • Page 51 B. Programming the ProClarity/ProClear Filter Timer A programmable filter timer can be set to remind you when to clean or replace the filters and skimmer bag. 1. When you enter the “Water Care” Water Care > > Menu, Figure 12.6c, tap until you >...

  • Page 52: Locking The Spa

    D. Programming the Water Change Timer A programmable “Water Refresh” reminder can be set to remind you when to drain and refill the spa. 1. While in the “Water Care” Menu, Figure Water Care > > 12.6e, tap until you reach the >...
  • Page 53 A. Temp Lock: LOCK 1. Tap Temp to lock the temperature temp service feature, Figure 12.7c. set lock level 0000 2. Use the scroll wheel to assign a 0000 4-digit lock and unlock code by sliding your finger to change the numbers. unlock lock 3.

  • Page 54: Programming The Time And Date

    12.8 Programming the Time and Date > From the “Settings” menu, tap next to “Time & Date” to enter the programming options, Figures 12.8a and 12.8b. SETTINGS Time & Date Time Date > Lock 6:45p 01/01/2015 8 00 > Time & Date >...

  • Page 55: Wi-Fi Setup

    1. There are 4 languages to select from: English, French, Deutsch, and Spanish. To view the selections, use the scroll wheel to move up and down. To select a language, tap next to the language you want to display, Figure 12.9c. LANGUAGE LANGUAGE English...

  • Page 56: System Information

    System and Wi-Fi Router Requirements a. The hardware for the Jacuzzi ProLink™ communicates over a 2.4 GHz home network supporting 802.11b/g wireless technology. The hardware does not support 5 GHz networks. • If you have 2 Wi-Fi networks, one at 2.4 GHz and the other at 5 GHz, then make sure that your smart phone is connected to the 2.4 GHz...

  • Page 57: Spa Maintenance

    13.0 Spa Maintenance Proper and regular maintenance of your spa will help it retain its beauty and performance. Your authorized Jacuzzi dealer can supply you with all the information, supplies, and accessory products you will need to accomplish this. DANGER:...
  • Page 58 A. Cleaning the filters and filter bag To ensure optimum performance 1. The ProClarity™ filter cartridge (A) must be cleaned every month and replaced every 18 months. 2. The ProClarity Depth filter (B) must be replaced every 3 months. 3. The ProClarity filter canister (C) can be rinsed when the filters are cleaned.
  • Page 59 Cartridge 1 Remove the filter pins If used, remove the Lift unthreaded filter in order to separate chemical feeder as cartridge from skimmer the ProClarity filter and instructed prior to rinsing well. the filter cartridge. Rinse canister. debris from filter pleats using a garden hose and high-pressure nozzle.
  • Page 60 Trapped Bubbles Debris Submerge both filter Place each cartridge Install clean debris bag cartridges in spa. Tilt back into skimmer back onto the filter cover threaded end upward well, then rotated clips as shown (you can to remove trapped air each cartridge handle flip the filter skimmer bubbles, then keep...

  • Page 61: Draining And Refilling

    During this time, it is also recommended that you use Jacuzzi’s Jet Line Cleaner to clean the internal plumbing lines from buildup and debris.

  • Page 62: Cleaning The Spa Interior

    If you are not certain as to the suitability of a particular cleanser, consult your authorized Jacuzzi dealer. We recommend using Jacuzzi’s Spa All Purpose Cleaner to clean the spa’s interior surface. Use extreme care to assure that no soap residue is left on the surface.

  • Page 63: Pillow Care

    “skin” is attractive and durable. Regular monthly cleaning and conditioning (vinyl) is strongly recommended and may increase the longevity of your cover. Jacuzzi chemicals are for use in the U.S. only. A. To Clean and Condition the Cover 1. Use a garden hose to loosen debris and dirt.

  • Page 64: Winterizing

    13.8 Winterizing Your Jacuzzi spa is designed to automatically protect itself against freezing when operating properly. During periods of severe freezing temperatures, you should check periodically to be certain that the electrical supply to the spa has not been interrupted. In extreme, bitter cold weather (less than 0°C) we recommend that the circulation pump is...

  • Page 65: Restarting Your Spa In Cold Weather

    11. Re-install cabinet side panels and cover spa so that no casual moisture can enter into it. Consult your Jacuzzi dealer if you have any questions regarding winter use or winterizing. 13.9...

  • Page 66: Ph Control

    That is why almost all spa water test kits contain a measure for pH as well as sanitizer. Jacuzzi offers products that help you maintain the ideal range. These chemicals are for use in the U.S.

  • Page 67: Other Additives

    With our chemical products your authorized Jacuzzi dealer can advise you on the use of these additives. Jacuzzi chemicals are for use in the U.S. only. 14.4 CLEARRAY® (Ultraviolet) Water Purification System...

  • Page 68: Clearray® Bulb Replacement And Quartz Tube Maintenance

    WARNINGS: • Do not operate the UV-C emitter when it is removed from the appli- ance enclosure. • This appliance contains a UV-C emitter. • Unintended use of the appliance or damage to the housing may result in the escape of dangerous UV-C radiation. UV-C radiation may, even in little doses, cause harm to the eyes and skin.
  • Page 69 2. Once the UV bulb has cooled off remove the CLEARRAY System enclosure cover (2) by removing the four screws (1). This will expose the UV bulb and connections, Figure 14.5b. Figure 14.5b DANGER: NEVER REMOVE COVER WITHOUT FIRST TURNING OFF AT POWER SOURCE AND DRAINING THE SPA.
  • Page 70 13. System Test 2: Reconnect the CLEARRAY unit to the controller. Turn breaker back ON. Turn on the pump to circulate the water through the CLEARRAY System. Wait for 5 minutes and assure no water is dripping. If water is visible, STOP, fix the leak by repeating quartz tube maintenance process from step 1 through step 12.

  • Page 71: Error/Display Messages

    15.0 Error/Display Messages There are a number of unique functions designed into your Jacuzzi spa to protect it from damage and/or to aid in troubleshooting. When an error occurs the spa will notify you by showing the screen below and an error code, Figure 15.0a.
  • Page 72 8. Open Ambient Temp Sensor: The temperature sensor is not functional. Heater is disabled. This must be repaired only by a qualified authorized service organization or service technician. Monitors the controller temperature. 9. Closed Flow Switch on Start-up: Flow switch is non-functional. Closed or shorted flow switch on system start-up (system disabled).
  • Page 73 15. Watchdog Freeze Protection: Spa water is below 40°F/4.4°C. Jet pumps operate until the spa is out of danger. Contact your authorized dealer or service organization. Note: The heater icon will be blinking and the error icon will be displayed under the temperature. 16.

  • Page 74: Troubleshooting Procedures

    16.0 Troubleshooting Procedures In the unlikely event your spa is not working the way you believe it should, please first review all the installation and operating instructions in this manual and check the message on the panel display; second, if you are still not satisfied it is working properly, please follow the appropriate troubleshooting instructions.
  • Page 75 Your input as a Jacuzzi spa owner is a cherished part of this process. If you have any comments or suggestions, or if you wish to be informed on any new products for your spa, please write to us.

  • Page 76: Typical Spa Wiring Diagrams

    17.0 Typical Spa Wiring Diagrams 17.1 Wiring diagram for North American 60 Hz Models Only 2-Pole Circuit Breaker with 2-Wire Grounded Load Connection (3 Wires to Hot Tub, 2-Hot (L1-L2), 1-Ground) 240 VAC Ground/Bonding Lug** White (N) Black (L1) 2-Pole GFCI Red (L2) Breaker...

  • Page 77: Circuit Board Wiring Diagrams

    18.0 Circuit Board Wiring Diagrams 18.1 Domestic 60Hz Wiring Diagram LIGHTING EXPANSION BLUEWAVE WATER STEREO SENSOR CONTROL PANEL (OPTIONAL) WI-FI FLOW SENSOR FOOTWELL LIGHT AUX SENSORS SERIAL ADCM WATER TEMP HI-LIMIT TEMP see section 18.3 for dip switch settings CIRC PUMP PUMP 1 F2 1/4AT 250VAC F7 30A...

  • Page 78: Export 50Hz Wiring Diagram

    18.2 Export 50Hz Wiring Diagram Dual service shown. LIGHTING EXPANSION BLUEWAVE WATER STEREO SENSOR FOOTWELL FLOW SENSOR (OPTIONAL) WI-FI LIGHT CONTROL PANEL AUX SENSORS WATER TEMP HI-LIMIT TEMP see section 18.3 for dip switch settings CIRC PUMP PUMP 1 F2 1/4AT 250VAC 230 VAC 1X16A/1x20A, (1X20A, 1X32A F7 30A...

  • Page 79: Dip Switch Settings

    18.3 Dip Switch Settings The dip switches are at the S1 location on the board. A. Switch settings for Domestic 60Hz Models DOMESTIC DIP SWITCH SETTINGS S1 LOCATION (factory default) DIP SWITCH NUMBER BREAKER OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF 50A* OFF OFF ON OFF OFF OFF OFF OFF OFF OFF...
  • Page 80 Single Service 1x20A This setting will turn the heater off any time either one of the pumps are activated. 1x32A This setting is for all two pump model spas. Both pumps and the heater will be allowed to operate at the same time.

  • Page 81: Dual Service 50Hz Connection

    18.4 Dual Service 50Hz Connection The factory setting for export models is for dual service breakers. The jumper wiring is shown below. The extra White wire is not used for this setting. PARTIAL VIEW OF THE CIRCUIT BOARD DUAL SERVICE Terminal Breaker at location: Heater/Transformer (Service 1) All other components (Service 2)

  • Page 82: Single Service 50Hz Connection

    18.5 Single Service 50Hz Connection An optional setting for export models is for a single service breaker. The jumper wiring is shown below. Additionally, the included extra White wire (1*) must be installed. PARTIAL VIEW OF THE CIRCUIT BOARD SINGLE SERVICE Terminal Breaker at location: All components (Service 1)

  • Page 83: Three Phase Service 50Hz Connection

    18.6 Three Phase Service 50Hz Connection Optional three-service breaker for export models. The jumper wiring is shown below. The extra White wire is not used for this setting. Terminal Breaker at location: Heater/Transformer (Service 1) Pump 2 (Service 2) Pump 1 and all other components (Service 3) JUMPER WIRING Two Phase Connection Wiring Wire...
