c. Measure the air induction system solenoid re-
sistance.
EAS2&'11
CHECKING THE INTAKE AIR PRESSURE
SENSOR
1. Check:
• Intake air pressu re sensor output voltage
Out of specification
->
Replace.
Intake air pressure sensor output
voltage
3.57-3.71 V@101.3 kPa
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Connect the test harness
S-
pressure sensor
(3P) "1" to the intake air pressure sensor and
wire harness as shown.
£CA1RCl &OS
NOTICE
~~~~~~~~~~~~~
Pay attention to the installing direction of the
test harness S- pressure sensor (3P) cou-
pler.
b. Connect the digital circuit tester (DCV) to the
test harness
S-
pressure sensor (3P).
Digital circuit tester
90890-031 74
Model 88 Multlmeter with tachom-
eter
YU-A1927
Test harness S- pressure sensor
(3P)
90890-03207
YU-03207
• Positive tester probe
pink (wire harness color) (intake air pres-
sure sensor 1)
pink/white (wire harness color) (intake air
pressure sensor 2)
• Negative tester probe
black/bl ue (wire harness color)
ELECTRICAL COMPONENTS
\
A. Intake air pressure sensor 1
B.
Intake air pressure sensor
2
c. Set the main switch to "ON".
d. Measure the intake air pressure sensor out-
put voltage.
••••••••••••••••••••••••••••••••
....,..,.
CHECKING THE INTAKE AIR
TEMPERATURE SENSOR
1. Remove:
• Intake air temperature sensor
EW"14110
A wARNING
• Handle the Intake air temperature sensor
with special care.
• Never subject the Intake air temperature
sensor to strong shocks. If the intake air
temperature sensor is dropped, replace it.
2 . Check:
• Intake air temperature sensor resistance
Out of specification -> Replace.
Intake air temperature sensor re-
sistance
540~6oo n @o
0
c
(32 °F)
290-390 n@ 8o
•c
(176 °F)
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Connect the pocket tester (n x 100) to the in-
take air temperature sensor terminal as
shown.
8-109
