PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number
is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see whether it has been
preassembled.
NO 59*2
NO 83*4
NO 26*2
NO 29*2
NO 30*2
NO 51*2
NO 13*3 NO 22*3 NO 34*3
ASSEMBLY
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• Left and right parts are marked "L" or "Left" and "R"
or "Right."
• To identify small parts, see page 19
• As you assemble the exercice bike, use the draw-
ings below to identify small parts. The number in
parentheses below each drawing is the key number
NO 33*6
NO 34*6
NO 22*6
NO 91*1
NO 21*4 NO 22*4 NO 23*4
of the part, from the PART LIST near the end of this
manual. The number following the parentheses is
the quantity needed for assembly.
• In addition to the included tool(s), assembly requires
the following tools:
• one adjustable wrench
• one Phillips screwdriver
• Note: If a part is not in the hardware kit, check to
see if it has been preassembled.
5
NO 14*2
NO 16*2
NO 92*1
NO 39*6 NO 40*6 NO 22*6
NO 19*2
NO 14*2
NO 16*2
