Step 5: Connect Power to the ACX Series Router

Depending on your configuration, your router uses either AC or DC power supplies. Perform

the appropriate procedures for each power supply in your router.

WARNING:

You must ground the router before connecting the power cables.

Connect AC Power to an AC-Powered ACX4000 Router on page 13

Connect DC Power to a DC-Powered ACX4000 Router on page 14

To connect power to the AC-powered router, you need the following tools:

AC power cords with C15 plugs

Locate power cords that have a plug appropriate for your geographical location. For

more information, see the

Attach an ESD grounding strap to your bare wrist and connect the strap to one of the

ESD points on the chassis.

Insert the appliance coupler end of the power cord into the appliance inlet on the

power supply.

Insert the power cord plug into an external AC power source receptacle.

NOTE:

Each power supply must be connected to a dedicated AC power

feed and a dedicated customer site circuit breaker. We recommend that

you use a dedicated customer site circuit breaker rated for 4 A (100 VAC),

or as required by local code.

Dress the power cord appropriately. Verify that the power cord does not block the air

exhaust and access to router components, or drape where people could trip on it.

Repeat Step

through Step

Observe the status LED on the power supply faceplate. If an AC power supply is

correctly installed and is functioning normally, the status LED lights green steadily.

If the status LED is not lit or red, the power supply is not functioning normally. Repeat

the cabling procedures.

Step 5: Connect Power to the ACX Series Router

ACX4000 Universal Access Routers Hardware Guide

for the remaining power supply.
