Specifications - Stihl MS 200 Instruction Manual

Specifications

EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
A = 300 hours
B = 125 hours
C = 50 hours
Engine
STIHL single cylinder two-stroke engine
Displacement: 35.2 cm
Bore: 40 mm
Stroke: 28 mm
Engine power to 1.6 kW (2.2 HP)
ISO 7293: at 10,000 rpm
Idle speed: 2,800 rpm
Max. permissible
engine speed with bar
and chain: 14,000 rpm
Ignition System
Electronic magneto ignition
(breakerless)
Spark plug (resistor Bosch WSR 6 F
type): ,
NGK BPMR 7 A
Electrode gap: 0.5 mm
MS 200
This spark ignition system meets all
requrements of the Canadian
Interference-Causing Equipment
Regulations ICES-002.
Fuel System
All position diaphragm carburetor with
integral fuel pump
Fuel tank capacity:
Chain Lubrication
Fully automatic, speed-controlled oil
pump with rotary piston. Additional
manual oil flow control
Oil tank capacity:
Weight
3
dry, without bar and chain:
Cutting Attachment
STIHL cutting attachments complying
with CSA Standard Z 62.3:
Rollomatic guide bars
Bar lengths (3/8" P
pitch):
Groove width:
3/8" Picco chains
Picco Micro Comfort 3 (63 PMC3)
Picco Duro 3 (63 PD3)
Pitch:
Drive link gauge:
Chain sprocket
6-tooth for 3/8" P (spur sprocket)
0.37 l
Other cutting attachments
Other cutting attachments complying
with CSA Standard Z 62.3 are available:
see section CSA-Standard Z 62.3,
"Chain Leaflet" inside chain box or
contact your local STIHL dealer.
0.24 l Please ask your STIHL dealer to
properly match your powerhead with the
appropriate bar/chain combinations to
reduce the risk of kickback injury.
3.8 kg
12", 14", 16", 18"
1.3 mm
English
3/8" P
(9.32 mm)
1.3 mm
41
