Summary of Contents for AEG L 98699 FL

  • Page 1 EN User manual L 98699 FL...

  • Page 2: Table Of Contents

    13. INSTALLATION ............30 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler –...

  • Page 3: Safety Information

    ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, careful- ly read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use cau- ses injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.

  • Page 4: Safety Instructions

    • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly quali- fied persons in order to avoid a hazard. • The operating water pressure (minimum and maxi- mum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa) •...

  • Page 5: Technical Information

    ENGLISH Water connection • Before maintenance, deactivate the appliance and disconnect the mains • Make sure not to cause damage to the plug from the mains socket. water hoses. • Do not use water spray and steam to • The appliance is to be connected to clean the appliance.

  • Page 6: Product Description

    Electrical connection: Voltage 220-240 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, ex- cept where the low voltage equipment has no pro-...

  • Page 7: Control Panel

    ENGLISH Spanner To remove the transit bolts. Plastic caps To close the holes on the rear side of the cabinet after the removal of the transit bolts. Sound barrier To decrease the noise while the ap- pliance operates. Plastic hose guide To connect the drain hose on the edge of a sink.
  • Page 8 Spin reduction touch button • You do not use the appliance for 5 mi- nutes before you press button Temperature touch button – All settings are cancelled. – Press button 5.1 TOUCH SCREEN to activate the ap- pliance again.
  • Page 9 ENGLISH • The time of the day When you activate the appliance the display shows the time of the day for some seconds. To adjust the clock, refer to "Clock setting". • The programme duration When the washing programme starts, the programme time decrea- ses every minute.

  • Page 10: Delay Start Button

    10 www.aeg.com Extra rinsing The indicator bar fills accordingly the numbers of rinses. Stains Prewash Soak The indicator bar fills accordingly to the set functions. The default spin speed of the programme. _ _ _ No spin Rinse hold 1) Only available for Spin/Drain programme.

  • Page 11: Extra Rinse Button

    ENGLISH 5.10 EXTRA RINSE BUTTON the water when the programme is completed. 5.16 TEMPERATURE BUTTON Touch button to add rinsing phases to a programme. Use this function for persons allergic to detergents and in areas where the water Touch button to change the default is soft.

  • Page 12: Programmes

    12 www.aeg.com • To deactivate the function touch but- and button at the same time until the symbol goes off. 6. PROGRAMMES Programme Tempera- Type of load Programme Functions ture Weight of load description Cottons 95° - Cold White and col-...
  • Page 13 ENGLISH Programme Tempera- Type of load Programme Functions ture Weight of load description Wool / Silk 40° - Cold Machine washa- Wash Spin Reduc- Rinses ble wool as well Rinses tion Short spin as for hand Short spin Rinse Hold washable wool- lens and delicate fabrics with...
  • Page 14 14 www.aeg.com Programme Tempera- Type of load Programme Functions ture Weight of load description 20 Min. - 3 40° or 30° Quick wash of Wash Spin Reduc- sport items or Rinses tion cotton and syn- Short spin thetic items, lightly soiled or worn once.

  • Page 15: Consumption Values

    ENGLISH Cotton and synthetic items. up to Steam Refresh 1,5 Kg This cycle removes odour from the laundry. Steam does not re- move animal odours. Cotton and synthetic items. up to Steam Anticrease 1,5 Kg This programme helps to dew- rinkle the laundry.

  • Page 16: Before First Use

    16 www.aeg.com Programmes Load Energy Water con- Approxi- Remain- (Kg) consump- sumption mate pro- ing mois- tion (kWh) (litre) gramme ture (%) duration (minutes) Cottons 60 °C Cottons 40 °C Synthetics 40 °C Delicates 40 °C Wool/Hand 0.35 wash 30 °C...

  • Page 17: Using The Appliance

    ENGLISH 8.2 Clock setting The hour digits flash. Turn the programme knob to After you set the language, the display change the hour. tells to set the clock: Touch button to confirm the se- • The hour digits flash. lection. •...

  • Page 18: Filling The Detergent And Additives

    18 www.aeg.com If you put more laundry than the Close the door. The text bar on the maximum load, the display tells display tells the percentage of deter- that you put more than the maxi- gent to use. This data is indicative mum load.
  • Page 19 ENGLISH This is the maximum level for the quantity of liquid additives. The compartment for the stain remover. Put the product in the compartment and set the stain function before you start the programme. Flap for powder or liquid detergent Turn it (up or down) in the correct position to use powder or liq- uid detergent.

  • Page 20: Starting The Programme

    20 www.aeg.com Measure out the detergent and the fabric conditioner. Carefully close the detergent dis- penser. Make sure that the flap does not cause a blockage when you close the drawer. 9.4 Set the delay start 9.7 Cancel a programme...

  • Page 21: Hints And Tips

    ENGLISH If you deactivate the appliance, it Keep the door ajar, to prevent mil- is necessary to set the pro- dew and odours. gramme again. Close the water tap. The washing programme is 9.10 At the end of the completed, but there is water in the programme drum: –...

  • Page 22: Care And Cleaning

    22 www.aeg.com 10.2 Stubborn stains • If your appliance has not the deter- gent dispenser with the flap device, For some stains, water and detergent is add the liquid detergents with a dos- not sufficient. ing ball. We recommend that you remove these stains before you put the items in the 10.4 Water hardness...

  • Page 23: Door Seal

    ENGLISH CAUTION! • Empty the laundry from the drum. Do not use alcohol, solvents or • Set the hottest cotton wash pro- chemical products. gramme • Use a correct quantity of powder de- 11.3 Maintenance wash tergent with biological properties. After each wash, keep the door open for With the low temperature programmes it a while to prevent mould and to let un-...
  • Page 24 24 www.aeg.com Remove the top part of the liquid additive compartment. Clean all the parts with water. Clean the dispenser recess with a brush. Put back the dispenser in the recess. • The display shows an alarm code be- 11.7 Drain pump cause of the problem with water drain.
  • Page 25 ENGLISH Put a container below the recess of the drain pump to collect the water that flows out. Press the two levers and pull for- ward the drainage duct to let the water flow out. When the container is full of water, put the drainage duct back again and empty the container.

  • Page 26: Emergency Drain

    26 www.aeg.com To clean the water inlet filters: Close the water tap. Remove the water inlet hose from the water tap. Clean the filter in the inlet hose with a stiff brush. Remove the inlet hose behind the appliance. Clean the filter in the valve with a stiff brush or a towel.

  • Page 27: Troubleshooting

    ENGLISH 12. TROUBLESHOOTING The start of the appliance does not oc- WARNING! cur or it stops during operation. Deactivate the appliance before Try to find a solution to the problem be- you do the checks. fore you contact the service centre (refer to the table).
  • Page 28 28 www.aeg.com PROBLEM WITHOUT ALARM MESSAGE Problem Possible cause Possible solution The appliance A washing programme Set the drain programme. does not drain without the drain phase the water. is set. The function Rinse Hold Set the drain programme. is on.
  • Page 29 ENGLISH Problem Possible cause Possible solution You did not remove the Remove the packaging and/or packaging and/or the the transit bolts. Refer to 'Instal- transit bolts. lation'. The load is very small. Add more laundry in the drum. The appliance The end of the drain Make sure that the drain hose is fills with water...

  • Page 30: Installation

    30 www.aeg.com 13. INSTALLATION 13.1 Fixing plate kit If you install the appliance on a plinth, secure the appliance in the fixing plates. (4055171146) Follow the instructions supplied with the kit. Available from your authorized dealer. 13.2 Unpacking Use the gloves. Remove the external film.
  • Page 31 ENGLISH Open the door. Remove the poly- styrene piece from the door seal and all the items from the drum. Put one of the polystyrene packag- ing elements on the floor behind the appliance. Carefully put down the appliance with the rear side on it.
  • Page 32 32 www.aeg.com Make sure to identify the different sizes and the positions of the sound barriers. Refer to the illustration: A (FRONT) = Front of the appliance B (BACK) = Rear of the appliance – Remove the adhesive strip from the silent barriers.

  • Page 33: Positioning And Levelling

    ENGLISH Turn the three bolts with the key supplied with the appliance. Pull out the plastic spacers. Put the plastic caps in the holes. You can find these caps in the user manual bag. WARNING! We recommend that you keep Remove all the packaging and the packaging and the transit the transit bolts before you install...
  • Page 34 34 www.aeg.com • The appliance must be level and sta- ble. CAUTION! Installation on suspended Do not put cardboard, wood or flooring equivalent materials below the appliance feet to adjust the level. Suspended wooden floors are particular- ly susceptible to vibration. To help pre-...

  • Page 35: Water Pressure

    ENGLISH • Connect the water inlet hose to the cold water tap with 3/4 thread. CAUTION! Make sure that there are no leaks from the couplings. Do not use an extension hose if If you can not connect the water inlet the inlet hose is too short.
  • Page 36 36 www.aeg.com • On the edge of a sink. • Make sure that the plastic guide can- not move when the appliance drains. Attach the guide to the water tap or the wall. • To a stand pipe with vent-hole.

  • Page 37: In The Interest Of The Environment

    ENGLISH • Directly to a built-in drain pipe in the room wall and tighten it with a clip. You can extend the drain hose to maximum 400 cm. Contact the service centre for the other drain hose and the extension. 13.6 In the interest of the environment •...
  • Page 38 38 www.aeg.com...
  • Page 39 ENGLISH...
  • Page 40 www.aeg.com/shop...
