Anti-trap windows

Anti-trap windows are designed to prevent
objects from getting caught between the
glass and the seal when the electric
window is closed. Upon sensing an
obstruction, the window automatically
re-opens and allows the trapped object to
be removed.

Safety Mode

WARNINGS
The anti-trap function is not active
during this procedure.
While you close the window
(auto-up) for the third time with the
obstacle in the way, the anti-trap
function is disabled. Make sure there are
no obstacles in the way of the closing
window.
If the system detects a malfunction, it
enters a safety mode. The windows will
move for only about 0.8 seconds at a time
and then stop again. Close the windows
by lifting the switch again when the
windows stop moving. Have this checked
immediately.

Bounce-Back

The window will stop automatically while
closing. It will reverse some distance if
there is an obstacle in the way.

Overriding the Bounce-Back Feature

WARNING
When you override the bounce-back
feature the window will not reverse
if it detects an obstacle. Take care
when closing the windows to avoid
personal injury.
Endeavour (TEC), EB3B-19G219-ZCA enIND
Windows and Mirrors
58
Proceed as follows to override this
protection feature when there is a
resistance, for example in winter:
1. Close the window twice until it reaches
the point of resistance and let it
reverse.
2. Close the window a third time to the
point of resistance.
Note: This operation should occur within
two seconds after the window reaches the
reversing end position.
3. The bounce-back feature is now
disabled and you can close the window
manually. The window will go past the
point of resistance and you can close
it fully.
See an authorized dealer as soon as
possible if the window does not close after
the third attempt.
Resetting the Bounce-Back Feature
WARNING
The bounce-back feature remains
turned off until you reset the
memory.
If you have disconnected the battery, you
must reset the bounce-back memory
separately for each window.
1. Lift and hold the switch until the
window is fully closed.
2. Release the switch.
3. Lift the switch again for one more
second.
4. Press and hold the switch until the
window is fully open.
5. Release the switch.
6. Lift and hold the switch until the
window is fully closed.
7. Open the window and then try to close
it automatically.
