Ford RANGER Owner's Manual page 64

Door Ajar Indicator
It will illuminate when the
ignition is on and any door is not
completely closed.
Engine Coolant Temperature
Warning Lamp
It will illuminate when the engine
or motor coolant temperature is
high. Stop your vehicle as soon
as possible and contact your authorized
dealer.
Engine Oil Warning Lamp
WARNING
If it illuminates when you are driving
do not continue your journey, even if
the oil level is correct. Have your
vehicle checked.
If it illuminates with the engine
running or when you are driving,
this indicates a malfunction.
Stop your vehicle as soon as it is safe to
do so and switch the engine off. Check the
engine oil level.
Electronic Locking Differential
Illuminates when using the
electronic locking differential.
E163170
Fasten Seatbelt Warning Lamp
It will illuminate and a chime will
sound to remind you to fasten
your seatbelt. See Seatbelt
Reminder (page 24).
Instrument Cluster
62
Four-Wheel Drive Indicators
Equipped)
4X4 LOW
Illuminates when four-wheel
drive low is engaged.
E181780
4X4 HIGH
Illuminates when four-wheel
drive high is engaged.
E181779
Front Airbag Warning Lamp
If the warning lamp does not
illuminate during start up,
remains on or flashes, the
system may be disabled.
Have your vehicle checked by an
authorized dealer.
Front Fog Lamps Indicator
It will illuminate when you switch
the front fog lamps on.
Frost Warning Lamp
WARNING
Even if the temperature rises to
above 4°C there is no guarantee that
the road is free of hazards caused by
inclement weather.
It will illuminate when the
outside air temperature is 4°C or
below.
Glow Plug Indicator
With the key in the on position,
illuminates when the glow plug
heat is necessary as a starting
aid. Wait until the light goes off before
starting.
(If
