INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Radiance
Vent Free Gas Heater
®
Installation and Operating Instructions
Models: 0003380, 0003381
INSTALLER / CONSUMER SAFETY INFORMATION
Please read this manual before installing and using
appliance.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (Oxygen)
from the room in which it is installed. Provisions for
adequate combustion and ventilation air must be
provided. Refer to Page 7.
30005056_R10 • 05/15
Advertisement
Table of Contents
Related Manuals for Vermont Castings 0003380
Summary of Contents for Vermont Castings 0003380
-
Page 1: Installation And Operating Instructions
Radiance Vent Free Gas Heater ® Installation and Operating Instructions Models: 0003380, 0003381 INSTALLER / CONSUMER SAFETY INFORMATION Please read this manual before installing and using appliance. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 2: Table Of Contents
Table Of Contents PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Vermont Castings stove. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Installation And Operating Instructions
Radiance Vent-Free Gas Heater ® Installation & Operating Instructions In order to ensure safe and effective installation, this unit must be CARBON MONOXIDE POISONING MAY LEAD TO installed only by a qualified agency, individual, firm, corporation DEATH! or company that is experienced in the installation, repair and servicing of this type of appliance and is familiar with the building Carbon Monoxide Poisoning: Early signs of carbon codes and installation techniques appropriate in your area. -
Page 4: Stove Dimensions
Radiance Vent-Free Gas Heater ® Radiance Vent Free Gas Heater Dimensions 29³⁄₄" (756mm) R A D I A N C E 28¹⁄₄" (717mm) 6¹⁄₂" Supply Inlet (165mm) 11" (279mm) 31" (787mm) 18³⁄₈" (465mm) Drawing Not to Scale Fig. 1 - Radiance Vent Free dimensions. 4555 RUVSOD specs 7/01... -
Page 5: Clearance Requirements
Radiance Vent-Free Gas Heater ® Clearance Requirements Minimum Clearances to Combustible Materials Maintain clearance, (empty space), between combustible materials and the heater as specified below. Wall A: Ceiling ..........32” (813 mm) B: Side Wall .......... 4” (102 mm) Mantel Mantel from C: Rear Wall ......... -
Page 6: Gas Specifications
Radiance Vent-Free Gas Heater ® High Elevations Gas Specifications Input ratings are shown in BTU per hour and are certified without deration from elevations up to 4,500 feet (1,370 m) above sea level. Input Input Shutter Model Fuel Control BTU/h BTU/h Setting Nuisance outages may occur at altitudes above 4,500 feet... -
Page 7: Vent Free Features
Radiance Vent-Free Gas Heater ® Vent Free Features Modern construction standards have resulted in homes that The Radiance Vent Free stove, is an unvented gas heating are highly energy-efficient and that allow little heat loss. appliance tested and listed to the ANSI standard Z21.11.2 Your home needs to breathe, however, and all fuel-burning Latest Edition. -
Page 8: Assembly Procedures
Radiance Vent-Free Gas Heater ® Assembly Procedures Read these instructions thoroughly before starting the Remove the Front, Screen and Logs assembly. Follow procedures in the order given. Inspect Remove the Front panel, the Screen panel, the Log Set and the stove for damage before starting the assembly. Do hardware bag from the firebox before positioning the stove. -
Page 9: Assemble Legs
Radiance Vent-Free Gas Heater ® Assemble the Legs 6. Remove pallet and allow stove to gently rest on all four 1. Slide stove to the rear of the pallet just far enough to legs. access rear leg holes. Make sure the stove does not tip 7. - Page 10 Radiance Vent-Free Gas Heater ® 4. Attach the fan assembly to the fan bracket provided in the 6. Position the fan assembly so the ducts slide between the log box. Use #10 sheet metal screws provided with fan inner and outer shroud. The inner shroud should engage kit.
- Page 11 Radiance Vent-Free Gas Heater ® 11. The rheostat control switch attaches to the left side of the WARNING valve bracket at the front of the stove. (Fig. 13) • Remove retaining nut from shaft of rheostat. (if pre- The optional fan kit is equipped with a three-prong installed) (grounding) plug for your protection against shock hazard •...
-
Page 12: Install On/Off Switch
Radiance Vent-Free Gas Heater ® Install ON/OFF Switch On/Off Switch Wiring The switch assembly parts are found in the parts bag. 1. Attach switch assembly to left rear side of stove shroud using two screws and existing holes in shroud. (Fig. 15) 2. -
Page 13: Connect The Gas Supply Line
Radiance Vent-Free Gas Heater ® Connect the Gas Supply Line CAUTION Check the Rating Plate attached by a steel cable to the firebox, to confirm that you have the appropriate firebox for the type of fuel to be used. This appliance should only be connected by a qualified gas technician. -
Page 14: Complete The Installation
Radiance Vent-Free Gas Heater ® Complete the Installation Right Log 1. Replace the screen frame by sliding the hooks over the Right Rear Log top front edge of the firebox and resting the bottom on Left Rear Log the support brackets. Swing the top edge of the assembly toward the firebox, and center it. -
Page 15: Operation
Radiance Vent-Free Gas Heater ® Operation The Radiance is shipped with the operable door front plate. The stove may be operated with the doors either open or closed. To open the front doors, insert the handle provided into the door latch stub and turn it to the right and up. (Fig. 22) When not in use, the handle may be stored in the handle holder on the right side of the rear shroud. -
Page 16: Lighting Instructions
Radiance Vent-Free Gas Heater ® Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manually. When •... -
Page 17: Troubleshooting
Radiance Vent-Free Gas Heater ® Troubleshooting Follow these procedures in the order presented. WARNING Turn off heater and allow to cool completely before servicing. CONDITION POSSIBLE CAUSE SOLUTION No spark at pilot when Ignitor is 1. Ignition Electrode is disconnected 1. - Page 18 Radiance Vent-Free Gas Heater ® Troubleshooting cont’d. SOLUTION CONDITION POSSIBLE CAUSE Pilot lights but flame goes out 1. Control Knob not fully depressed 1. Depress Control Knob fully and when Control Knob is released. or held in long enough. hold in for a full 30 seconds. 2.
-
Page 19: Maintenance
Radiance Vent-Free Gas Heater ® Maintenance The following procedures will help ensure that your heater Screen Hooks continues to perform safely and efficiently. Firebox Cleaning and Inspection Cleanliness is critical to correct operation of the heater. Glass Latch The log set, burner, valve controls and air circulation areas must all be kept free of dust and unobstructed by debris. -
Page 20: Replacement Parts
Vent-Free Gas Heater ® 10a,b 12a,b 24a,b, Vermont Castings Group reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice.` Radiance Vent Free Gas Heater Models: 3380, 3381 5056 Radiance VF PARTS Ref. - Page 21 Radiance Vent-Free Gas Heater ® Radiance Vent Free Gas Heater Models: 3380, 3381 (continued) Ref. Description Part No. Handle Package, Ceramic w/Screw 30004175K Damper Steel Handle/Screw 30002720 10a. Valve SIT - Nat. 14D0467 10b. Valve SIT - LP 14D0468 11a. Oxygenerator, NG OP #8204 55464 11b.
-
Page 22: Optional Accessories
Radiance Vent-Free Gas Heater ® Optional Accessories Fan Kits Screen Kit An optional screen, R40SK, is available for use with the FK26 Fan operable doors to allow the doors to be left in the open position. The FK26 fan helps distribute heated air from within the firebox Warming Shelf out into the room. -
Page 23: Warranty
LIMITED LIFETIME WARRANTY PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY Vermont Castings Group (hereinafter referred to collectively as the •... - Page 24 Radiance Vent-Free Gas Heater ® 149 Cleveland Drive • Paris, Kentucky 40361 www.vermontcastingsgroup.com 30005056...
