Engine Dimensions with Low-Profi le Air Cleaner-PTO Side
U
G
T
S
R
Q
A 335.04 mm (13.19 in.)
E Lift Strap
2 X 308.24 mm
I
(12.136 in.)
3/8-16 UNC-2B in.
21 mm (0.827 in.)
M Deep
165.1 mm (6.5 in.)
B.C.
Engine Mounting
Q
Surface
U M8 X 1.25 4 Studs
24 690 01 Rev. K
A
B
C
G
G
V
P
B 122.10 mm (4.807 in.)
F Oil Fill Location
2 X M8 X 1.25
J 20.5 mm
(0.807 in.) Deep
7/16-14 UNC-2B in.
21 mm (0.827 in.)
N
Deep 196.8 mm
(7.75 in.) B.C.
R Solenoid Shift Starter
V 45°
KohlerEngines.com
D
E
F
K
L
M
O
N
65.0 mm (2.559 in.)
C
Muffl er Mounting
G 30°
K 135°
Center Line Mounting
O
Hole "A"
283.58 mm (11.164 in.)
S
Muffl er Mounting
Specifi cations
G
H
I
J
D 75.42 mm (2.969 in.)
50.00 mm (1.969 in.)
H
Exhaust Port #2
5/16-24 UNC-2B in.
17 mm (0.669 in.)
L Deep
127 mm (5.0 in.)
B.C.
177.8 mm (7.0 in.)
P
Pilot Diameter
50.00 mm (1.969 in.)
T
Exhaust Port #1
11
