Disassembly/Inspection And Service; External Engine Components - Kohler command pro ECH749 Service Manual

Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.

External Engine Components

O
Heavy-Duty Air
A
Cleaner
E Paper Element
I Dipstick
M Oil Cooler
24 690 01 Rev. K
WARNING
B
N
L
M
K
Low-Profi le Air
B
Cleaner
F Precleaner
J Spark Plug Lead
N Nipple
KohlerEngines.com

Disassembly/Inspection and Service

Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
C
D
E
F
G
H
Low-Profi le Air
C
Cleaner Cover
Low-Profi le Air
G
Cleaner Base
K Oil Drain Plug
O Oil Filter
A
I
J
K
D Element Cover
H Dipstick Tube
L O-ring
103
