Model:
Everest
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • Everest • 750-900 Rev. W • 10/14
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed.
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo Everest

Summary of Contents for Heat & Glo Everest

  • Page 1 Technologies suggests NFI certifi ed or factory trained gases, unless a certifi ed kit is used. professionals, or technicians supervised by an NFI certifi ed professional. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 2: Congratulations

    BTUH: 00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 3: Table Of Contents

    E. Hearth Extensions ......42 Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 4 D. Contact Information ......58  = Contains updated information. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 5: Limited Lifetime Warranty

    3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645F 02-18-13 Page 1 of 2 Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 6 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645F 02-18-13 Page 2 of 2 Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 7: Listing And Code Approvals

    • In CANADA: Reduce input rate 10% for elevations between 2000 feet and 4500 feet. Above 4500 feet, consult local gas utility. Check with your local gas utility to determine proper orifi ce size. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 8: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 9: User Guide

    • Never leave children alone near a hot fi replace, whether operating or cooling down. Figure 2.1 General Operating Parts • Teach children to NEVER touch the fi replace. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 10: Clear Space

    Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative door or front. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 11: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 12: After Fireplace Is Lit

    Is it normal to see the pilot fl ame burn In an Intellifi re ignition system it is normal to see the pilot fl ame, but it should turn off when continually? ON/OFF is turned off. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 13: Maintenance And Service

    • Carefully set fi xed glass assembly in place on fi replace. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 14: Maintenance Tasks-Qualifi Ed Service Technician

    Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided. • Remove all foreign objects. • Verify unobstructed air circulation. Figure 3.1 IPI Pilot Flame Pattern Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 15: Installer Guide

    (SECTION 8.C) OPTIONAL WALL SWITCH (SECTION 12.C) MANTEL AND MANTEL LEG (SECTION 5.D) SURROUND HEARTH EXTENSION GAS LINE (SECTION 11) Figure 4.1 Typical System (Non-Specifi c Fireplace Model Shown) Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 16: Design And Installation Considerations

    Plumb line Safety glasses Level Reciprocating saw Manometer Flat blade screwdriver 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 17: Framing And Clearances

    4” (102 mm) 1/2” (13 mm) Inches 35-1/2 21-3/4 30-1/2 43-1/4 61-3/16 Millimeters 1099 1554 Figure 5.1 Appliance Locations Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 18: Constructing The Appliance Chase

    fi replace is 4 inches (102 mm). The back of the fi replace may be recessed 23 (584 mm) inches (546 mm) into combustible construction. Figure 5.2 Clearances to Combustibles Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 19: Mantel And Wall Projections

    Combustible Mantels CEILING = 4-1/2 INCHES AIR SPACE Figure 5.4 Non-Combustible Zone TOP FRONT EDGE OF FIREPLACE Figure 5.3. Minimum Vertical and Maximum Horizontal Dimensions of Combustibles above Fireplace Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 20: Termination Locations

    Over 16/12 to 18/12 ..........7.0 Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 21 2 sides beneath the fl oor. venting system does not meet these requirements. • Vinyl protection kits are suggested for use with vinyl siding. Figure 6.3 Minimum Clearances for Termination Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 22: Vent Information And Diagrams

    Refer to Height/Length DVP24 Section 10.J. DVP36 DVP48 1219 DVP6A 3 to 6 76 to 152 DVP12A 3 to 12 76 to 305 Figure 7.2 DVP Pipe Effective Length Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 23: Vent Diagrams

    = 40 ft. (12.2 m) Maximum 90º elbow, to allow the vent pipe to clear the top standoffs. = 20 ft. (6.1 m) Maximum Figure 7.3 Venting with One 90° Elbow Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 24 4 ft. 1.2 m 18.5 ft. 5.6 m = 40 ft. (12.2 m) Maximum = 20 ft. (6.1 m) Maximum INSTALLED HORIZONTALLY Figure 7.4 Venting with Two 90° Elbows Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 25 2.9 m* 6 in. 152 mm 9 ft.* 2.7 m* = 20 ft. (6.1 m) Maximum = 40 ft. (12.2 m) Maximum Figure 7.6 Venting with Three 90° Elbows Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 26 fl ue restrictor should be used. VERTICAL BAFFLE 5” EXHAUST PIPE FIREPLACE BOTTOM Figure 7.7 Vertical Baffl e Figure 7.6 Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 27 4 ft. 1.2 m 18.5 ft. 5.6 m = 50 ft. (15.2 m) Maximum *No specifi c restrictions on this value EXCEPT cannot exceed 50 ft (15.2 m) Figure 7.8 Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 28 1.2 m 4 ft. 1.2 m 18.5 ft. 5.6 m 18.5 ft. 5.6 m = 20 ft. (6.1 m) Maximum = 40 ft. (12.2 m) Maximum INSTALLED HORIZONTALLY Figure 7.9 Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 29: Vent Clearances And Framing

    * Shows center of vent framing hole for top or rear venting. The center of the hole is one (1) in. (25.4 mm) above the center of the horizontal vent pipe. Figure 8.2 Wall Penetration Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 30: Install The Ceiling Firestop

    Figure 8.3 Installing Ceiling Firestop INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 8.4 Installing the Attic Shield Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 31: Appliance Preparation

    • Secure the appliance to the fl oor by inserting two screws through the pilot holes at the bottom of the appliance. Figure 9.2 Rope Gasket Location NAILING TABS (BOTH SIDES) Figure 9.3 Proper Positioning and Securing of an Appliance Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 32: Installing Vent Pipe

    fl ue at the horizontal elbow joint to prevent the elbow from rotating. Use screws no longer than 1/2 in. (13 mm). If predrilling screw holes, DO NOT penetrate inner pipe. INCORRECT Figure 10.4 Seams Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 33: Assemble Slip Sections

    NOTICE: If slip section is too long, the inner and outer fl ues of the slip section can be cut to the desired length. Figure 10.8 Securing Horizontal Pipe Sections Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 34: Disassemble Vent Sections

    • Slide the roof fl ashing over the pipe sections extending through the roof as shown in Figure 10.12. CAULK Figure 10.12 Figure 10.12 Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 35: Assemble And Install Storm Collar

    • Tighten nut and make sure the collar is tight against the Caulk pipe section. • Caulk around the top of the storm collar. See Figure 10.14 Figure 10.14 Figure 10.14 Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 36: Install The Elbow Heat Shield

    See Figure 10.16. COMBUSTIBLE SURFACE CORRECT INCORRECT DIRECTION 3 IN. MIN. ELBOW HEAT SHIELD 90º ELBOW Figure 10.16 Orientation of Elbow Heat Shield Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 37: Heat Shield Requirements For Horizontal Termination

    FIRESTOP Important Notice: Heat shields may not be fi eld constructed. SLIP SECTION CAN BE EXTENDED INNER VENT SHEATHING OUTER VENT INTERIOR EXTERIOR Figure 10.17 Venting through the wall Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 38: Gas Information

    fl exible gas connector are connected to the 1/2 in. (13 mm) control valve inlet. • If substituting for these components, please consult local codes for compliance. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 39: Electrical Information

    Remove batteries before using the transformer, and unplug the transformer before installing the batteries. Battery polarity must be correct or module damage will occur. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 40: Junction Box Installation

    NOTICE: Remotes or other 120 volt powered options will Figure 12.2 Junction Box Detail not function during a power outage. (Appearance may vary per model) Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 41: Finishing

    4. Once plumbing and wiring are completed, replace splatter guard on appliance by pushing in tabs. Re- move splatter guard before lighting appliance. TABS TABS Figure 13.2 Splatter Guard Knobs Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 42: Mantel And Wall Projections

    Comply with all minimum clearances to combustibles as specifi ed in this manual. Overlapping materials could ignite and will interfere with proper operation of doors and louvers. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 43: Appliance Setup

    A bag of rock is shipped with this fi replace. Refer to Section enough for 3 to 5 applications. 14.G for placement instructions. EMBER MATERIAL Figure 14.1 Placement of Embers Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 44: Install The Log Assembly

    1/8” of the back of the orifi ce (see Figure 1). Position the base of the log next to the outer left grate tine with the burner neck resting on the grate. Place the top of the log into the groove on the back log. 750-925E 1/02 Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 45 Place the top of the right inside log #4 in the groove on the back log. Place the base of the log on the inside of the outer right grate tine with the tine fi tting in the groove on the log. Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 46 The black rock, included in the log package, can be placed below the grate on the base refractory GRATE (see Figure 2). The rock is decorative and is not required. ROCK Figure 2 Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 47: Fixed Glass Assembly

    • Install optional trim kits and/or surrounds using the instructions included with the accessory. • Use non-combustible materials to cover the gap between the sheet rock and the appliance (when applicable to the model). Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 48: Troubleshooting

    Verify module is securely grounded to metal chassis of appliance. D. Module voltage output / Valve/Pilot Verify battery voltage is at least 2.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 2.7. Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 49 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 50: Reference Materials

    Location Inches Millimeters 34-1/8 8 dia. 203.1 8-15/16 28-13/16 23-3/8 20-7/8 47-7/16 1205 36-1/8 54-1/2 1384 4-11/16 45-7/16 1154 49-7/8 1266 2-3/16 4-11/16 2-5/16 5-7/16 Figure 16.1 Appliance Dimensions Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 51: Vent Components Diagrams

    (254 mm) 14 in. (356 mm) 5 in. 12 in. (127 mm) (305 mm) 6 in. (152 mm) DVP-HVS (Vent Support) DVP-WS (Wall Shield Firestop) Figure 16.2 DVP Vent Components Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 52 Cap Shield 13-7/8 in. 9-1/2 in. 26 in. (352 mm) (241 mm) 660 mm 14 in. (356 mm) DVP-HSM-B Extended Heat Shield DRC-RADIUS Figure 16.4 DVP Vent Components Cap Shield Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 53 (41 mm) 12 in. DVP-HPC 305 mm High Performance Cap 7-1/4 in. (184 mm) 12-1/2 in. (318 mm) 5-1/4 in. (133 mm) DVP-TVHW VerticalTermination Cap (Highwind) Figure 16.5 Vent Components Heat & Glo • Everest • 750-900 Rev. W • 10/14...
  • Page 54 117 mm 12 in. Effective (305 mm) 5-3/8 in. 9-3/8 in. Length Trap2 137 mm 238 mm DVP-TRAP Horizontal Termination Cap DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 Figure 16.3 DVP vent components Heat & Glo • Everest • 750-900 Rev. W • 10/14...

  • Page 55: Service Parts

    5890485, 5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945B Printed in U.S.A. - Copyright 2014 Heat & Glo • Everest • 750-900 Rev. W • 10/14...
