Model:
Everest
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions
and the manufactured home construction and safety standard,
Title 24 CFR, Part 3280 or Standard for Installation in Mobile
Homes, CAN/CSA Z240MH, in Canada.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • Everest • 750-900 Rev. o • 10/08
Owner's Manual
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as fi re-
place.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
Installation and Operation
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo Everest

  • Page 1 fi tter. See Table of Contents for location of additional Commonwealth of Massachusetts requirements. Heat & Glo • Everest • 750-900 Rev. o • 10/08 Owner’s Manual Installation and Operation party responsible for use and operation.
  • Page 2: Safety And Warning Information

    Any safety screen or guard removed for servicing must be replaced before operating this appliance. DO NOT place furniture or any other combustible household objects within 36 inches of the fi replace front. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 3: Table Of Contents

    Step 11 Before Lighting the Fireplace ...27 Step 12 Lighting the Fireplace ...27 After the Installation ...27 Battery Backup ...27 Section 4: Maintaining and Servicing Your Fireplace..28 Contact Information ...29 = Contains updated information. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 4: Service Parts Lists

    EVEREST Service Parts Beginning Manufacturing Date: Aug. 2000 Service Parts Diagram Ending Manufacturing Date: ______ Log Set Assembly Part number list on following page. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 5 Regulator NG Regulator LP Additional service part numbers appear on following page. STANDING PILOT CONVERSION KITS Pre 5000 IPI CONVERSION KITS Post 5000 Heat & Glo • Everest • 750-900 Rev. o • 10/08 COMMENTS PART NUMBER LOGS-EVEREST SRV750-703 SRV750-701A...
  • Page 6: Service Parts

    Wire Harness Wire Harness Piezo Ignitor Service Parts IPI Valve Assembly Post Serial #5000 Heat & Glo • Everest • 750-900 Rev. o • 10/08 EVEREST Beginning Manufacturing Date: Aug. 2000 Ending Manufacturing Date: ______ (SP) Pre 5000 (IPI) Post 5000...
  • Page 7: Section 1: Approvals And Codes

    To identify the proper orifi ce size, check with the local gas utility. If installing this appliance at an elevation above 4,500 feet (in Canada), check with local authorities. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 8: Section 2: Getting Started

    Heat & Glo, not withstanding any independent testing laboratory or other party ap- proval of such component part or accessory. ANY SUCH ACTION MAY POSSIBLY CAUSE A FIRE HAZARD. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 9 34-1/8 (866 mm) TOP VENT COLLARS TOP STANDOFFS TRIM DOOR RATING PLATE AND LABELS GAS CONTROLS ELECTRICAL ACCESS Heat & Glo • Everest • 750-900 Rev. o • 10/08 (203 mm) Ø8 (203.1) 49-7/8 (1266 mm) ELECTRICAL ACCESS 4-11/16 2-5/16...
  • Page 10: Section 3: Installing The Fireplace

    B..50-1/2” (1283 mm) C..21-3/8” (542 mm) D..55-1/2” (1372 mm) Figure 3. Framing Dimensions Heat & Glo • Everest • 750-900 Rev. o • 10/08 Minimum Clearances Inches Vertical Sections..1 ... 25 Horizontal Sections Top ...3 ...
  • Page 11: Step 3 Installing The Vent System

    (5-inch inner pipe / 8-inch outer pipe) VERTICAL TERMINATION HORIZONTAL TERMINATION WALL FIRESTOP CEILING 90 DEGREE FIRESTOP ELBOW Heat & Glo • Everest • 750-900 Rev. o • 10/08 DVP4 DVP6 DVP24 DVP36 11-1/4 7-1/4 1-1/4 TYP DVP48 1/2 TYP NOTE: PIPES OVERLAP 1-1/4 INCHES (31.8 mm) AT EACH JOINT.
  • Page 12 STRAIGHT UP VERTICAL VENTING V (FT.) 40’ MAX. (12.4 M) Figure 6. Straight Up Vertical Venting Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 13 fi replace before a 90º elbow, to allow the vent pipe to clear the top standoffs. Figure 7. Venting with One 90° Elbow Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 14 4’ MIN. (1.22 m) V+H+H = 40’ MAX. (12.4 m) H+H +H = 40’ MAX. (12.4 m) Heat & Glo • Everest • 750-900 Rev. o • 10/08 H + H 10’ MAX. (3.1 m) 15’ MAX. (4.65 m) 20’ MAX. (6.2 m)
  • Page 15 4’ MIN. (1.22 m) 20’ MAX. (6.2 m) NOTE: H + H = 20’ MAX. (6.2 m) V + V + H + H = 40’ MAX. (12.4 m) Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 16: Installing Vent Components

    NENT AND THE OUTER FIREPLACE WRAP. If the installation is for a termination cap attached directly to the fi replace, skip to the sections, Install Firestops and Vent Termination. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 17 NOTE: Model DVP-TRAP does not need an exterior fi restop on an exterior combustible wall. Heat & Glo • Everest • 750-900 Rev. o • 10/08 COMBUSTIBLE SURFACE 3“ MIN.
  • Page 18 This shows an attic installation. Keep insulation away from the vent pipe at least 1 inch (25 mm). CEILING NAILS (4 REQUIRED) Figure 16. Attic Firestop Heat & Glo • Everest • 750-900 Rev. o • 10/08 ” CHIMNEY HOLE EXISTING CEILING...
  • Page 19: Vent Termination

    NOT BE RECESSED INTO A WALL OR SIDING. VENT TERMINATION CLEARANCES MUST BE FOLLOWED TO AVOID FIRE DANGER. SEE VENT TERMINATION MINIMUM CLEARANCES DIAGRAM ON FOLLOWING PAGE. Figure 17. Trapezoid Termination Cap Heat & Glo • Everest • 750-900 Rev. o • 10/08 7-1/4 in. (184 mm)
  • Page 20 Heat & Glo assumes no responsibility for the improper performance of the appliance when the venting system does not meet these requirements. Heat & Glo • Everest • 750-900 Rev. o • 10/08 (See Note 2) Electrical Service...
  • Page 21 Over 16/12 to 18/12 ...7.0 Over 18/12 to 20/12 ...7.5 Over 20/12 to 21/12 ...8.0 Figure 19. Minimum Height from Roof to Lowest Heat & Glo • Everest • 750-900 Rev. o • 10/08 HORIZONTAL OVERHANG 20 INCHES MIN. VERTICAL...
  • Page 22: Step 4. Positioning, Leveling, And Securing The Fireplace

    WARNING: CONTINUOUS 110-120 VAC SER- VICE MUST BE WIRED TO THE FIREPLACE JUNCTION BOX. WARNING: DIRECT VENT PROPANE MODELS WITH IPI CONTROL SYSTEMS CANNOT BE USED IN CANADA. Figure 21. Intermittent Pilot Ignition Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 23: Step 6 The Gas Supply Line

    (1/2) psig (3.5 kPa). Heat & Glo • Everest • 750-900 Rev. o • 10/08 USE A WRENCH ON SHUT-OFF VALVE WHEN...
  • Page 24: Step 8 Wiring The Fireplace

    CAUTION: LABEL ALL WIRES PRIOR TO DISCON- NECTION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING. Heat & Glo • Everest • 750-900 Rev. o • 10/08 INTERMITTENT PILOT IGNITOR GROUND TO...
  • Page 25: Step 9 Finishing

    A hearth extension may be desirable for aesthetic reasons. However, ANSI or CAN/CGA testing standards do not require hearth extensions for gas fi replace appliances. Heat & Glo • Everest • 750-900 Rev. o • 10/08 FINISH WALL MATERIAL MAY BE COMBUSTIBLE - TOP AND SIDES HIGH TEMPERATURE (300º...
  • Page 26: Step 10 Installing Trim, Logs, And Ember Material

    • Pull out and latch the glass clips into the groove on the glass frame. LATCHES GLASS ASSEMBLY Figure 26. Glass Assembly Glass Specifi cations: CERAMIC EMBER MATERIAL Figure 27. Placement of the Ember Material Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 27: Step 11 Before Lighting The Fireplace

    Be careful not to disconnect any wires in the process. NOTE: Remotes or other powered options will not function during a power outage. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 28: Section 4: Maintaining And Servicing Your Fireplace

    NOTE: DO NOT handle or attempt to clean the door when it is hot and DO NOT use abrasive cleaners. Heat & Glo • Everest • 750-900 Rev. o • 10/08...
  • Page 29: Contact Information

    • Read, understand and follow these instructions for safe installation and operation. Printed in U.S.A. - Copyright 2008 Heat & Glo • Everest • 750-900 Rev. o • 10/08 • Leave this manual with party responsible for use and operation.
