CDM-600 Satellite Modem
ODU Operation
D.2.32
(ODU,ENABLE,STANDALONE KST)
KST INFO:
Use the [←] or [→] arrow keys to select the type of information to view, then press
ENTER.
D.2.33
(ODU,ENABLE,STANDALONE KST,INFO)
MODEL:
HPA:
Press ENTER or CLEAR to return to previous menu.
D.2.34
(ODU,ENABLE,STANDALONE KST,INFO)
INFO: TX:OFF
Press ENTER or CLEAR to return to previous menu.
D.2.35
(ODU,ENABLE,STANDALONE KST,INFO)
INFO:
Press ENTER or CLEAR to return to previous menu.
Note: The RX Band information is not shown for the KST-2000A.
MODEL
MISC
KST-2000B
CEFD-SSPA
13955MHz
RX:
11950MHz
HPA:OFF
Band:B
LNA:OFF
TX+RX-PARAM
NUMBERS
10dB
20dB
REF:087
FLT-LOGIC:NO-SUMM
FLT-LOGIC:SUMMARY
D–15
Revision 7
MN/CDM600.IOM
