CDM-600 Satellite Modem
ODU Operation
D.2.2 ODU
ODU CONTROL=ENABLE
SYSTEM TYPE=STANDALONE (STANDALONE,1:1)
ODU CONTROL: either ENABLE or DISABLE - turns on or off the FSK link to the
ODU.
SYSTEM TYPE: either STANDALONE or 1:1.
D.2.3 (ODU)
1:1 MONITOR & CONTROL:
Use the [←] or [→] arrow keys to select the menu option, then press ENTER.
Selecting ODU#1 or ODU#2 will take the user to the menu of paragraph D.2.5. Selecting
REDUNDANCY-BOX will take the user to the following menu.
STANDALONE should be selected when the Modem is linked via the Rx IF
cable to a single Comtech EF Data ODU. Selecting STANDALONE for a CSAT
will take the user to the menu shown in paragraph D.2.5. If the modem detects a
KST, the user will be taken to the menu shown in paragraph D.2.27.
1:1 should be selected when the Modem is linked to a redundant CSAT system
via connection between the Rx IF and the ODU Redundancy Controller Box.
Selecting 1:1 will take the user to the menu shown next.
ODU#1 ODU#2
(DISABLE/ENABLE)
ENABLE, 1:1
REDUNDANCY-BOX
D–3
Revision 7
MN/CDM600.IOM
