Comtech EF Data CDM-600 Operating Instructions Manual page 219

CDM-600 Satellite Modem
ODU Operation
D.2.13 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STANDALONE CSAT)
MONITOR:
POWER-SUPPLIES
Use the [←] or [→] keys to select the parameters to monitor, then press ENTER.
D.2.14 (ODU,ENABLE,1:1,CSAT#1, MONITOR)
(ODU,ENABLE,1:1,CSAT#2, MONITOR)
(ODU,ENABLE,STANDALONE CSAT, MONITOR) TX
TX: SYNTUNE = 09.6 VDC
Press ENTER or CLEAR to return to previous menu.
D.2.15 (ODU,ENABLE,1:1,CSAT#1, MONITOR)
(ODU,ENABLE,1:1,CSAT#2, MONITOR)
(ODU,ENABLE,STANDALONE CSAT, MONITOR) RX
RX: SYNTUNE = 01.4 VDC
Press ENTER or CLEAR to return to previous menu.
D.2.16 (ODU,ENABLE,1:1,CSAT#1, MONITOR)
(ODU,ENABLE,1:1,CSAT#2, MONITOR)
(ODU,ENABLE,STANDALONE CSAT, MONITOR) MISC
MISC: REF TUNE = 03.0 VDC
Press ENTER or CLEAR to return to previous menu.
TRANSMIT RECEIVE MISCELLANEOUS
IFLO = 11.1 VDC
IFLO = 11.2 VDC
LNA = 00.05 mA
POWER = <24 dBm
TEMP = 26 C
TEMP = 26 C
FAN = 550 mA
D–9
Revision 7
MN/CDM600.IOM
