VTech VM311 User Manual

Important safety
instructions
User's manual
When using your equipment, basic safety
precautions should always be followed to
VM311/VM311-13/VM311-2/
reduce the risk of fire, electric shock and injury,
VM311-23 including the following:
1. Follow all warnings and instructions marked
TM
on the product.
Safe & Sound
2. Adult setup is required.
Full Color Video and Audio
3. This product is intended as an aid. It is not
Monitor a substitute for responsible and proper adult
supervision and should not be used as
such.
4. This product is not intended for use as a
BC
medical monitor.
5. Do not use this product near water. For
example, do not use it next to a bath tub, wash
bowl, kitchen sink, laundry tub or swimming
pool, or in a wet basement or shower.
6. CAUTION: Use only the batteries indicated in
this manual. There may be a risk of explosion
if a wrong type of battery is used for the parent
unit. Use only the supplied rechargeable
battery or replacement battery pack
(BT185645/BT285645) for the parent unit. Do
not dispose of batteries in a fire. They may
explode. Dispose of used battery according to
Congratulations
the information in The RBRC
7. Use only the adapters included with this
on purchasing your new VTech product.
product. Incorrect adapter polarity or voltage
Before using this product, please read
can seriously damage the product.
Important safety instructions.
Baby unit power adapter:
For support, shopping, and everything new at AC 150mA 50/60Hz; Output: 6V DC 600mA
VTech, visit our website at Parent unit power adapter:
AC 150mA 50/60Hz; Output: 6V DC
www.vtechphones.com.
8. The power adapters are intended to be
Register online to get an additional
correctly oriented in a vertical or floor mount
3-month warranty! position. The prongs are not designed to
hold the plug in place if it is plugged into a
Visit www.vtechphones.com. ceiling, under-the-table or cabinet outlet.
9. Unplug this product from the wall outlet
Registration
before cleaning. Do not use liquid or aerosol
Register your product online for
cleaners. Use a damp cloth for cleaning.
enhanced warranty support.
10. Unplug the power cords before replacing
batteries.
Product news
11. Do not cut off the power adapters to replace
Learn about the latest VTech
them with other plugs, as this causes a
products.
hazardous situation.
12. Do not allow anything to rest on the power
cords. Do not install this product where the
Connect the baby unit Charge the parent unit battery
Once you have
its battery, press and hold
Power outlet not
battery icon indicates the battery status (see
controlled by a wall switch
the table below). The parent unit battery is fully
charged after 12 hours of continuous charging.
The standby time varies depending on the
Baby unit power adapter
sensitivity level you set, your actual use and
the age of the battery.
When the parent unit is operating in battery
mode and the battery is low, you need to
charge the parent unit without interruption for at
least 30 minutes to give the parent unit enough
Self-adhesive
charge to use for a short time. When operating
strap
in low battery condition, the parent unit displays
. The
the parent unit plays short beeps to alert you.
The following table summarizes the battery
charge indicators and actions to take.
Baby unit
Battery
indicators
Connect the parent unit
The battery
icon is off and
Power outlet not controlled displays.
by a wall switch
Parent unit power adapter
Self-adhesive
strap
The screen
displays
The
flashes.
The battery
icon
becomes
solid .
cords may be walked on or crimped.
13. This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the type
of power supply in your home, consult your
dealer or local power company.
14. Do not overload wall outlets or use an
extension cord.
15. Do not place this product on an unstable
table, shelf, stand or other unstable surfaces.
16. This product should not be placed in
any area where proper ventilation is not
provided. Slots and openings in the back
or bottom of this product are provided
for ventilation. To protect them from
overheating, these openings must not be
blocked by placing the product on a soft
surface such as a bed, sofa or rug. This
product should never be placed near or over
a radiator or heat register.
17. Never push objects of any kind into this
product through the slots because they may
touch dangerous voltage points or create a
short circuit. Never spill liquid of any kind on
the product.
18. To reduce the risk of electric shock, do
not disassemble this product, but take it to
an authorized service facility. Opening or
removing parts of the product other than
specified access doors may expose you to
seal.
®
dangerous voltages or other risks. Incorrect
reassembling can cause electric shock when
the product is subsequently used.
19. You should test the sound reception every
Input 100-240V
time you turn on the units or move one of
the components.
Input 100-240V
20. Periodically examine all components for
600mA.
damage.
21. Be aware of possible loss of privacy while
using public airwaves. Conversations may
be picked up by other nursery monitors,
cordless phones, scanners, etc.
22. Children should be supervised to ensure
that they do not play with the product.
23. The product is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Before use
installed the parent unit and
to turn it on. The
You may test the baby monitor before initial
use, and at regular times thereafter.
To test your video and audio monitor:
1. Place the parent unit and the baby units in
the same room to test the product. Make
sure the baby units are at least 3 feet away
from the parent unit.
2. Press and hold
the POWER light turns on.
3. Press and hold
the POWER light turns on.
I f both units are not connected, the parent
light on the parent unit flashes and
unit displays
unit. If no baby unit is found after a while,
it displays
Positioning the baby monitor
Battery Action
Place the parent unit within the operating range
status
of the baby unit. We recommend the parent
No battery Install the unit is at least 3 feet away from the baby unit
is installed parent unit to avoid audio feedback. If you still experience
but operates battery. audio feedback, move the parent unit and the
using AC Charge baby unit farther apart.
power, or the
without
For better image quality, do not place the
baby unit too far away from your baby.
battery has interruption
been installed (at least 30
For desktop usage and/or wall mounting the
incorrectly. minutes).
baby unit, you can refer to Installation guide.
The battery Charge
Operating range
. has very little without
light charge and interruption
The operating range of the baby monitor is up
may be used (about 30
to 1,000 feet outdoors or 150 feet indoors. The
for only a minutes).
actual operating range may vary depending
short time.
on the environmental conditions and other
interferences such as walls, doors and other
The battery is To keep
obstructions.
fully charged. the battery
charged,
connect it to
AC power
when not in
use.
When you charge the battery initially or it is
not used for a long period of time, charge
it for 12 hours continuously. It takes longer
to charge the battery when the parent unit
is turned on. To shorten the charging time,
turn the parent unit off while charging.
Cautions
1. Use and store the product at a temperature
between 32 o F and 104 o F.
2. Do not expose the product to extreme
cold, heat or direct sunlight. Do not put the
product close to a heating source.
3. Batteries should not be exposed to
excessive heat such as bright sunshine
or fire.
4. Make sure the baby unit(s) and the adapter
cord(s) are always out of reach of the baby,
at least 3 feet away from the baby or crib, to
avoid a possible strangulation hazard.
5. Never place the baby unit(s) inside the
baby's crib or playpen. Never cover the
baby unit(s) or parent unit with anything
such as a towel or a blanket.
6. Other electronic products may cause
interference with your baby monitor. Try
installing your baby monitor as far away
from these electronic devices as possible:
wireless routers, radios, cellular telephones,
intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital
cordless devices):
Wireless Technology Research, LLC (WTR),
an independent research entity, led a
multidisciplinary evaluation of the interference
between portable wireless devices and
implanted cardiac pacemakers. Supported by
the U.S. Food and Drug Administration, WTR
recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six
inches from the pacemaker.
• Should NOT place wireless devices directly
over the pacemaker, such as in a breast
pocket, when it is turned ON.
WTR's evaluation did not identify any risk
to bystanders with pacemakers from other
persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards
regarding electromagnetic fields (EMF).
If handled properly and according to the
instructions in this user's manual, the product
is safe to be used based on scientific evidence
available today.
Overview
Baby unit overview
on the baby units until
on the parent unit until
while searching for a baby
.
1 Camera
2 Infrared LEDs
Backup light for night vision.
3 POWER on/off indicator
• On when the baby unit is powered on
and currently linked to parent unit.
• Flashes when the baby unit is not
linked to a parent unit; or
the pairing process is in progress; or
the parent unit is not viewing this baby
unit.
4 Power jack
5 Control key panel
/VOL +
Press to increase the listening volume.
/VOL-
Press to decrease the listening volume.
PAIR
Press and hold to pair to the parent unit.
(On/Off)
Press and hold to turn on or off.
6 Microphone
7 Stand
Tilt to adjust the camera angle.
8 Rim
9 Base
Part checklist
3. Align the battery compartment cover flat
against the battery compartment, then
place down and slide it towards the center
of the parent unit until it clicks into
Replace the battery
1 set for
VM311/VM311-13;
To replace the battery, pull the battery out of
2 sets for
the battery compartment and unplug the battery
VM311-2/VM311-23
connector from the socket, then follow the steps
above to install the battery.
Install the battery
•
You can power up the parent unit by connecting
it to AC power or to the rechargeable battery
provided. Even if the parent unit is connected
to AC power, we recommend you also
•
install the battery. This guarantees continual
operation in case of a power outage.
Install the battery as shown below.
Connect and charge the
1. Slide and lift to open the battery compartment
cover.
battery
•
•
2. Plug the battery connector securely into
•
the socket.
•
Parent unit overview
5 Control key panel
/VOL +
•
•
•
MENU/SELECT
•
•
/VOL-
1 Visual sound indicator
•
Visual sound indicator shows the sound
•
level detected from baby unit. It also
shows the volume level during speaker
•
volume setting.
Sound level detected from the baby unit
is independent from the volume level
/
set at the parent unit.
•
• Green lights
indicate a moderate sound level
•
detected from the baby unit; or
Level 1 to Level 3 of the speaker
volume setting.
• Red lights indicate
/
a higher sound level detected from the
baby unit; or •
Level 4 to Level 5 of the speaker
•
volume setting.
2 Battery level indicator
•
• Light On when the parent unit battery
is being charged.
• Light Flashes when the parent unit
TALK
battery is low and needs charging.
While viewing image, press and hold to
• Light Off when the parent unit battery
talk to the selected baby unit.
is fully charged, or when no battery is
installed.
(On/off)
3 POWER on/off indicator
•
• On when the parent unit is turned on.
•
• Flashes when in pairing process, or
6 Slot for portable use
when connecting to baby unit while
Stand
7
the baby unit is not available.
8 Battery compartment cover
4 Power jack
Make sure the supplied rechargeable
battery with the label THIS SIDE UP facing
up.
THIS SIDE UP
place.
The operating time for using the
rechargeable battery is short. If you want
to monitor your baby for a long time, we
recommend you connect the parent unit
to AC power.
If the parent unit will not be used for a long
time, disconnect and remove the battery to
prevent possible leakage.
Use only the battery supplied with this
product.
Use only the parent unit power adapter or
the baby unit power adapter supplied with
this product.
The parent unit power adapter and
baby unit power adapter are intended
to be correctly oriented in a vertical or
floor mount position. The prongs are not
designed to hold the plug in place if it is
plugged into a ceiling, under-the-table or
cabinet outlet.
Make sure the parent unit, the baby unit
and the power adapter cord are out of
reach of children.
Press to increase the speaker volume.
While in the menu, press to scroll up.
While viewing a zoomed image,
press and hold to move the image
upward.
Press to enter the menu.
While in a menu, press to choose an
item, or save a setting.
Press to decrease the speaker
volume.
While in the menu, press to scroll
down.
While viewing a zoomed image,
press and hold to move the image
downward.
While in a menu, press to choose the
option on the left side.
While viewing a zoomed image, press
to zoom out; or
press and hold to move the image
leftward.
While in a menu, press to choose the
option on the right side.
While viewing image, press to zoom
in.
While viewing a zoomed image,
press and hold to move the image
rightward.
Press and hold to turn on or off.
Press to turn on or off the screen.
